Photo Printer User Manual

18 COMPACT 2
TM
Operation
®
Lock Function
To prevent unintentional change of operation parameters the input can be locked.
If the input is locked any attempt to change the parameters will display an error “LO”
(locked).
Activating and de-activating of the input lock:
1. Press buttons 4 and 5 “Enter Memory” simultaneously to enter the memory
mode (see diagram on page 17).
2. Press several times the button 3 “Select” until the display will show “L.0”(Lock
off input unlocked) or “L.1” (Lock on: input locked).
3. Now by pressing one of the buttons 4 or 5 change the display: “L.0” if you
want to unlock the input or “L.1” if you want to lock the input.
4. To finalize the changes press button 6 “Exit”.
Please note:
Even when the input lock is activated it is possible to recall (previously stored)
procesing parameters of the memory-function.
Important: Please note, if input is locked via lock function, then processing param-
eters cannot be stored - when trying to do this, an error message “LO” will be dis-
played.
Stop Film Transport
In a case of a film-jam inside the machine, the film transportation can be manually
interrupted. To stop the film transport press both arrow-buttons (2 and 3) simulta-
neously.
Related topics:
“Manual starting and stopping the film transport” page 16
“Film is caught up in the racks” page 27
Infrared Sensitive Materials
Infra-red sensitive film material can be processed without danger of exposure by
the light-barrier.
Rollfilms and Paper Films
Automatic Cooling Function
If the developer temperature exceeds the set value, the automatic cooling function
will be activated. The fan runs for a fast cooling of the bath. The same happens
when the temperature is decreased by pressing the arrow button.
Roll films with a polyester lead of at least 10 cm length can be transported. The
adhesion must be chemical resistant.
Roll films without lead and paper-films must be folded on the corners, as shown
in the diagram, before being fed into the machine.
