Use and Care Manual

15
Item Button Function
1 POWER
Soft power down switch. Use this before un-
plugging the NVR
2 REC Begin recording
3 Numbers Input numbers in fields or select camera
4 Fn1 Not functional at this time
5
Multi-
Screen
Choose multi-screen display mode
6 Next Switch to next live view group
7 SEQ Switch to sequential channel display
8 Audio Enables Audio in Live View Mode
9 Spot Change video display mode
10 Enter Confirms choice
11
Directional
Controls
Move cursor
Control PTZ direction in PTZ mode
12 Menu Open Main menu
13 Exit Exits menu or interface
14
PTZ
Controls
Controls PTZ camera including zoom, focus, iris
and speed
15 Preset Opens PTZ preset settings
16 Cruise Opens PTZ cruise settings
17 Light Turns on PTZ cameras light
18 Wiper Turns on PTZ camera wiper
19 Track Opens PTZ track settings
20 Clear Returns to previous menu/ interface
21 Info Opens NVR Info menu
22 Fn2 Not functional at this time
23
Playback
Controls
Play/Pause, Stop, Fast Forward, Rewind, Single
Frame Forward/Backward
24 Search Opens up video search window
25 Snap
Takes still image snapshot of active live view
window
26 Backup Opens Backup menu
27 Cut
Select start/end points to create a shorter video
segment from a video being played back.
28 PiP Picture-in-Picture mode
29 Zoom Activates digital zoom
Press the PTZ button to enter the PTZ control panel. Choose a channel and then press the
PTZ button to close the panel. Wiper and light functions only function if PTZ camera is so
equipped.
