Stop switch
H
Choke valve
pulling rod
4. Put the stop switch in the upper position.
5. Pull out the whole choke valve pulling rod.
6. Safely control the chain saw.
7. Check whether the guide plate and chain are free from
contact with any object before starting the engine.
8. Pull the starter handle several times until the ignition
sound is uttered by the engine.
9. Push in the whole choke valve pulling rod.
10. Pull the starter handle again until the engine is started.
Warning Danger
If the chain brake is not activated but the engine is
started, the chain will rotate. Do not start the engine
untilthechainbrakeisactivated.
If the engine cannot be started easily:
1. Check whether fuel and oil are lled.
2. Press the front bafe forwards (in the position of chain
brake activation).
3. Put the stop switch in the upper position.
4. Safely control the chain saw.
5. Pull the starter handle.
Operation
Make the engine rotate at idle speed several minutes after start-
up. Gradually press the throttle to accelerate the engine.
Warning
Aftertheengineisstartedandthethrottleispressed,
theclutchwillbeengaged,andthechainwillrotate.
Aftertheengineisstarted,releasethethrottleand
keeptheengineoperatingatidlespeed.
The chain will rotate when the engine
speed is approximately 4,300rpm.
Check whether the acceleration is
normal and whether the chain saw
and guide plate are well lubricated.
Do not operate the engine at high
speed unless otherwise required.
Check whether the chain saw stops running after the throttle is
released.
Warning
1. After the engine is started, rapidly pull back the
frontbafe(toreleasethechainbrake).
2. Donotacceleratetheengineifthechainbrakeis
stillengaged.
3. The chain brake must be used in emergencies.
Unless it is absolutely required, the chain brake
mustnotbeused.
Stop operations
Loosen the throttle to make the engine operate at idle speed.
Set the stop switch in the stop position.
Attention
Iftheenginecannotbestopped,pulloutthewhole
chokevalvepullingrodtostoptheengine.Restartthe
engineafterinspectionandmaintenanceoftheignition
switch.
Cutting test
Be familiar with the chain saw before actual cutting. Therefore,
it is wise to perform cutting tests with small logs or branches.
People or small animals must not enter the working area. Chain
saw operators work in the same area must keep a sufcient
safety distance.
Trigger
Trigger control arm
