DINB 13850 v.1.0 DINB 13,8V/5A DIN rail buffer power supply. EN** Edition: 2 from 26.01.2015 Supersedes the edition: 1 from 03.11.
www.pulsar.
www.pulsar.pl DINB13850 1.3 Description of components and power supply connectors (Table 1, Fig.2). Table 1. The components of power supply. Component No. [1] [2] [3] [4] Description L-N power connector 230V AC +OUT- DC power output +BAT- battery connector LED optical indication: AC – AC voltage indication DC – DC voltage indication BAT – battery charging indication Fig. 2. The view of the PSU module. 1.
www.pulsar.pl DINB13850 2.2 Installation procedure. 1. Before installation, make sure that the voltage in the 230V power-supply circuit is cut off. 2. Mount the power supply module on a DIN rail. 3. Connect the power cables to the L-N terminals of the PSU. 4. Connect the receiver cables to the + OUT connector - terminal block on the PSU module. 5. Switch on the 230V AC supply. 6. Connect the battery in accordance with the markings: +BAT red to 'plus', -BAT black to 'minus’. 7.
www.pulsar.pl DINB13850 WEEE MARK According to the EU WEE Directive – It is required not to dispose of electric or electronic waste as unsorted municipal waste and to collect such WEEE separately. The power supply unit is adapted for a sealed lead-acid battery (SLA). After the operation period it must not be disposed of but recycled according to the applicable law. THE GENERAL WARRANTY CONDITIONS 1.
