(P8074-28) Specification Sheet

Patent# 5,758,990
Incandescent 6" Open Trim Recessed
IC & Non-IC
High Wattage
Type
-28
P8074
■■
Finish Dimensions (Inches)
Catalog No. White A B
P8074 -28 8-3/4 4-3/8
Rev. 9/08
Lamp Wattage
Housing IC Non-IC
P87-AT 90w PAR38/BR40 120w BR40/150w PAR38
P87-ATQC 90w PAR38/BR40 120w BR40/150w PAR38
P187-TG 90w PAR38/BR40 120w BR40/150w PAR38
P821-AT 120w BR40/150w PAR38 120w BR40/150w PAR38
P821-FB, FBFC N/A 150w R40/BR40/PAR38
Specifications:
Flange
• Bright white powder painted
integral metal flange
• No light leaks around trim flange
• Covers irregular ceiling openings
Trim
• Aluminum construction
• Socket mounts to trim for optimum
performance and consistent lamp
position
• Trim-Lok action forces trim to fit
snugly against the ceiling
• Splay design optimally accommodates
Par38 lamps
Labels
• UL-CUL damp location listed
• Rated IC and Non-IC
Photometrics
• Refer to PAR38 & BR40 Lamp
Application Data
A
B
Progress Lighting
701 Millennium Blvd.
Greenville, South Carolina
29607
www.progresslighting.com
