WASHER-DRYER LPR 721 PROGRAMMES SPIN REDUCTION QUICK WASH HALF LOAD RINSE HOLD ON/OFF A U T O WA S H 1 2 0 0 LPR 721 132983050 INSTRUCTION BOOKLET GB
Important Safety Information It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant warnings. These warnings have been provided in the interest of safety.
Contents For the User Important Safety Information Your New Washer-Dryer Description of the Appliance Detergent dispenser drawer Child Safety Feature 2 4 Washing 5 kg of white cotton at 95°C Load the laundry Measure out the detergent Measure out the fabric softener Select the required options Select the required programme Start the machine At the end of the programme Washing 2 kg of mixed fabrics at 50°C Load the laundry Measure out the detergent and fabric softener Select the required options Select the
Your New Washer-Dryer Your new machine meets all modern requirements for effective treatment of laundry with low water, energy and detergent consumption. It is gentle with your laundry, simple to use and easy to care for. ● The special wool programme with its new delicate wash system treats your woollens with extreme care. ● The anti-unbalance device ensures that the machine remains stable when spinning.
Description of the Appliance 1 Detergent dispenser drawer 2 Programme guide 3 Drying indicator light 4 Drying time selector dial 5 “Option” buttons 6 “ON/OFF” button 7 “Mains-on” light 8 Programme selector dial 9 Door opening handle 10 Filter 11 Adjustable feet 1 34 5 67 8 PROGRAMMES SPIN REDUCTION QUICK WASH HALF LOAD RINSE HOLD ON/OFF A U T O WA S H 1 2 0 0 LPR 721 2 9 10 11 Detergent dispenser drawer Prewash Main wash Fabric softener Programme chart The programme chart is in the interio
The Control Panel PROGRAMMES SPIN REDUCTION QUICK WASH HALF LOAD RINSE HOLD ON/OFF A U T O WA S H 1 2 0 0 LPR 721 1 2 3 4 5 6 7 8 9 1 Detergent dispenser drawer 10 Important! In order to save energy and to avoid too long drying times we suggest not to reduce the spin speed when you wash and dry automatically. The programme chart is in the interior part of the drawer. 2 Drying indicator light 5 QUICK WASH button This light illuminates when the machine is drying.
3 ON/OFF button By depressing this button the machine starts operating. When depressing it again, the machine stops. The push button is provided with a child-proof safety lock. Move the small slider placed in the middle of the button downwards to lock the button in the «off» position. 9 Mains-on light This light will illuminate when the machine starts working and goes out when the ON/OFF button is depressed again to switch the machine off.
Operating Sequence 3. Measure out the fabric softener Before the first wash, we recommend that you run a cotton cycle at 95°C, without any laundry in the machine, to remove any manufacturing residue from the drum and tub. Pour 1/2 a measure of detergent into the dispenser drawer and start the machine. If required, pour fabric softener into the compartment marked (the amount used must not exceed the “MAX” mark in the drawer). Close the drawer gently.
6. Start the machine Before starting up the machine check that: ● the appliance is plugged in ● the water supply tap is turned on ● the drain hose is correctly and securely positioned ● the door and the detergent dispenser drawer are closed. Depress the ON/OFF button : the mains-on light will illuminate and the machine starts operating. ON/OFF P0471S 7. At the end of the programme The machine stops automatically.
WASHING 2 KG OF MIXED FABRICS AT 50°C Suppose you have 2 kg of mixed fabrics to wash. They are rather delicate fabrics and should not be washed at a high temperature. 4. Select the required programme Turn the programme selector dial clockwise to the programme H. 1. Load the laundry PROGR AMMES H Open the door by pulling the catch outward. Place the laundry in the drum, one item at a time, shaking them out as much as possible. Close the door. P0429M 5.
DRYING 2.5 KG OF COTTON You have for example just machine-washed and spun at 1200 rpm 5 kg of laundry. They are cotton fabrics of medium weight which you want to iron as soon as they are dry. Switch off the machine. Then remove the laundry from the appliance and divide the items to obtain two loads of approx. 2.5 kg each. 4. Start the machine Depress the ON/OFF button , the mains-on light and drying light will illuminate and the machine starts operating. ON/OFF 1.
AUTODRYING 1.5 KG OF MIXED FABRICS You intend to wash and dry automatically 1.5 kg of mixed fabrics which have to be ironed. Proceed as follows: 5. Select the required time Following indications given in the programme chart on page 17, turn the time selector dial clockwise to the 90 mins setting in the black sector. 1. Load the laundry Open the door by pulling the catch outward. Load the items one at a time and close the door. 90 120 2.
Washing and Drying Hints Do NOT overload the machine. Weigh the laundry the first few times you use the appliance.
Which detergent?.... And in which form? To ensure you obtain the best wash results from your appliance, it is important to use the right detergent in your everyday wash, and only detergents recommended for use in automatic machines. To maintain the appearance of your clothes and household textiles and to make them last longer you should use different types of detergent for different washes, whether for whites, colours or delicates.
Washing Programmes Programmes for cotton and linen Wash programme Degree of soil and type of laundry Whites with prewash For heavy soiled cotton items (whites and coloureds). Whites White cotton, for example normally soiled work garments, sheets, household linen, underwear, towels. Fast coloured cotton or Fast coloureds linen fabrics, shirts, underwear, towels. Programme dial position Description Possible options Max. Progr. time load mins.
