This will allow the 1080P signal to pass. If your TV tuner does not support 1080P through the tuner
you will not receive any signal or video. If this happens, switch it back to “Interlacing.”
Depending on if you care about the low latency mode or not you can change the Vid Quality to
“HIGH.” A very slight change in image quality will happen as well as an increase in delay between
menus GUI’s due to the information handling sent to your TV. Please refer to Vid Quality settings in
the manual above for more information.
MY PICTURE LOOKS GREAT UNTIL THERE IS FAST MOTION
This could be an “interlacing,” issue with 1080i mode. This happens a lot with sports. Some TV’s don’t
like Interlacing trough the tuner causing “Ghosting.” Change your HDMI source to 1080P (progressive)
or 720P as well as on the unit 1080P Mode -> Advanced options -> 1080P Conversion -> Auto
This will allow the 1080P signal to pass. If your TV tuner does not support 1080P through the tuner
you will not receive any signal or video. If this happens, switch it back to “Interlacing,” and use 720P
Try changing the VID QUALITY settings as well to help with slower Tuners or if using QAM (J.83B)
switch your MOD from QAM64 to QAM256 if supported by your TV.
HOW DO I MIX MY UNIT WITH OTHER DIGITAL SIGNALS?
Please refer to the “MIXING SIGNALS WITH OTHERS,” in our manual above
MY VIDEO IS STRETCHED OUT ON THE TV
Our unit has a passive HDMI meaning it only encodes what the video is being sent to the unit. It does
not change the color or Aspect ratio of the video to your TV. Please check your HDMI source or TV
aspect Settings.
HOW DO I REPLACE AN OLD MODULATOR WITH THIS ONE?
Depending on how your old modulator was set up will determine how you will set your new unit up.
Please refer to your settings of the modulator you are replacing and copy the settings as best as
possible such as Frequencies, Channel Number, Name, etc. Please refer to the “CUSTOMIZATION
SETTINGS,” above.
I AM LOSING OTHER CHANNELS IN MY COAX NETWORK WHEN I TURN ON THE PVI UNIT
Check to ensure you are not broadcasting on the same frequency as other signals. Please refer to our,
“MIXING SIGNALS WITH OTHERS,” guide above. It could be that our unit is oversaturating the other
signals as well because of the strength of the signal. Try lowering the RF level under the “ADVANCED
MENU.” Using attenuators works as well or amplification of the other signal such as antenna signal
coming in before combining it in your coax network.
