Exploded Parts

Distributed Exclusively by Ferguson and Wolseley Canada

Parts Breakdown

Two-Handle

Wall Mount Utility Faucet

PFXC800

LOW

LEAD

COMPL IANT

NSF61

Warranty and Codes

This product comes complete with installation, operating, care and maintenance instructions.

This PROFLO faucet carries a limited lifetime warranty when installed in residential applications.

The warranty is ﬁve years in commercial applications. This product meets ASME: A112.18.1-2011

*Compliant with lead content requirements of US Senate Bill S.3874

NO. Material

1 Faucet Body N/A Low-lead Brass

2 Seat LIN652121 Low-lead Brass

3 Packing LIN654238 Nylon

4 Stem - Cold LIN652228 Low-lead Brass

5 Stem - Hot LIN652229 Low-lead Brass

6 Handle - Cold LIN650380 Zinc

7 Handle - Hot LIN650368 Zinc

8 Screw N/A Brass

9 O-Ring N/A Rubber

10 Connector N/A Low-lead Brass

11 O-Ring N/A Rubber

12 Spout Nut N/A Brass

13 Spout N/A Low-lead Brass

14 NBR

15 POM

16 Stainless Steel

17 Brass

18 Union Nut N/A Brass

19 O-Ring N/A Ru

bber

20 Connector N/A Low-lead Brass

21 Washer LIN655232 Rubber

22 Swivel Union LIN653613 Low-lead Brass

23 Flange LIN653749 Zinc

Aerator Kit

Part & Code

N/A
