Mixing ratio of gasoline and oil:
Pure two-stroke oil
…………………
30:1
Other standard two-stroke oil
…………………
25:1
Warning Danger
Inanycase,slowlyloosenthefuelcontainercoveruntil
thepressureinsidethecontaineris basically equalto
the external pressure and then remove the container
covertoopenthecontainer.
--Do not directly mix fuel in the engine oil tank.
-- Prevent gasoline and oil from spillage in the lling process.
Wipe the spilled fuel.
--Fuel is easy to burn. Use fuel with care.
--Keep fuel in the standard container with safety certicate.
Chain lubrication
The friction between the chain and guide plate
can be reduced by means of good lubrication,
thus, the service life of the chain and guide plate
can be prolonged. Use high-quality special chain
lubricating oil.
Do not use waste oil or oil of unknown brand, so as to avoid
failure of the oil pump.
SAE30
…
used in summer.
SAE10
…
used in winter or for cutting of trees with a lot of resin.
Start-up operations
Start-up mode
Start-up on the
ground
Start-up between
both knees or legs
1. Start-up on the ground
• Safely set the chain saw on the ground. Ensure that you
can stably stand on the ground and the chain will not
contact with any object or the ground.
• Hold the front handle with the left hand. Press the chain
saw on the ground, with the thumb under the handle.
• Put the right foot in the right handle and press the chain
saw.
2. Start-up between both knees or legs
• Clamp the rear handle with the thigh parts adjacent to the
knees.
• Hold the front handle with the left hand, with the thumb
under the handle.
Start-up operations
Carefully lift the starter handle with the right hand to the stop
position. Then rapidly pull the handle with force and press
the front handle down. Do not pull the start rope to the largest
extent; otherwise, the start rope may be broken. Prevent free
bounce of the starter handle. Instead, slowly lead the start rope
into the shell so as to properly roll the rope.
Attention
Donotpullthestartropetothelargestextent.
Preventsuddenretractionofthestarterhandleinthe
oppositedirectionofthebox.
Cold start of engine
Starter
handle
HL
2
1
4
1
Chain braking
direction
1. Fill the mixed fuel into the fuel tank. Prevent fuel from
overow onto the fuel tank in the lling process.
2. Fill lubricating oil into the oil tank.
3. Press the front bafe forwards (in the position of chain
brake activation).
