Specification: * Natural Response Drum Head with 128 Level Force Velocities * 11 Pre-set Drum Kit with up to 4 Variations * Built-in Reverb Switch * Headphone Jack * Stereo Line-in for Portable MP3 Device *MIDI In/Out * Built-in Metronome * Fully Adjustable Drum Rack PED04 Include: 5 Drum Pads 2 Drum Sticks 1 Hi-Hat Pedal 1 Bass Pedal 1 User Manual 1 Drum Rack 1 Sound Module 1 100V~240V Auto Switch Power Adapter 7 Cables Drum Lock 1
Operation Warning Instruction for Prevention of Fire, Electric Shock, & Physical Injury About Warning & Caution Signs: WARNING This sign indicates the risk of serious physical injury and even death. Please operate the machine according to instructions. CAUTION This sign indicates the risk of serious physical injury and even death. Please operate the machine according to instructions.
Always follow the instructions as described below WARNING Please read the following instruction before operation. Do not open or, in any way, modify the machine or adapter. Do not attempt to repair the machine, or replace any internal parts by yourself, unless instructed to do so by the manual. In case of technical need, please contact with your retailer, or customer service, or any our recognized retailers printed on the information page.
For proper operation, make sure that the support stands are placed on flat and stable ground in order to support the machine safely and stably. Use only the included adapter. Make sure that the voltage of the socket matches the voltage indicated on your adapter to prevent damage or electric shock. Please do not over-twist or over-bend the power cable, or place any objects on it. Doing so may result in short-circuit that can lead to fire and electric shock.
WARNING Prevent letting any object like coins or pins, or any liquid slip inside the machine. Should any of the following situations result, please stop operation and remove the adapter from the socket, and consult with your retailer, the nearest customer service, or any of the recognized retailers listed on the information page: The adapter or the power cable is damaged. An object, or liquid has slipped into the interior of the machine. The machine has been exposed in rain, or has got wet.
When using the machine in other countries, please consult your retailer, the nearest customer service, or any of the recognized retailers listed on the information page. CAUTION Always place the machine and the adapter in areas with good airflow. When inserting or removing the power cable into/from the socket or the machine, always grab the plug instead of the cable.
CAUTION Do not place heavy objects on the machine. When moving the machine, or during insertion/removal of the plug, always use dry hands. Please remove all the connected cables first before moving the machine. Please turn off the power and remove the adapter from the socket before cleaning the machine. When there is a risk of lightning strike, please remove the adapter from the socket.
Precautions Please read the following precautions aside from the safety instructions printed on page 1 & 2” Power Supply Do not share the power supply with other electronics that can produce cable statics, for example, electric motors. It is normal for direct current (DC) to produce heat with extended usage, and there is no need to be worried. Before connecting the machine to other equipments, always turn off the power to prevent damage.
Additional Precautions During operation, please handle with care to prevent any damage. Do not hit or press against the display screen. Always grab the heads of cables during insertion/removal to prevent damage to the cables or the machine. To prevent disturbing your neighbors, please operate the machine at an acceptable volume, or use a headphone, especially at nights.
Please do not hit the pads with excessive force to prevent the risk of hurting your fingers.
Manual Summary Preface This manual includes all the operational knowledge and precautions. With the help of this manual, users are able to understand the software and hardware of this machine, and enjoy making use of it according to their needs. Cha pt er Sum mar y Hardware Introduction This section of the manual explains the basic operation of the machine. It introduces all the ports, power, sound output/input, MIDI, and volume controls with clear illustrations.
Contents 2 3 8 Warning & Caution Signs Warning Precautions Manual Guide 11 Hardware Introduction 11 Parts 11 Advance Learning 11 Contents 12 Introduction to Parts 14 Support stands 14 Connectors 14 Parts Accessories 15 15 Assembly Instructions 16 16 Support Stands Step 1 16 Step 2 17 Step 3 18 Step 4 19 Step 5 19 Step 6 20 Finished Diagram 20 21 Parts PAD 21 CRASH 22 CONTROL BOX 23 Finished Diagram 24 12
Accessories Introduction 26 Accessories Illustration 26 Accessories Assembly Diagram & Instructions 27 Console Control 28 Console Control Illustration 28 Console Control Diagram & Instructions 29 Console Operation 30 30 Drum & Percussion Sound Patches Style 30 Patch 31 Reverb 31 Sounds & Tones 32 33 Metronome On/Off 33 Rhythmic Style 33 Tempo 34 13
Parts Please make sure that you have all the necessary parts before assembly Support Stands A3 A1 22.5x800 (mm) main support bar x 5 12.7x400 (mm) locking bar x 5 A2 22.
Parts Floor pad x 4 Nuts x 42 Y1 U-shape plate x 1 Spare(2) Spare(2) Y2 Y4 Y3 Screws x 2 22.
Assembly Instructions Y2 NOTE Y3 Y4 B2 B1 Y7 Please insert the bolts and nuts to connectors before assembly. B3 Support Stands Step 1 Assemble the floor pads onto either side of the two floor bars with double T-shape locks, and place the bars parallel to each other, with a distance equal to the length of the main support bar. Adjust the facing direction of the T-shape locks as according to the diagram.
