User's Manual

5
2
Microphone connector
http://www.qxdz.cn
POW
SQ
L
Initial Installation
Microphone
F
or voice communications, connect a microphone equipped with an
8-pin modular plug into the modular socket on the front of the main
unit. Press rmly on the plug until the locking tab clicks. Attach the
supplied microphone hanger in an appropriate location using the
screws included in the screw set.
PC Connecting
T
o utilize the optional QPS-888 software, you must rst connect the
transceiver to your PC then using an optional programming cable
PC50 .
Please use QPS-888 software for programming.
Ask your dealer about purchasing a Programming Cable PC50.
