CLASSICAL USB TURNTABLE WITH CD, AM/FM RADIO, CASSETTE www.pyleaudio.
IMPORTANT SAFETY INSTRUCTIONS 1) Please read these instructions and keep them for future reference. 2) Pay attention to all warnings. 3) Follow all instructions. 4) Do not use this apparatus near water. 5) Clean only with a dry cloth. 6) Do not block any ventilation openings. 7) Install in accordance with the manufacturer's instructions. Do not install near any heat sources such as radiators, heaters, stoves, or other apparatus (including amplifiers) that produce heat.
IMPORTANT NOTES Avoid installing this unit in places exposed to direct sunlight or close to heat radiating appliances such as electric heaters, on top of other stereo equipment that radiates too much heat, places lacking ventilation or dusty areas, places subject to constant vibration and/or humid or moist areas. Do not attempt to clean this unit with chemical solvents as this might damage the finish. Use a clean dry cloth. Operate controls and switches as described in the manual.
To prevent any damage to your furniture we strongly recommend that you purchase small self-adhesive felt pads, available at hardware stores and home improvement centers everywhere, and apply these pads to the bottom of the rubber 'feet' before you place the product on fine wooden furniture. IMPORTANT: Raising and Lowering the Lid To open the lid, raise it as far as it will go until the lid support bracket locks in the open position.
PHONOGRAPH : 1) Turntable 2) 45 RPM Adapter 3) Transit Screw 4) Cue Lever 5) Speed Selector (33 / 45 / 78 RPM) 6) Tone arm Lock 7) Tone arm with Stylus REMOTE CONTROL OPERATION: R1.OPEN / CLOSE R2.RECORD R3.REPEAT R4.PLAY / PAUSE R5.DN/FB (SKIP REV) R6.DN/FF (SKIP Forward) R7.STOP R8.TRACK -10 R9. TRACK +10 R10.RANDOM R11.DELETE R12.PROGRAM NOTE: ALL of the buttons on the remote control have the same function as these buttons in the unit. This remote control just used for CD/MP3, USB mode.
NOTE: Level hold PLAY/PAUSE button to enter function change as follows: CD-USB When the CD function model has not put in CD/MP3 disc, inserts USB card, will automatic switching to USB card the playback. To confirm recording successful or not, select the CD function and level hold PLAY/PAUSE button to enter into USB function, insert USB card the unit will read the USB songs. CD/MP3 FUNCTION OPERATION: Select to the CD function. press the OPEN/CLOSE button to open the CD door and the unit LCD displays .
SELECTING YOUR DESIRED PART FOR CD/MP3/USB: Depress and hold SKIP FWD or SKIP REV button on the unit front panel or UP/FF or DN/FB button on the remote control to select your desired part of the currently playing track and then release the buttons. The playback will resume normal from that point. PAUSE CONTROL IN CD/MP3/USB MODEL: In CD/MP3/ USB playing mod: Press the PLAY/PAUSE button once.Play stops but the disc continues to spin and the LCD indicator of the track number will flashs.
PROGRAM FUNCTION IN CD/MP3/USB MODE: This feature allows you to program of the CD 20 tracks and MP3/USB 99 tracks on a disc for playback in any desired order. In CD/MP3/USB stop model: Press the PROGRAM button to enter the program mode. The program number briefly shows '0 0 1', and the program indicator lamp flash.
CASSETTE CARE Two common causes of trouble experienced when using cassettes are: 1) Tape jamming-Leading to uneven speed in playback. 2) Tape entangling- the tape wraps itself around vital parts of the mechanism. To reduce the likelihood of these problems occurring, the following precautions should be observed: Check that there are no loose layers of tape visible through the cassette centre window (see Fig. 1).
