ROUPS12VR

v.1.0

ROUPS 12V/5A

RACK mounted buffer power supply of the recorder.

Edition: 2 from 30.03.2017

Supercedes the edition: 1 from 15.03.2016

Summary of content (8 pages)

PAGE 1
ROUPS12VR v.1.0 ROUPS 12V/5A RACK mounted buffer power supply of the recorder. EN Edition: 2 from 30.03.2017 Supercedes the edition: 1 from 15.03.
PAGE 2
www.pulsar.
PAGE 3
www.pulsar.pl ROUPS12VR RACK POWER CCTV CONTENTS: 1. Technical description. 1.1. General description 1.2. Block diagram 1.3. Description of PSU components and connectors 1.4. Specifications 2. Installation. 2.1. Requirements 2.2. Installation procedure 3. Operating status indication. 3.1. LED indication 3.2. Technical output 3.3. Acoustic indication 4. Operation and use. 4.1. Overload or short circuit of the PSU output 4.2. Battery-assisted operation 4.3. Maintenance 1. Technical description. 1.1.
PAGE 4
www.pulsar.
PAGE 5
www.pulsar.pl RACK POWER CCTV ROUPS12VR Electrical parameters (tab. 2).
PAGE 6
www.pulsar.pl ROUPS12VR RACK POWER CCTV 2. Installation. 2.1. Requirements. The PSU RACK shall be mounted by a qualified installer with appropriate permissions and qualifications for 230V/AC installations and low-voltage installations (required and necessary for a given country). The device shall be mounted in confined spaces, according to the environment class II, with normal air humidity (RH=90% max. without condensation) and the temperature from -10°C do +45°C.
PAGE 7
www.pulsar.pl ROUPS12VR RACK POWER CCTV RED LED:  ON – too high temperature of the switch mode power supply (>70°C)  OFF – standard temperature of the switch mode power supply RED LED:  on – battery voltage <11,5V  off – battery voltage >11,5V GREEN LED:  on – DC voltage in the DVR output  off – no DC voltage in the DVR output 3.2. Technical output. The power supply is fitted with the ALARM output of collective failure (relay type).
PAGE 8
www.pulsar.pl ROUPS12VR RACK POWER CCTV 4. Operation and use. 4.1. Overload or short circuit of the PSU output. The power supply outputs are protected against short circuit by melting fuse; in the case of fuse failure, it should be replaced with a fuse of the same type. 4.2. Battery-assisted operation. In case of a main power outage, the device is immediately switched into a battery-assisted operation. The PSU is equipped with the discharged battery disconnection system.