Washing Programmes Degree of soil and type of laundry Possible options Max. Progr. time load mins.
Drying Programmes Degree of drying Programme/ Type of fabric Max. load Spin speed Drying time mins G 2.5 kg 1200 85-95 Red sector 1.5 kg 1200 55-65 Red sector 1.5 kg 850 110-120 Black sector Synthetics and mixed fabrics (jumpers, blouses, underwear) 1 kg 850 65-75 Black sector G 2.5 kg 1200 60-70 Red sector Cotton and linen (sheets, tablecloths, shirts, etc.) 1.5 kg 1200 40-50 Red sector L 1.
Wash Care Symbols Wash care labels inside garments recommend how to launder your clothes with the best results. The care labelling code is in line with care labelling used in the rest of Europe. The symbols used make it easy to select the correct programme on your washing machine. WASHING SYMBOL WASH ACTION 95 Normal (Maximum) White Cotton or Linen without Special Finishes 60 Normal (Maximum) Cotton, Linen or Viscose without Special Finishes Colourfast at 60°C.
Maintenance and Cleaning Before any maintenance or cleaning is carried out you must DISCONNECT the appliance from the electricity supply. Descaling The water we use normally contains lime. It is a good idea to periodically use a water softening powder in the machine. Do this separately from any laundry washing, and according to the softening powder manufacturer's instructions. This will help to prevent the formation of lime deposits.
Unscrew and remove the filter. Clean carefully under a fast running tap. The dangers of freezing If the machine is exposed to temperatures below 0°C, certain precautions should be taken. ● Turn off the water tap. ● Unscrew the inlet hose. ● Unhook the drain hose from the rear support and position the end of this hose and that of the inlet hose in a bowl. Run the draining programme. ● Disconnect the appliance. ● Screw the inlet hose and reposition the drain hose.
Something Not Working Certain problems are due to lack of simple maintenance or oversights, which can be solved easily without calling out an engineer. Before contacting your local Service Centre, please carry out the checks listed below. IMPORTANT: if you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation, a charge will be made even if the appliance is under guarantee.
Symptom Possible causes The door will not open ● ● ● The programme is still running. The door lock has not yet released. There is water in tub. The door can not be opened if water is present in the tub. The machine makes an unusual noise ● The machine is fitted with a type of motor which makes an unusual noise compared with other traditional motors. This new motor ensures a softer start and more even distribution of the laundry in the drum when spinning, as well as increased stability of the machine.
Customer Care Bedfordshire LU4 9QQ Tel 08705 950 950* * calls to this number may be recorded for training purposes.
Installation Instructions It is dangerous to alter the specifications or attempt to modify this product in any way. Care must be taken to ensure that the appliance does not stand on the electrical supply cable. Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. Any plumbing work required to install this appliance should be carried out by a qualified plumber or competent person.
Unpacking Set the machine upright and remove the two remaining bolts from the back. Pull out the three plastic spacers from the holes into which the bolts were fitted. Plug the open holes with the plugs which you can find in the envelope containing the instruction booklet. All transit bolts and packing must be removed before using the appliance. You are advised to keep all the packaging for re-use in case the machine is to be transported again. Using a spanner unscrew and remove the rear right bolt.
Water inlet Connect the hose to a tap with a 3/4” thread. Do not use previously used hoses for water connection. U piece supplied P1199 Place the drain hose into your standpipe, which should have an internal diameter of approximately 38mm thus ensuring there is an air break between the drain hose and standpipe. P1088 Installation should comply with local water authority and building regulations’ requirements. The appliance must be connected to a cold water supply. A minimum water pressure of 0.
Any necessary adjustment can be made with a spanner. Accurate levelling prevents vibration, noise and displacement of the machine during operation. Some vibration is inevitable, especially if mounted on a wooden floor. Sprung wooden floors are particularly susceptible to vibration. For advice, consult a builder. If possible, always place the machine on a solid floor. 2. Onto a sink outlet spigot. If the outlet spigot has not been used before, remove any blanking plug that may be in place.
Electrical connection The wire coloured blue must be connected to the terminal marked «N» or coloured black. The wire coloured brown must be connected to the terminal marked «L» or coloured red. Upon completion there must be no cut, or stray strands of wire present and the cord clamp must be secure over the outer sheath. Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. WARNING: THIS APPLIANCE MUST BE EARTHED.
Building-in The height (C-Fig. C) depends on the height of the adjacent furniture's base. This appliance has been designed to be built into the kitchen furniture. The recess should have the dimensions shown in picture A. B 35 Ø 12.5-14 depth 16 -22 600 570 min. 120 416 818 176,5 820 min 596 515 ,5 22+1 98 595-5 1 195 54 C P0422S 160 8 C 416 600 165 90 0 49 P0965 A b) Hinges To mount the hinges it is necessary to drill two holes (dia. 35 mm, depth 12.
Position the base into the recess with its front edge as far forward as the adjoining plinth line will allow. The reason for placing the base in this position is to allow a small strip of beading to be fitted in front of the appliance feet. f the door has to be opened from left to right, invert the position of the plates (7), the magnet (4) and the plate (5) (Fig. B and E).
From the Electrolux Group. The world’s No. 1 choice. The Electrolux Group is the world's largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx. USD 14 billion in more than 150 countries around the world.
