RSUPS108 v.1.1 RSUPS108 10-ports switch with buffer power supply for 8 IP cameras, RACK mounted. EN Edition: 2 from 14.02.2019 Supercedes the edition: 1 from 23.03.
www.pulsar.pl RACK POWER RSUPS108 Features: Uninterruptible power supply of 8 IP cameras (52 V DC) Switch 10 ports: 8 PoE ports 10/100Mb/s, (1÷8 ports) (data transfer and power supply) 2 10/100Mb/s ports (UpLink) 30 W for each PoE port, supports devices complaint with the IEEE802.
www.pulsar.pl 1. RACK POWER RSUPS108 Technical description. 1.1. General description. The RSUPS108 is a complete solution for power supply and battery backup of 8 IP cameras (52 V DC power supply) in RACK 19" standard.
www.pulsar.pl RSUPS108 BUZZER, micro switch, turning ON / OFF of acoustic indication switch in the top position, indication ON switch in the down position, indication OFF PoE port 1÷8 for cameras IP connection (data + power supply) 2 x UP LINK port 230 V INPUT, power socket 230 V, power cable 1,5m included FMAINS, fuse in the supply circuit 230 V, T 3,15 A/250 V Fig. 2. The front power of the power supply unit. Fig. 3. The rear power of the power supply unit. Fig.4. The view of the PSU.
www.pulsar.pl RACK POWER RSUPS108 Fig.5. The view of the switch. Table 2. (See Fig. 5). Element no. [Fig. 4] Description LINK - yellow LED - indicating the LAN connection status PoE - green LED indicating voltage at the PoE port PWR - green LED indicating the supply voltage of the Switch PoE ports 1÷8 for cameras IP connection (data + power supply) 2 x UP LINK port 1.4. Specifications. - parameters of the switch (tab.3) - electrical parameters (tab.4) - mechanical parameters (tab.
www.pulsar.pl RACK POWER RSUPS108 Mechanical parameters (tab. 5).
www.pulsar.pl RSUPS108 RACK POWER As the PSU is designed for a continuous operation and is not equipped with a power-switch, therefore an appropriate overload protection shall be guaranteed in the power supply circuit. Moreover, the user shall be informed about the method of unplugging (usually through assigning an appropriate fuse in the fuse-box). The electrical system shall follow valid standards and regulations. 2.2. Installation procedure. 1.
www.pulsar.pl RSUPS108 RACK POWER 3.2. Optical indication of the switch operation: OPTICAL INDICATION OF THE SWITCH's POWER SUPPLY (1÷8) GREEN LED LIGHT (PoE) Indication of the PoE power supply at the RJ45 ports OFF- no power supply at the RJ45 port (the device is not connected or not compliant with the IEEE802.
www.pulsar.pl RSUPS108 RACK POWER 4. Operation and use. 4.1. Overload or short circuit of the PSU output. In case of overload, the output voltage is automatically shut off, and so is the LED indicator. The restoration of the voltage takes place immediately once the failure (overload) is over. 4.2. Battery-assisted operation. In case of a main power outage, the device is immediately switched into a battery-assisted operation. The PSU is equipped with the discharged battery disconnection system.
