1 Introduction This manual describes the features and installation of the QLogic SANbox 6142 Intelligent Storage Router (iSR-6142), also referred to as the SANbox 6142 router or simply router. Intended Audience This guide is for users who are responsible for installing, managing, and servicing the SANbox 6142 router and the storage area network (SAN) equipment to which it is attached. Related Materials Internet Protocol, Version 6 (IPv6) Specification., RFC2460.
S 1 – Introduction Safety SCSI-3 Fibre Channel Protocol (SCSI-FCP), X3.269:1996 Fibre Channel Physical and Signaling Interface (FC-PH), X3.230:199 Fibre Channel 2nd Generation (FC-PH-2), X3.297:1997 Third Generation Fibre Channel Physical and Signaling Interface (FC-PH-3), X3.303:1998, Fibre Channel-Arbitrated Loop (FC-AL-2), working draft, revision 6.
A 1 – Introduction Communications Statements Federal Communications Commission (FCC) Class A Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
S 1 – Introduction Communications Statements CE Statement The CE symbol on the equipment indicates that this system complies with the EMC (Electromagnetic Compatibility) directive of the European Community (89/336/EEC) and to the Low Voltage (Safety) Directive (73/23/EEC). Such marking indicates that this system meets or exceeds the following technical standards: 1-4 EN60950-1, A11:2004 – “Safety of Information Technology Equipment, Including Electrical Business Equipment”.
A 1 – Introduction Laser Safety Information VCCI Class A Statement This is a Class A product based on the standard of the Voluntary Control Council For Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance may arise. When such trouble occurs, the user may be required to take corrective actions. Laser Safety Information This product may use Class 1 laser optical transceivers to communicate over the fiber optic conductors. The U.S.
S 1 – Introduction Accessible Parts Accessible Parts The following field replaceable units (FRUs) are supported by the SANbox 6142 router: Small form-factor pluggable (SFP) optical transceivers License Agreements Refer to the QLogic Software End User License Agreement for a complete listing of all license agreements affecting this product. General Public License QLogic SANbox routers are powered by the Linux operating system.
A 1 – Introduction General Public License When we speak of free software, we are referring to freedom, not price. Our General Public Licenses are designed to make sure that you have the freedom to distribute copies of free software (and charge for this service if you wish), that you receive source code or can get it if you want it, that you can change the software or use pieces of it in new programs, and that you know you can do these things.
1 – Introduction General Public License S translation is included without limitation in the term "modification".) Each licensee is addressed as "you". Activities other than copying, distribution and modification are not covered by this License – they are outside its scope. The act of running the Program is not restricted, and the output from the Program is covered only if tis contents constitute a work based on the Program (independent of having been made by running the Program).
A 1 – Introduction General Public License Thus, it is not the intent of this section to claim rights or contest your rights to work written entirely by you; rather, the intent is to exercise the right to control the distribution of derivative or collective works based on the Program.
1 – Introduction General Public License S 5. You may not copy, modify, sublicense, or distribute the Program except as expressly provided under this License. Any attempt otherwise to copy, modify, sublicense or distribute the Program is void, and will automatically terminate your rights under this License. However, parties who have received copies, or rights, from you under this License will not have their licenses terminated so long as such parties remain in full compliance. 6.
A 1 – Introduction General Public License This section is intended to make thoroughly clear what is believed to be a consequence of the rest of this License. 9.
1 – Introduction General Public License S ANY GENERAL, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF USE OR INABILITY TO USE THE PROGRAM (INCLUDING BUT NOT LIMITED TO LOSS OF DATA OR DATA BEING RENDERED INACCURATE OR LOSSES SUSTAINED BY YOU OR ANY OTHER PROGRAMS), EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
A 1 – Introduction General Public License How to Apply These Terms to Your New Programs If you develop a new program, and you want it to be of the greatest possible use to the public, the best way to achieve this is to make it free software which everyone can redistribute and change under these terms. To do so, attach the following notices to the program.
S 1 – Introduction Technical Support This General Public License does not permit incorporating your program into proprietary programs. If your program is a subroutine library, you may consider it more useful to permit linking proprietary applications with the library. If this is what you want to do, use the GNU Library General Public License instead of this License. Technical Support Customers should contact their authorized maintenance provider for technical support of their QLogic switch products.
