Installation Manual

92500,92600

LIMITED 90 DAY WARRANTY

Putco guarantees it’s Stainless Steel and Aluminum products against defects in workmanship and material for as long as you

own your vehicle. All painted products have a 90 day warranty on the painted surface. Any defects resulting from faulty

material or workmanship will be warranted by Putco and repaired or replaced at our discretion. Putco assumes no extra labor

costs. Damages caused by freight carriers, improper installation, misuse, collision, or neglect will not be warranted by Putco.

9/14/2016-CPH

2015+ Ford F150 Ford Emblem Installation Instructions

Congratulations on your purchase of a high quality PUTCO product. Should you

need any application or technical assistance, feel free to call us at: 1-800-247-3974

Monday-Friday 8:00 a.m. - 5:00 p.m. (Central Standard Time)

Contact your PUTCO dealer for other quality accessories.

Please read all instructions before installation and to check to see that all parts are included.

KIT CONTENTS: 92500

Description

Qty.

Ford Emblem

Bolt Kit

KIT CONTENTS: 92600

Ford Emblem

Bolt Kit

Front Emblem Installation

1. Remove Emblem from packaging. Check to see if all parts from above table of kit contents are included.

2. With a flat-head screwdriver, remove(10)

retaining clips to remove plastic cover.

Keep clips and cover. (locations shown

above).

3. Remove and keep the top (4) grille screws

with 10mm wrench (location shown by

circles) and (2) plastic tree clips with

screwdriver (location shown by squares).

4. Pull out plastic cover around headlight.

Passenger side is shown. Repeat on driver

side.

5. On side of grille, use a flat-headed

screwdriver to pull out (total 6) tree clips that

hold on rubber shield. (keep clips)

Passenger side location is shown above.

Repeat on driver side

Tools Needed:

- 8mm & 10mm Wrench

- 7/16" Wrench

- 3/8” Socket and Ratchet

- Pliers

- Flat Head Screw Driver

PAGE 1
92500,92600 2015+ Ford F150 Ford Emblem Installation Instructions Congratulations on your purchase of a high quality PUTCO product. Should you need any application or technical assistance, feel free to call us at: 1-800-247-3974 Monday-Friday 8:00 a.m. - 5:00 p.m. (Central Standard Time) Contact your PUTCO dealer for other quality accessories. Please read all instructions before installation and to check to see that all parts are included. KIT CONTENTS: 92500 Description Qty.
PAGE 2
92500,92600 6. Remove and keep (total 2) 8mm bolts securing lower grille to truck. Passenger side location is shown above. Repeat on driver side 7. Unclip (2) electrical plugs on the top side of the factory grille. Locations shown above. 8. Remove factory grille assembly by pulling grille straight up and out. 9. Once factory grille assembly is removed from truck; remove the three 10mm nuts from the back of the emblem 10.
PAGE 3
92500,92600 Rear Emblem Installation 1. Lower tailgate and remove the eight T-30 screws from the access cover 2. Remove access cover 3. Through this area of the tailgate you can gain access to the back of the emblem 4. Pry on the highlighted clips while pulling out on the emblem from the outside 6. Install the emblem into the tailgate using the included washers and lock nuts. Be careful not to overtighten the fasteners and damage the tailgate 7.
