B – Command Line Interface
Show Command
B-68 59042-06 A
0
The following is an example of the Show Topology command for port 1:
SANbox2 #> show topology 1
Local Link Information
----------------------
PortNumber 1
PortID 650100
PortWWN 20:01:00:c0:dd:00:91:11
PortType F
Remote Link Information
-----------------------
Device 0
NodeWWN 50:80:02:00:00:06:d5:38
PortType NL
Description (NULL)
IPAddress 0.0.0.0
Device 1
NodeWWN 20:00:00:20:37:2b:08:c9
PortType NL
Description (NULL)
IPAddress 0.0.0.0
Device 2
Description (NULL)
IPAddress 0.0.0.0
Device 3
NodeWWN 20:00:00:20:37:2b:05:c9
PortType NL
Description (NULL)
IPAddress 0.0.0.0
