PWMA68 Sing Along Portable Karaoke Radio and PA Speaker System Compact Headset Microphone Amplifier, Digital Lyrics Display
FUNCTION • [Digital song] input numbers to select songs, supports 1-9999 preferred song. • [MP3 player] direct Micro SD Memory Card broadcast and U disk MP3 files, supports MP3, WMA, WAV music formats. • [Digital recording] built-in microphone, recording function. • [Lyrics] support the display of song lyrics, synchronized display playback. • [FM Radio] FM digital stereo radio, clock radios, radio broadcast memory, you can store 40 radio stations.
11. [ ]: Next song, press and hold to fast forward. 12. [M]: Short press to confirm function, press to return to the main menu. 13. [FM]: Short press to enter FM/play/pause, press and hold to search radio stations and save 14. [REC]: Press when entering the record, press enter to save and play back recording, playback recording press Delete Record 15. [1234567890]: Enter the selected song numbers, select the radio station, select the frequency.
Press the "M" key to enter the card catalog or USB directory as shown below: • Songs stored in "Removable Disk" root directory • Songs stored in "Removable Disk" root directory • "Removable Disk" root of the file list • New "folder" to store songs • New "folder" to store songs • Root • No Doubt • Sublime • The Specials • Monkey Man • Ghost Town • Songs stored in "Removable Disk" root directory • Songs stored in "Removable Disk" root directory • Press the "next track" button to select "New Folder", press "
MUSIC MODE SETTINGS In music mode, press M key to enter the setup menu, following figure: Cycle Mode • Cycle mode • EQ settings • Repeat mode • Lyrics (open) • Return to main screen • Exit EQ SETTINGS Natural, rock, pop, soft, jazz, heavy bass and other sound options. Repeat mode A-B Repeat 1. While playback, press M key to enter the play sub-menu button to select "Repeat Mode" menu, press the M key to enter the "repeat mode." 2.
Lyrics (open) Playing the "open" lyrics, select "Off" to play music without the lyrics, display playback time. RECORDING The machine does not contain storage memory chips, recording, external Micro SD or insert U disk recording device to store files, if the external memory storage device is not inserted, the machine will be prompted to "disk error", please insert the external storage memory device further recording.
FM RADIO SUB-MENU FUNCTION DESCRIPTION • Select Save station: save current station; • Select radio recording: save current station being broadcast content; (need to insert Micro SD card to store audio files) • Select Delete radio: Delete the current radio station; • Select Delete All: delete all stored station; • Select automatic station search: effective automatic search for radio stations in the band; • Select Normal frequency channel: namely 87.5 ~ 108.0MHZ; • Select campus frequency channel: the 76.
ALARM SETTINGS Enter the "System Settings" option, following figure: Select "Tools" option, press "M" key to enter the "Tools", view as above picture Press the "M" key hit (open) alarm clock, then select "Time" item to set the alarm time. TIME FM SETTINGS (CLOCK RADIO) Press the icon to open the time FM radio function, first set the "regular FM (open)", then set the "FM Time", the last set, "radio frequency", for example: 7:00 am tomorrow, I want to listen to 30 minutes F93.
The AUX audio input interface, the distribution of the "audio signal line" end into the machine "AUX" jack and the other end into the computer's "Ω symbol" audio output jack, and computer speaker function. CHARGING Insert distribution of 9V1A charger to DC 9V jack of machine's for charging, the battery icon will not flashing as full charge on. It can use too long connected by charger as machine built overcharge protection circuit.
FEATURES: • 3-in-1: Karaoke Speaker + Radio + Music Streaming • Fun for Performers of All Ages! • Use it Like a Megaphone & Project Your Voice • Lightweight, Compact & Handheld Design • Lyrics (Text) Display Ability to Sing Along • FM Radio and Clock with Digital LCD Display • Built-in Rechargeable Battery • Headset Microphone Included • Aux (3.
WHAT'S IN THE BOX: • Headset Microphone • Remote Control • 9V Power Adapter Cable • Convenient Carry Strap TECHNICAL SPECS: • Output Power: 10 Watt • Lyric (Text) File-Type Compatibility: .LRC • *Download Your Own Lyric Files • Full Battery Provides up to 6 Hours Operation • Loudspeaker Driver: 3'' • Impedance: 4 Ohm • S/N Ratio: >80dB • Power Supply: 110/220V • Digital Audio File Support: MP3, WMA, WAV • MAX Flash Memory Support: 32GB • Size: 5.5'' x 4.7'' x 5.2'' www.PyleUSA.
Questions? Issues? We are here to help! Phone: (1) 718-535-1800 Email: support@pyleusa.