B2 Step 2 B1 B2 A1 Assemble the T-shape connectors and connector A(s) onto the main support bars. The main support bar on the left should have two T-shape connectors and two connector A(s) as according to the illustration on the left. These two connector A(s) are for Hi-Hat and Snare. B1 B1 The main support bar on the right should have two T-shape connectors. A1 B1 2~15cm 5~15cm 15~20cm NOTE 17 Adjust the heights of all four T-shape connectors so that they match on either main support bar.
Step 3 Insert the assembled main support bars (from Step 2) into the T-shape locks on the assembled floor bars (from Step 1). Adjust as necessary to make sure that the main support bars are perpendicular to the floor bars. NOTE With the chair that you will be using, you should sit on the chair and adjust the heights of the T-shape connectors according to your chest and knee heights.
B2 NOTE BACK Step 4 B2 B2 4CM 8CM 5CM A1 T he remai n ing th r ee main sup p ort bars a re for conn e ct i on bet we en the 4 Tsha p e c o nne c tors o n the m a i n s u p port bars a nd t he 2 T-shape lo c ks o n t h e floor bars, with the upp e r on e a s se m b led with 3 con n ector A(s ). These 3 c o nne c tor A(s) wi l l be u sed f or th re e Pa ds. Plea s e ch ec k t he d irec t ion t o w h i c h NOTE t he 4 c on ne c t or A(s ) a r e f astcinratge. dTh.
Step 6 Insert the long and short locking bars, and stoppers as illustrated to complete the support structure. Finished Diagram of Support Structure 22.
Accessories PAD HI-HAT SNARE Z1 Assemble the Pads (Hi-Hat Snare and Tom 3) and connector B(s) as illustrated. B3 TOM1 Z1 TOM2 Tilt the Tom 1 and Tom 2 for smoother playing. B3 Z1 NOTE When assembling the Pads and connector B(s), match the depressed side of connector B(s) with the protruding side of Pads. Depression B3 NOTE Below are examples of wrong assembly.
Assemble the pads (Snare, Hi-Hat, Tom 1,& Tom 2) and the Crash onto the support structure.
Control Box Z3 Y5 Following the illustration, attach the U-shape plate onto the back of the control box. Position the box onto the second main support bar (labeled as A on the previous page), and fold the U-shape plate upwards around the bar. Y6 Tighten the screws for the Ushape plate to a suitable tightness.
Finished Diagram HI-HAT TOM1 CRASH TOM2 Position the pedals as illustrated to complete the setup. SNARE H.H CTRL Position the Hi-Hat Pedal below the HiHat. Z4 BASS Position the Bass/Kick Pedal in the middle below the set.
Mono sound cable Z7 For Pad and Pedal must to use the NOTE mono sound cable(Black). Crash Pad Stereo sound cable ( BLUE ) Z6 NOTE For Crash must to use the stereo sound cable(Blue).
Accessories Introduction H.H CTRL HI-HAT SNARE CRASH BASS TOM1 TOM2 Using the diagram on the previous page and the one on this page as a guide, connect the cables to the Control Box. For Crash, use the stereo sound cable (two parallel black lines at the tip) for connection, NOTE as illustrated by .
Hi-Hat Snare High Tom Middle Tom Crash Pad Hi-Hat Pedal Bass/Kick Pedal Hi-Hat Pad (Labeled as ) and Hi-Hat Pedal (Labeled as ) correspond to each other as open and close Hi-Hat, simulating realistic Hi-Hat playing.
Console Control Introduction MIDI About MIDI MIDI (Musical Instrument Digital Interface) is an industry-standard protocol that enables electronic musical instruments, computers, and other equipment to communicate, control, and synchronize with each other. MIDI allows computers, synthesizers, MIDI controllers, sound cards, samplers and drum machines to control one another, and to exchange system data.
DC IN For connection of the adapter. POWER Switch power on/off. NOTE MIDI IN To prevent damage to speakers, always turn down the volume before inserting or removing sound cables. MIDI OUT For transmitting MIDI data. VOLUME For adjusting the volume. PHONE For connection of a headphone. LINE OUT R LINE OUT L For connection of speakers or amplifiers. LINE IN For connection of a sound input source like a CD player, MD player, or Mp3 player. The sound is directed to both Phone and Line Out.
Console Operation Percussion Sound Module &Metronome Drum Voice List PERCUSSION SOUND MODULE STYLE Available Styles: ROCK JAZZ METAL BLUES POWER TECHO MARCH LATIN TIMBALE FUSION 30
With different style of music selected, users may select different percussion sounds. P. S . S o u n d s e l e c t i o n c a n b e o p e r a t e d a s i l l u s t r a t e d b e l o w. PATCH After choosing the style, this button allows users to choose different sounds. REVERB ON/OFF This button can be used to turn reverb on/off .
Styles & Sounds List 32
METRONOME CHICK ON/OFF This button allows users to switch the metronome on/off. BEAT After turning on the metronome, these two buttons can be used to change the beat of the metronome.
TEMPO These two buttons are be used to adjust the tempo of the metronome. The metronome is ideal to help users develop stable rhythm sense, and for practicing.