A 1 – Introduction Technical Support North American Region Email support@qlogic.com Phone +1-952-932-4040 Fax +1 952-974-4910 Europe, Middle East, and Africa Region Email emeasupport@qlogic.com Phone Numbers by Language +353 1 6924960 +353 1 6924961 +353 1 6924962 +353 1 6924963 +353 1 6924964 +353 1 6924965 - English - Français - Deutsch - Español - Português - Italiano Asia Pacific Region Email apacsupport@qlogic.
1 – Introduction Technical Support 1-16 S FI0054601-00 C
2 General Description This section describes the following features and capabilities of the SANbox 6142 router: Router Capabilities (see page 2-2) Licensed Features (see page 2-2) Remote SAN Island Connectivity (see page 2-4) Local SAN Island Connectivity (see page 2-6) FCIP - Fibre Channel over IP (see page 2-6) Chassis LEDs (see page 2-7) Chassis Controls (see page 2-8) Fibre Channel Ports (see page 2-10) Fibre Channel SFP Transceivers (see page 2-11) iSCSI/Gigabit
S 2 – General Description Router Capabilities Router Capabilities The SANbox 6142 is a bi-directional FC-to-iSCSI router.
A 2 – General Description Licensed Features Provides failover and failback between two gigabit ethernet links. Allows data compression. This is very useful when data round-trip latencies between two routers exceed more than 50 ms or long distance link rate is equal or less than 4500 Mbits/sec (DS-3 line rate) SmartWrite is an optional feature which requires the purchase of a license key.
S 2 – General Description Remote SAN Island Connectivity Remote SAN Island Connectivity The SANbox 6142 Intelligent Router supports inter-connecting remote SAN islands (see Figure 2-2). Figure 2-2 Remote SAN Island Connectivity This configuration has the following additional requirements: At least one FC Port of SANbox 6142 connected to FC SAN.
A 2 – General Description Remote SAN Island Connectivity To map remote FC devices to local SAN: 1. If the remote router is not already associated with a local router, use either the SANsurfer Add Remote Router wizard (see page 7-68) or the CLI command remotepeer add (see page A-32) to associate the two routers with each other. 2. Use the SANsurfer Map Remote Initiator/Target wizard (see page 7-75) or the CLI remotemap add command (see page A-28) to create the initiator to target mapping.
2 – General Description Local SAN Island Connectivity S Local SAN Island Connectivity You can use either the SANsurfer Map Local Initiator/Target wizard (see page 7-55) or the CLI localmap add command (see page A-20) to map any of the following connections: iSCSI Server to an FC Device (Target) FC server to an iSCSI Device (Target) FC Server from one SAN to FC target on another SAN CAUTION! When adding multiple routers in the same physical SAN, you must import a given FC device from a remote S
A 2 – General Description Chassis LEDs Chassis LEDs The chassis LEDs shown in Figure 2-4 provide information about the router’s operational status. These LEDs include the input power LED, heartbeat LED, and the system fault LED. To apply power to the router, plug the power cord into the router AC power receptacle and into a 100 VAC to 240 VAC, 50 Hz to 60 Hz power source. Figure 2-4 Chassis LEDs Heartbeat LED (Green) The heartbeat LED blinks once a second as long the the router firmware is operational.
S 2 – General Description Chassis Controls Chassis Controls The maintenance button shown in Figure 2-5 is the only chassis control. Pressing this button resets the router or recovers the router if it has become disabled. Figure 2-5 Chassis Controls Maintenance Button The maintenance button is a multifunction momentary switch on the front panel.
A 2 – General Description Chassis Controls Reset and Select Boot Image You can reset the router using either the primary or secondary boot image: Primary Image – To reset the router and select the primary boot image, use a pointed, nonmetallic tool to press and hold the maintenance button until the heartbeat LED flashes once, then release the button. The router will boot from the primary boot image. The boot time is less than one minute.
