Installation Guide

77
Finish Plasters
Gold Bond Gauging Plaster, quick set
or slow set type, is designed for use
with finish lime. It is specially ground,
calcined gypsum, which readily mixes
with water and lime putty. Proper
proportioning is essential, since
gauging adds strength and hardness
to the finish surface by reinforcing
the plastic non-setting lime against
shrinkage and cracking. A finish coat
of gypsum gauging plaster and finish
lime, job mixed 2 parts hydrated
lime to 1 part plaster by weight, is
designed primarily for interior smooth
trowel application over a gypsum
For a mill-mixed finish plaster, use
Kal-Kote Smooth Finish, Kal-Kote
Texture Finish Plaster, Uni-Kal
Veneer Plaster or X-KALibur
Extended Set Veneer Plaster.
Requires the addition of water
only. See page 17.
Bag Weight
Quick Set:
50 lbs. (22.7 kg)
Slow Set: 50 lbs. (22.7 kg)
Bag Weight
50 lbs. (22.7 kg)
Mill-Mixed Finish Plasters
plaster basecoat. Smooth finish plas-
ters should be applied at a thickness
of not more than 1/16". Texture
finishes should be applied at a thick-
ness of not more than 1/8".
Specification Reference
Complies with ASTM Designation
C 28.
Gold Bond
®
brand
Gypsum Gauging Plaster (Super White)
Gold Bond Moulding Plaster is a very
white, finely ground gypsum, primar-
ily used for all kinds of ornamental
plaster work. Because of its low
expansion, excellent strength and
hardness, it is specially adaptable for
casting in rubber, gelatin and other
types of moulds. For casting pur-
poses, only water is added. For run-
in-place ornamental work, such as
cornices, the moulding plaster is used
with lime putty, mixed 2 parts lime to
1 part moulding plaster by weight.
Specification Reference
Complies with ASTM Designation
C 59.
Note: Application of plaster shall
be in accordance with ASTM C 842.
Gold Bond
®
brand
Gypsum Moulding Plaster (Super White)
Technical Data
GYPSUM GAUGING PLASTER
Method of Application Coverage*
Trowel Finish 1000-1400 sq. yds./Ton (921-1290 m
2
/Metric Ton)
113-158 sq. ft./Bag (10.5-15 m
2
/bag)
*Based on one part plaster to two parts hydrated lime.
Technical Data
GYPSUM MOULDING PLASTER
Method of Application Coverage*
Trowel Finish 1000-1400 sq. yds./Ton (921-1290 m
2
/Metric Ton)
113-158 sq. ft./Bag (10.5-15 m
2
/bag)
*Based on one part plaster to two parts hydrated lime.
*See page 17 for additional information.
MILL-MIXED FINISH PLASTERS*
Method of
Product Application Coverage*
Kal-Kote Smooth Finish Trowel 650-750 sq. yds./Ton
(598-645 m
2
/Metric Ton)
Kal-Kote Texture Finish Trowel 650-750 sq. yds./Ton
(598-645 m
2
/Metric Ton)
Uni-Kal and X-KALibur Trowel 600-665 sq. yds./Ton
(553-613 m
2
/Metric Ton)
PHYSICAL PROPERTIES OF BASECOAT PLASTERS (TYPICAL TEST RESULTS PER ASTM C 472)
Plaster Gypsolite Two-Way Hardwall to Two-Way Hardwall Two-Way Hardwall
Properties Regular Sand by Weight and Vermiculite and Perlite
Regular Masonry Regular Masonry
Mix Mill Mix 1:1 1:2 1:3 100 lbs. (45.4 kg) 100 lbs. (45.4 kg) 100 lbs. (45.4 kg) 100 lbs. (45.4 kg)
2 cu. ft. (.06 m
3
) 3 cu. ft. (.08 m
3
) 2 cu. ft. (.06 m
3
) 3 cu. ft. (.08 m
3
)
Approximate Compressive 900 1600 1150 750 500 300 900 650
Strength lbs. per sq. in. (kPa) (6201) (11024) (7923) (5168) (3445) (2067) (6201) (4479)
Approximate Tensile 160 250 190 120 130 90 160 100
Strength lbs. per sq. in. (kPa) (1102) (1722) (1309) (827) (896) (620) (1102) (689)
