User Manual

８
● #2~#6 LEDs: The #2 LED is orange and the #3~#6 LEDs are green,
these LEDs indicate the percentage of the load level in Line mode and
Bypass mode, or the battery capacity in Battery mode.
4.1.2 The Corresponding Form of the LED Display
Table 1. The corresponding form of the Panel Interface.
No.
Status
LED display
Alarm
#1 #2 #3 #4 #5 #6 #7 #8 #9 #10
1
Line
Mode
0~35%
Load
● ● ● None
2
35%~55%
Load
● ● ● ● None
3
55%~75%
Load
● ● ● ● ● None
4
75%~95%
Load
● ● ● ● ● ● None
5
95%~105%
Load
● ● ● ● ● ● ● None
6
Battery
Mode
0~20%
Battery
capacity
● ● ★
Beep once
every sec,
◆
7
20%~40%
Battery
capacity
● ● ● ●
Beep once
every 4 sec,
◇
8
40%~60%
Battery
capacity
● ● ● ● ●
Beep once
every 4 sec,
◇
9
60%~80%
Battery
capacity
● ● ● ● ● ●
Beep once
every 4 sec,
◇
10
80%~100%
Battery
capacity
● ● ● ● ● ● ●
Beep once
every 4 sec,
◇