S 2 – General Description Fibre Channel Ports Erases all presentations. Erases all discovered initiators and targets. Fibre Channel Ports The SANbox 6142 router has two Fibre Channel ports, labeled FC1 and FC2, as shown in page 2-10. Figure 2-6 Fibre Channel LEDs Each port is served by a small form-factor pluggable (SFP) optical transceiver and is capable of 1-Gbps or 2-Gbps transmission. SFPs are hot-pluggable.
A 2 – General Description Fibre Channel SFP Transceivers Table 2-2.
2 – General Description iSCSI/Gigabit Ethernet Port LEDs S iSCSI/Gigabit Ethernet Port LEDs The iSCSI/gigabit Ethernet ports shown in Figure 2-7 are RJ-45 connectors that provide connection to an Ethernet SAN through a 10/100/1000 Base-T Ethernet cable. The ports are labeled GE1 and GE2. These ports have two LEDs – the link status LED (green) and the activity LED (also green). The link status LED lights up continuously after the router establishes an Ethernet connection.
A 2 – General Description Serial Port Serial Port The SANbox 6142 router is equipped with an RS-232 serial port for maintenance purposes. Figure 2-9 shows the serial port location. It is labeled IOIOI. You can manage the router through the serial port using the CLI. Figure 2-9 Serial Port The serial port connection requires a standard, eight-wire Ethernet cable and the RJ45-to-DB9F adapter (supplied) to convert the Ethernet RJ45 connector to a female DB9 connector.
S 2 – General Description Serial Port Table 2-4.
3 Planning This section describes how to plan for using the SANbox 6142 router.
S 3 – Planning Device Access Device Access Consider device access needs within the FC and iSCSI SANs. Access to an FC device is controlled by mapping FC device to specific iSCSI initiators. FC devices may be mapped to more than one initiator. Giving multiple initiators access to an FC device requires access management. Fibre Channel The Fibre Channel ports automatically discover all FC target devices, whether connected directly (loop) or by fabric (switch).
A 3 – Planning iSCSI/Gigabit Ethernet Performance Bandwidth Bandwidth measures the amount of data transmitted over a channel or network. A 1-Gbps/2-Gbps FC port can transmit or receive at nominal rates of 1- or 2-Gbps, depending on the device to which it is connected. This corresponds to actual bandwidth values of 106 MB and 212 MB, respectively. WAN data rates range from 1.
S 3 – Planning Performance Tuning Table 3-1. T1 / DS-1 – 1.554 Mbits/Sec Round Trip delay (ms) Total Window Size (bytes) Scaling Factor 25 32 K 0 20 32 K 0 15 32 K 0 10 32 K 0 5 32 K 0 2.5 32 K 0 1 or less 32 K 0 Table 3-2. T3 / DS-3 – 45 Mbits/Sec Round Trip Delay (ms) Total Window Size (bytes) Scaling Factor 250 1 MB 5 100 512 K 4 50 256 K 3 25 128 K 2 20 128 K 2 15 64-128 K 1 or 2 10 64 K 1 5 32 K 0 2.5 32 K 0 1 or less 32 K 0 Table 3-3.
A 3 – Planning Performance Tuning Table 3-3. DS-5 – 400 Mbits/Sec (Continued) Round Trip Delay (ms) Total Window Size (bytes) Scaling Factor 50 1 MB 5 25 1 MB 5 20 1 MB 5 15 1 MB 5 10 512 K 4 5 256 K 3 2.5 128 K 2 1 or less 64 K 1 Table 3-4. OC-1 – 50 Mbits/Sec FI0054601-00 C Round Trip Delay (ms) Total Window Size (bytes) Scaling Factor 250 1 MB 5 100 512 K 4 50 256 K 3 25 128 K 2 20 128 K 2 15 64-128 K 1 or 2 10 64 K 1 5 32 K 0 2.
S 3 – Planning Performance Tuning Table 3-5. OC-3 – 150 Mbits/Sec Round Trip Delay (ms) Total Window Size (bytes) Scaling Factor 250 1 MB 5 100 1 MB 5 50 1 MB 5 25 512 K 4 20 512 K 4 15 256 K 3 10 256 K 3 5 128 K 2 2.5 64 K 1 1 or less 32 K 0 Table 3-6. OC-12 and Above – 621 Mbits/Sec 3-6 Round Trip Delay (ms) Total Window Size (bytes) Scaling Factor 250 1 MB 5 100 1 MB 5 50 1 MB 5 25 1 MB 5 20 1 MB 5 15 1 MB 5 10 1 MB 5 5 512 K 4 2.
