A – Specifications
Maintainability
A-2 59042-06 A
0
A.2
Maintainability
Buffer Credits.................................. 12 buffer credits per port
Media Type ..................................... Small Form Pluggable (SFP) optical
transceivers. Hot swappable. 3.3 Volts.
Fabric Port Speed........................... 1.0625 or 2.125-Gbps
Maximum Frame Size..................... 2148 bytes (2112 byte payload)
System Processor........................... 266 MHz Geode® processor
Fabric Latency (best case) ............. <0.4 µsec.
Fabric Point-to-Point Bandwidth ..... 1.0625 or 2.125-Gbps, full duplex
Fabric Aggregate Bandwidth .......... 16 Gb/s for a single switch
Diagnostics ..................................... Power On Self Test (POST) tests all
functional components except SFP
transceivers. Port tests include online,
internal, and external tests.
User Interface ................................. LED indicators
