ITEM #0355455 #0355452 #0354705 Portfolio® is a registered trademark of LF, LLC. All Rights Reserved. 3-LIGHT VANITY BAR MODEL #VB256-3BNK #VB256-3CH #VB256-3WDBZ Français p. 9 Español p. 17 ATTACH YOUR RECEIPT HERE Serial Number Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-800-643-0067, 8 a.m. - 6 p.m., EST, Monday - Thursday, 8 a.m. 5 p.m., EST, Friday. EB12289 Lowes.
PACKAGE CONTENTS PART A DESCRIPTION Fixture QUANTITY 1 B Mounting Plate (preassembled to fixture (A)) 1 C Socket Ring (preassembled to fixture (A)) 3 A B C HARDWARE CONTENTS (shown actual size) AA E3 Wire Connector BB Mounting Plate Screw Qty. 4 Qty. 3 SAFETY INFORMATION READ AND SAVE THESE INSTRUCTIONS. Please read and understand this entire manual before attempting to assemble, operate or install the product.
SAFETY INFORMATION DANGER • DO NOT connect the bare or green insulation fixture ground wire to the black (HOT) current-carrying wire or the white neutral house wire. Connection of the bare or green fixture ground wire to the black or white house wires may cause metal parts of the fixture to carry electrical currents. Under this condition anyone coming in contact with the fixture will receive electrical shock, which could cause serious injury or death.
PREPARATION Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product.
ASSEMBLY INSTRUCTIONS 3. Remove mounting plate (B) from fixture (A) by removing mounting plate screws (BB) from the edges of the fixture (A). 3 BB Save mounting plate screws (BB) for later use. B Hardware Used BB Mounting Plate Screw E x4 A BB 4. Attach mounting plate (B) to the outlet box (not included) using the existing outlet box screws and washers.
ASSEMBLY INSTRUCTIONS 5. Unwrap BARE wire from BLACK and WHITE wires. Prepare wire by stripping 3/4 in. of insulation from wire ends using wire strippers (not included). Connect WHITE wire from fixture (A) to WHITE wire from outlet box using existing wire connector or wire connector (AA). Connect BLACK wire from fixture (A) to BLACK wire from outlet box using existing wire connector or wire connector (AA).
ASSEMBLY INSTRUCTIONS 7. Align holes in fixture (A) with fixture screws on mounting plate (B) and push fixture (A) toward wall. Attach fixture (A) to mounting plate (B) using the mounting plate screws (BB) that were previously removed. Note: Fixture (A) can be installed with the sockets facing either up or down. 7 BB B NOTE: Before tightening mounting plate screws (BB) completely, use level to check fixture (A)--adjust if necessary. Hardware Used BB Mounting Plate Screw A x3 BB 8.
CARE AND MAINTENANCE • Shut off main power supply. Wipe fixture with soft, damp cloth. Use window cleaner to clean glass. Do not use an abrasive cleaner on glass or fixture. TROUBLESHOOTING WARNING: Before beginning work, shut off the power supply to avoid electrical shock. PROBLEM Bulb will not light. POSSIBLE CAUSE 1. Bulb is burned out. 2. Power is OFF. 3. Faulty connection. CORRECTIVE ACTION 1. Replace light bulb. 2. Make sure power supply is ON. 3. Check wiring and all connections.
