According to practical application, you can set the radio works as
Amateur Transceiver mode or Professional Transceiver mode. There
are also 2 levels operation menu to set functions as you need. It is easy
and convenient (From No.1 to No.15 are channel function setup, From
No.15 to No.29 are general setting setup).
:RUNLQJ0RGH
1.
%\SURJUDPPLQJVRIWZDUHA. In PC software's "General Setting"
menu, choose "Display Mode" to select Amateur Transceiver
mode or Professional Transceiver mode.
By manual setupB. : Please refer to "Display Mode" in Page 25.
$PDWHXU7UDQVFHLYHU0RGH
2.
Except setting as "CH" mode, others
considered as Amateur transceiver mode. Under this mode, press
key to switch between Channel mode and VFO mode .
3URIHVVLRQDO7UDQVFHLYHU0RGH
3.
When
set display mode as "CH", it enters
into Professional Transceiver mode.At
this mode, except scan, other shortcut
operation can't operate. And from No.1-
17 menu in function setting will be
auto-hidden, they should be set by PC
software.If there is corresponding name
for current channel, the LCD will display
current channel name Otherwise, it
shows current channel number. (As pic 4) (As pic 5)
Under every mode, from No.18-29 menu in
4.
general setting can be
changed and saved.
9)20RGH)UHTXHQF\PRGHC. :
This mode shows only frequency on
the display. Shortcut operation and
Channel setting will be changed &
stored as the latest value permanently.
Once the radio is turned off or
changed to new VFO frequency, the latest setting is remained
If transceiver programmed as professional transceiver mode and
locked, you can't return to amateur transceiver mode by manual
operation from general setting.
(Pic 4)
(Pic 5)
)UHTXHQF\&KDQQHOPRGHA. : When set display as "FR", it
enters into Frequency+Channel
mode, new setting of channel
operation and shortcut operation can
be temporarily used by user. Once
the radio is turned off or switched
to another channel, the temporary
&KDQQHO1DPH7DJ0RGHB. : When set display as "NM", it enters
into Channel+Name Tag mode. At this mode, it will display
corresponding channel name when
the current channel is edited with
name. Otherwise, it will display
frequency+channel. Its operations
are the same as frequency + channel
WORKING MODE (AMATEUR TRANSCEIVER OR PROFESSIONAL TRANSCEIVER)
setting will be erased and back to initial settings.
mode.
until next change.(
