Specification Sheet

Distributed Exclusively by Ferguson and Wolseley Canada
© 2016 Ferguson Enterprises, Inc. CAP Jab/2016
PF3001
Product Features
• Pressure balance valve with integral stops
• One-piece cartridge design for
ease of maintenance
• Ceramic disc valve cartridge
• Back-to-back capability
• Cast bronze valve body
• Optional air test cap available
• Adjustable temperature limit stop
Parts Available
ACF3001CRT Replacement cartridge assembly
ACF3001AIR Air test cap
ACF3001GRD Plaster guard
ACF3001EXTCP Deep rough extension kit CP
ACF3001EXTBN Deep rough extension kit BN
ACF3001EXTORB Deep rough extension kit ORB
PF3001
Product Specifications
5-7/8”
(149 mm)
1-7/8”
(44 mm)
3”
(76 mm)
1-7/8”
(44 mm)
4”
(100 mm)
2”
(51 mm)
7/8”
(23 mm)
4-1/4”
(108 mm)
A
Model Numbers
PF3001 Ceramic disc tub & shower valve
with stops 1/2” MIP &SWT
PF3001C Ceramic disc tub & shower valve with
stops CPVC connection
PF3001F Ceramic disc tub & shower valve
with stops FIP
PF3001P Ceramic disc tub & shower valve
with stops PEX crimp connector
Warranty and Codes
This product comes complete with installation, operating, care and maintenance instructions. This PROFLO faucet
carries a limited lifetime warranty when installed in residential applications. The warranty is five years in commercial
applications. This product meets ANSI: A112.18.1M and ASSE 1016-P
Rough-in depth
2” min.-3”max
Pressure Balance
Tub and Shower Valve with Stops
• 6.3 GPM flow rate at 60 psi
• IAPMO Approved
• Quick remove plaster guard
• Easy mounting brackets
• Meets or exceeds ASSE 1016-P standards
(anti-scald)
A (in) A (mm)
PF3001 5-1/2 139
PF3001C 8-1/8 206
PF3001F 5-1/8 130
PF3001P 5-1/4 134