A 3 – Planning Topology Topology The SANbox 6142 supports two distinct topologies: interconnecting local SANs (see Figure 3-1) and interconnecting remote SANs (see Figure 3-2).
S 3 – Planning Fibre Channel Switch Ports and Zoning Requirements Fibre Channel Switch Ports and Zoning Requirements The SANbox 6142 FC ports are configured as loop ports. Therefore, the FC switch port, (where SANbox 6142 FC port is connected) must be configured to support a loop topology such as fibre loop port (FL-Port) or generic port (G-Port). The SANbox 6142 uses its local FC ports for discovering local FC devices in the SAN.
A 3 – Planning Services Save the router’s configuration (as a new file) after every configuration change, because you may: Want to revert to a previous configuration Need to configure a replacement router Save the router’s mappings (as a new file) after every mapping change, because you may: Want to revert to a previous mapping Need to map a replacement router Want to duplicate the mapping on a second router (for backup) Services You can configure your router to suit the demands
S 3 – Planning Security Notes 3-10 FI0054601-00 C
4 Installation This section describes how to install and configure a SANbox 6142 router. It also includes firmware installation instructions.
S 4 – Installation SANbox 6142 Router Installation Table 4-1. Management Workstation Requirements Item Description Processor 500 MHz or faster Hardware CD-ROM drive, RJ-45 Ethernet port, RS-232 serial port (optional) Internet browser One of the following: Microsoft Internet Explorer 5.0 and later Netscape Navigator® 4.72 and later Mozilla® 1.02 and later Safari™ Java 2 runtime environment to support the web applet Power Requirements Power requirements for the SANbox 6142 router are 0.
A 4 – Installation SANbox 6142 Router Installation Figure 4-1 SANbox 6142 Router and Accessories To install the SANbox 6142 router: 1. Complete the pre-installation checklist (see page 4-4). 2. Mount the router (see page 4-4). 3. Install the transceivers (see page 4-5). 4. Connect the management workstation to the router (see page 4-5). 5. Configure the management workstation (see page 4-5). 6. Install the management application (see page 4-7). 7.
S 4 – Installation SANbox 6142 Router Installation Pre-installation Check List During the initial configuration process, the system prompts you for the parameters listed in Table 4-2. Fill out the table before installation to expedite the configuration process. Table 4-2.
A 4 – Installation SANbox 6142 Router Installation Install the Transceivers The router supports a variety of SFP transceivers. To install a transceiver, insert the transceiver into the port and gently press until it snaps in place. To remove a transceiver, gently press the transceiver into the port to release tension, then pull the release tab or lever and remove the transceiver. Different transceiver manufactures have different release mechanisms. Consult the documentation of your transceiver.
S 4 – Installation SANbox 6142 Router Installation Setting the Workstation IP Address The IP address of a new router is 10.0.0.1. To ensure that your workstation is configured to communicate with the 10.0.0 subnet, refer to the following instructions for your workstation: Steps for different versions of Windows vary. For a Windows 2000 workstation, do the following: a. From the Windows Start menu, select Settings>Control Panel>Network and Dial-up Connections. b. Click Make New Connection. c.
A 4 – Installation SANbox 6142 Router Installation 3. For Linux: a. Set up minicom to use the serial port. Create or modify the /etc/minirs.dfl file with the following content: pr portdev/ttyS0 pu minit pu mreset pu mhangup pr portdev/ttyS0 specifies port 0 on the workstation. Choose the pr setting to match the workstation port to which you connected the router. b. Verify that all users have permission to run minicom. Review the /etc/minicom.
4 – Installation SANbox 6142 Router Installation S Linux Installation Perform the following steps to install the SANsurfer iSCSI/FC Router Manager application from the QLogic website to a Linux workstation: 1. Go to the QLogic download site: http://support.qlogic.com/support/drivers_software.aspx 2. Select the Intelligent Storage Routers icon. 3. Select SANbox 6142 in the product selection window and click Go. 4.
