User guide

www.princetontec.com
ENGLISH
Figure 1 – Switch Operation Opération de commutation Betriebsartenschalter
* Princeton Tec calculates total burn time as the time it takes for the light source to produce a
minimum of 0.25 lux at 2 meters. 0.25 lux is about the equivalent of a full moon on a clear night.
* Princeton Tec berechnet die Gesamtbrenndauer bezogen auf eine von der Stirnlampe erzeugte
minimale Beleuchtungsstärke von 0,25 Lux in 2 Meter Abstand. 0,25 Lux entsprechen in etwa
der Beleuchtungsstärke des Vollmonds in einer klaren Nacht.
* Princeton Tec définit la durée totale d’éclairage comme le temps nécessaire à la source
lumineuse pour produire un minimum de 0,25lux à 2mètres. 0,25lux équivaut à peu près à la
luminosité d’une pleine lune dans un ciel nocturne dégagé.
TM
REMIX
LED HEADLAMP
Operating and Maintenance
Instructions
Notice d’utilisation et d’entretien
Bedienungsanleitung
Battery Installation – See Battery Installation Diagram
• 3 AAA
• Alkaline (LR03)
• Rechargeable NiCad or NiMH
Princeton Tec cares about the environment and
recommends recycling batteries. For more information
about battery recycling, please go to:
www.batteryrecycling.com
To install the batteries, unlatch the battery door. Open
the Remix case by popping the door latch over the
catch and rotate the door open.
Install three AAA batteries according to the polarity
markings on the inside of the cabinet. Observe proper
battery polarity when installing the batteries. Improper
installation of the batteries will damage the light and
void the warranty.
Rotate the door to the closed position, squeeze the
body between your forefingers and thumb to snap the
door latch over the catch.
WARNING
• Never mix fresh and used batteries.
• Never mix different battery brands or
chemistry types.
• Always remove drained batteries immediately.
• Remove batteries during long periods of storage.
NOTE: Rechargeable NiCad or NiMH batteries
may result in reduced brightness due to lower
nominal voltage.
Switch Operation – See Switch Operation diagram
The Remix has two light sources to choose from, three
Ultrabright LEDs or a Maxbright LED. Each light source
has two modes (High and Low).
To switch between light sources, press and hold the
button down until the light source switches to the
desired source. As soon as it switches release the
button.
NOTE: If you keep the button pressed the light will
continue to switch back and forth between the 5mm
and Maxbright LED (on low light settings) until you
release the button.
Once you have found your desired light source, you
now can select different brightness levels. Your light
will start on “low output”. To change to “high output”
you must press the button again in less than 1.6
seconds from the previous press. Any additional
delay will cause the light to turn off after the next
button press.
One final note about the light function – If you have the
light turned on, (and more than 1.6 seconds has
passed since your last button press) and you press
and hold the button down to switch light sources, you
will be in darkness for about one second as the light
sees this press as a signal to turn the light off and
switch to the other light source simultaneously.
**The times listed on the rear of the package
assume you have start with fresh batteries and
use only one mode.
Troubleshooting
If the Remix fails to light:
• Check the batteries for proper installation.
• Replace batteries if proper installation is
confirmed.
• Check the light for water contamination on the
circuit board. The light will resume normal operation
once the water is shaken or blown out and the light is
left open until completely dry. If the light has been
contaminated with salt water, flush the unit with fresh
water and dry as described above.
USA– International 5-Year Warranty
WARRANTY – Princeton Tec warrants this product to
be free from defects in workmanship and materials
under normal use for as long as you own this product.
This warranty covers all of the component parts of the
product except batteries. This warranty does not cover
deterioration due to normal wear or damage due to
misuse, alteration, negligence, accidents, or
unauthorized repair. Princeton Tec will repair or replace
parts which are defective in workmanship or materials.
Your authorized Princeton Tec Dealer and Princeton
Tec are the only facilities authorized to repair the
product. After (3) unsuccessful attempts (within the
warranty period) to repair the product, you have the
right to elect replacement of the product or a refund of
the purchase price less allowance for use of the
product. NO INCIDENTAL OR CONSEQUENTIAL
DAMAGES ARE INCLUDED IN THIS WARRANTY.
(Some states do not allow the exclusion or limitation of
incidental or consequential damages, so the above
limitations or exclusions may not apply to you.) This
warranty gives you specific legal rights, and you may
also have other rights which vary from state to state.
Princeton Tec reserves the right to change product
specifications without notice.
Return Policy
If your light fails to operate, follow these simple steps:
1) Check batteries. Replace if necessary.
2) Contact Princeton Tec customer service at
800-257-9080 to request an RMA number to send your
light in for repair or replacement. No warranty repairs
will be accepted without an RMA number.
3) Return the light without batteries to: Princeton Tec,
5198 Rt. 130, Bordentown, NJ 08505. Postage due
and freight collect items will not be accepted.
Princeton Tec
PO Box 8057,
Trenton, NJ 08650
Phone: [phone]
Fax: [phone]
www.princetontec.com
© 2012 Princeton Tec
Figure 2 – Battery Replacement Remplacement des piles Einlegen der Batterien
press 1x = Low
press 2x = High
1 MAXBRIGHT
LED
DISTANCE (Meters) 10 38 53 73
LOW 53H
HIGH 28H
LOW 200H
HIGH 61H
DISTANCE (Meters) 10 23 28 53
To switch between light
sources, press and hold
button (1-2 seconds)
3
1 2
press 1x = Low
press 2x = High
3 ULTRABRIGHT
LEDs
