User's Manual

G3L-1929-75 Installation and Service Manual
Table 1-3 G3L-1929-120 Amplifier Mechanical Specifications
Physical Dimension of
MCPA (inches)
Front panel: 13.98 W x 3.90 H x 0.118 D
Body: 11.61 W x 3.75 H x 17.56 D
Weight Approximately 28.6 pounds (13 killograms)
Connector Type
D-sub, Hybrid, Plug-in Type RF connector: PKZ 26-0020 series
straight plug type (Phoenix Co.) refers to attached drawing.
MCPA Front Panel
Switch
On/Off Switch and +27 Vdc Power Indicator
Pin Outs
A1 RF Input (Coaxial Contact)
A2 +27 Vdc (Power Contact)
A3 Ground (Power Contact)
A4 RF Output (Coaxial Contact)
1 TX H 10 +27 V
2 TX L 11 COM SV
3 GND 12 AMP AO
4 RX H 13 AMP A1
5 RX L 14 AMP A2
6 GND 15 AMP A3
7 HERE LPA 16 NC
8 FF LPA 17 NC
21WA4 Connector
Description
9 RESERVED
Front Panel LED Display: LED type: SMD
RUN Green (When MCPA is enabled)
ALM Red (When any alarm occurred, LED is on)
DC Green (When DC Power is ON, LED is on)
Table 1-4 G3L-1929-120 Amplifier Environmental Specifications
Operating Temperature
-10 to + 60° C
Storage Temperature
-40 to + 85° C
Relative Humidity 5 to 95% RH (non-condensing)
 Copyright Powerwave Technologies, Inc., May 2003. All rights reserved
044-05138 Rev. A 1-3 May 2003
