Specification Sheet

Distributed Exclusively by Ferguson and Wolseley Canada
© 2018 Ferguson Enterprises, Inc. 0318 773619
PF1500 Series
High-Efficiency Toilet
Warranty and Codes
This product comes complete with installation, operating, care and maintenance instructions. All PROFLO
fixtures carry a 1-year limited warranty. This product meets or exceeds ASME/ANSI A112.19.2M. In an effort
to continually improve our products, we will make design changes from time to time. We reserve the right to
ship newly designed product to fill any order unless we agree in writing to do otherwise.
C
Product Specification
The combination toilet shall be made of vitreous china. Toilet shall be 1.28 gpf
(4.8 lpf). Toilet shall have 2" (5.1cm) fully glazed trapway. Toilet shall include chrome
trip lever. Toilet shall be less seat and supply. Toilet shall be ADA compliant (PF1503)
with 17" high bowl.
RF RF CH EL ADA
PF1500/PF6112 PF1500CH/PF6112 PF1501/PF6112 PF1503/PF6112
A
30" 31-1/2" 30" 31-1/2"
B
16-1/2" 16-1/2" 18-1/2" 18-1/2"
C
15-1/2" 17" 15-1/2" 17"
D
27" 27" 29" 29-1/4"
E
10" 10" 9-7/8" 10"
F
20-5/8" 21" 21-3/8" 21"
G
8" 8" 8" 8"
H
12" 12" 12" 12"
PF1500/PF6110 PF1500CH/PF6110 PF1501/PF6110 PF1503/PF6110
D
26-1/4" 26" 27-7/8" 28-1/8"
G
6-3/4" 6-3/4" 6-3/4" 6-3/4”
H
10" 10" 10" 10"
PF1500/PF6114 PF1500CH/PF6114 PF1503/PF6114 PF1503/PF6114
D
29-7/8" 29-1/3" 31-3/8" 31-3/8"
G
10-1/4" 10-1/4" 10-1/4" 10-1/4"
H
14" 14" 14" 14"
Finished Wall
3/8
"
D
F
B
A
E
C
C/L Outlet
Finished Floor
H
C/L of Seat
Post Holes
G
17-3/8"
14-3/8"
Finished Wall
3/8
"
D
F
B
A
E
C
C/L Outlet
Finished Floor
H
C/L of Seat
Post Holes
G
17-3/8"
14-3/8"
Note: All dimensions and specifications are nominal and may vary: Dimensions of 8" and greater have
a tolerances of +3%. Dimensions less than 8" have a tolerances of +5%.
