Owner manual

5
AMS-1000 Features:
1—Billet aluminum enclosure and all parts are specified over an extended temperature range.
2—Vibration and weather proof.
3—System software can be erased and reprogrammed by the factory for future software updates.
4—User settings will remain for up to 20 years with no power applied. No back up batteries are needed.
5—Factory default RESET available in the options menu to restore controller to state it was out of the
box from the factory.
6—Launch mode programmable to range of selected MAP sensor.
7—Scramble boost to apply an amount of pressure that you program to the gate, thus increasing boost
no matter where in the main program you are currently at. Think of it as an emergency boost button
(kinda like a shot of nitrous) Remove the signal and it goes back to current target psi. Can be used as a
single stage of boost
8— Reduce boost which works the opposite of scramble. It will remove a programmed amount from the
current target psi. If you spin stab a button and it will reduce power instantly.
9—Delay timer for Activation in Shift Based Mode and First stage of Time based mode may be used as
a delay timer.
10—Multiple operating modes:
Time Based (up to 6 stages) programmable to 1 hundredth of a second.
Shift Based (up to 6 stages)
GPS (up to 6 gears), self learning, can be used on anything with a voltage output to indicate
gear position.
11—Programmable Ramp Rate to control the rate at which the pressure is applied. 0 to 100 psi range.
12—Dual output channels available or the auxiliary channel may be used for live boost pressure data
viewing and data logging. Basically there are 2 controllers in 1 box. You can control multiple waste gate ,
valves, blow offs on supercharged systems thus giving you boost control.
13—Integrated Dual channel data logger with 35 seconds of record for each channel. Graph view of
logged data. Logged data will remain until it is erased by user.
14—Graph view of programmed settings.
15—Display backlight and contrast is user adjustable from the options menu.
16—Help screens and setup wizards to help with setup.
17—Most inputs can be configured for + 12volt or ground activation.
18—All inputs have input protection diodes. All outputs have integrated noise suppression devices to
clamp fly back voltage from solenoids.
19—Outputs short circuit protected and over current protected( 7 amp Maximum)
20—Reverse battery protection.
Click for Index.
Back
Next
NOTE—Target Psi is the amount applied to the waste gate and is NOT the actual Manifold Boost Psi!
