Manual

Model 4069 ProfileIR
TM
User Manual Maintenance
Research, Inc. 31
Accessories, Spare, and Replacement Parts – Heater
Model Description
103390-003
103390-004
103390-005
103390-007
103390-010
106721-001
106721-002
106721-003
106721-004
106778-001
106778-002
106895-001
106895-002
106895-003
106895-004
106895-005
106895-006
106895-007
106895-008
M4069P
Replacement Lamp For:
12kW or 18kW maximum-power rated heater (10 inch length, 1000-watts)
24kW or 36kW maximum-power rated heater (10 inch length, 2000-watts)
19kW or 29kW maximum-power rated heater (16 inch length, 1600-watts)
30kW or 45kW maximum-power rated heater (25 inch length, 2500-watts)
46kW or 68kW maximum-power rated heater (38 inch length, 3800-watts)
Replacement Reflector For:
10-inch length
16-inch length
25-inch length
38-inch length
Replacement End Reflectors (Four required per heater) for:
12-reflector size heater
18-reflector size heater
Spare Split Quartz Liner Half (Two required per heater) for:
12-reflector, 10-inch length
12-reflector, 16-inch length
12-reflector, 25-inch length
12-reflector, 38-inch length
18-reflector, 10-inch length
18-reflector, 16-inch length
18-reflector, 25-inch length
18-reflector, 38-inch length
Additional User Manual
