Item Brochure

All safety eyewear meets ANSI Z87.1+ standards (
•
) and provide 99% protection
from harmful UV rays. All lenses are hard coated polycarbonate scratch-resistant
unless otherwise noted. Some options meet European (EN166) (
•
), Canadian (CSA
Z94.3) (
•
), Australian (AS/NZS 1337) (
•
) or Ballistic (MIL-PRF-32432) (
•
) standards.
For specic lens options visit our website or contact your sales representative.(P) 800.736.8673 | (F) 901.861.4967
Part No. Gray Body with Quick Release Strap
GG504T
••••
AF
Clear H2X
GG504TM
•••
AF
Clear H2MAX
Part No. Chemical Green Body with Neoprene Strap
GC504TN
••
AF
Clear H2X
Fits over prescription glasses
Soft vinyl goggle body conforms to facial contours
Goggle provides protection against dust and chemical splash
Removable vent caps allow the user to remove when more ventilation is
required or leave in place for unsurpassed chemical splash resistance
GG504T and GG504TM passes D3: Droplet and Splash Test – provides
protection from droplets and splashes
Passes Ballistic MIL-PRF-32432 High Velocity Impact standards
Capstone 500 Series
BALLISTICASCSACEANSI
General Specications
Weight: 92 gm
PD: 68 mm
Bridge: 45 mm
Lens base: 5.5 curve
Lens size diagonal: 154 mm
Lens size vertical: 78 mm
Lens thickness: 2.3 mm
Overall length (lens - tip): 91 mm
Overall width (hinge - hinge): 180 mm
Strap length: 540 mm
Materials
Lens: polycarbonate
Body: polycarbonate & polyvinyl
chloride (PVC)
Headband: textile elastic
Nosepiece: polyvinyl chloride (PVC)
Lens Marking Symbols
P: Manufacturer’s mark
Z87: ANSI standard for eye and face protection devices
+: High impact
UV Filter Transmittance
U6: .01% max eective far UV • .1% max near UV
Frame Marking Symbols
P: Manufacturer’s mark
Z87: ANSI standard for eye and face protection devices
+: High impact
D3: Droplet & Splash Test with strap
c SEI CAN/CSA Z94.3-15: CAN/CSA standard for eye and face protection devices
Part No. Lens Markings Frame Markings
GG504T
P Z87 + U6 P Z87 + D3 / P c SEI CAN/CSA Z94.3-15
GG504TM
P Z87 + U6 P Z87 + D3 / P c SEI CAN/CSA Z94.3-15
GC504TN P Z87 + U6 P Z87 +
vimeo.com/pyramex/h2max
H2MAX
ANTI-FOG
