2 – General Description
Power Supply and Fan
59042-06 A 2-9
0
2.5
Power Supply and Fan
The power supply converts standard 110 or 230 VAC to DC voltages for the
various switch circuits. An internal fan provides cooling. Air flow can be
front-to-back or back-to-front depending on the switch model. To energize the
switch, plug the power cord into the switch AC receptacle and into a 110 or 230
VAC power source.
2.6
Switch Management
The switch supports the following management tools:
SANsurfer Switch Manager
SANsurfer Switch Manager web applet
SANsurfer Switch Manager Application Programming Interface (API)
Command line interface (CLI)
Simple Network Management Protocol (SNMP)
File Transfer Protocol (FTP)
2.6.1
SANsurfer Switch Manager
SANsurfer Switch Manager is a workstation-based Java® application that
provides a graphical user interface for fabric management. This includes
SANsurfer Performance Viewer which graphs port performance. SANsurfer
Switch Manager can run on a Windows, Solaris, or Linux workstation. A
management workstation connects to the fabric through the Ethernet port of one
or more switches and can provide in-band management for all other switches in
the fabric. Refer to the SANbox2-8c/16 Switch Management User’s Guide for
information about the SANsurfer Switch Manager application and its use.
Note: The power supply and fan are not field replaceable units.