A 4 – Installation SANbox 6142 Router Installation Connect the Router to AC Power WARNING!! This product is supplied with a 3-wire power cable and plug for the user’s safety. Use this power cable in conjunction with a properly grounded outlet to avoid electrical shock. An electrical outlet that is not correctly wired could place hazardous voltage on metal parts of the router chassis. It is the customer’s responsibility to ensure that the outlet is correctly wired and grounded to prevent electrical shock.
S 4 – Installation SANbox 6142 Router Installation Configure the Router You can configure the router using the SANsurfer iSCSI/FC Router Manager application or the command line interface (CLI). The SANsurfer Router Manager provides a Configuration Wizard you can use to configure the GE ports. If either of the router’s GE ports have not been configured (IP address is 0.0.0.0), the Configuration Wizard starts automatically when the SANsurfer first connects with the router.
A 4 – Installation Firmware Installation Cable Devices to the Router Connect cables to the SFP transceivers and their corresponding devices. Devices can have small form-factor pluggable (SFP) or small form-factor (SFF) transceivers or gigabit interface converters (GBIC). Lucent (LC)-type duplex fiber optic cable connectors are designed for SFP transceivers, while Subscriber-connector (SC)-type connectors are designed for GBICs.
S 4 – Installation Firmware Installation Using the CLI to Install Firmware To use the CLI to install the firmware, transfer the firmware image file from a workstation to the router. Then use the CLI image unpack command to install the new firmware image: 4-12 1. At the workstation prompt, use the ftp command to go to the location on the router where you want to transfer the firmware image. For example: C:\fwImage>ftp 172.17.137.190 Connected to 172.17.137.190. 220 (none) FTP server (GNU inetutils 1.4.
A 4 – Installation Firmware Installation 7. Type the following command from the router, where x stands for the firmware image name: image unpack isr-6142-2_2_0_x.bin The following message displays: Unpack Completed. Please reboot the system for FW to take affect. 8. Type reboot. The following message displays: Are you sure you want to reboot the System (y/n): 9. Type y to reboot the system.
4 – Installation Firmware Installation S Notes 4-14 FI0054601-00 C
5 Diagnostics and Troubleshooting Diagnostic information about the router is available through the chassis LEDs and the port LEDs. Diagnostic information is also available through the SANsurfer iSCSI/FC Router Manager and CLI event logs and error displays.
5 – Diagnostics and Troubleshooting Power-On Self-Test Diagnostics S Input Power LED is Off The input power LED lights up to show that the router logic circuitry is receiving proper voltages. If the input power LED is off, do the following: Inspect power cord and connectors. Is the cord unplugged? Is the cord or connector damaged? Yes – Make necessary corrections or repairs. If the condition remains, continue. No – Continue. Inspect AC power source.
A 5 – Diagnostics and Troubleshooting LED Blink Patterns LED Blink Patterns The Heartbeat and System Fault LEDs show the operational status of the router. When the POST completes with no errors, the heartbeat LED will blink once every second. When the router is in maintenance mode, the Heartbeat and System Fault LEDs are on continuously. All other System Fault blink patterns show critical errors. The heartbeat LED shows an error blink pattern for the conditions listed in Table 5-1. Table 5-1.
5 – Diagnostics and Troubleshooting LED Blink Patterns S Management Port IP Address Conflict Blink Pattern The System Fault LED generates a four-blink pattern (once per second) followed by a two second pause when the router detects an IP address conflict on the management Ethernet port. You can clear the IP address conflict blinking using the CLI or SANsurfer Router Manager. Use the beacon OFF function.
A 5 – Diagnostics and Troubleshooting Recovering a Router Recovering a Router You may have to recover a router for one of the following reasons: The password was changed and has been forgotten. The router’s management IP address is unknown. To recover the router’s password, reset the password to the default by using the maintenance button (see page 2-8).
5 – Diagnostics and Troubleshooting Recovering a Router S Notes 5-6 FI0054601-00 C
6 Removal/Replacement This section describes the removal and replacement procedures for the following field replaceable units (FRU): SFP transceivers The router (see page 6-2) SFP Transceiver Removal and Replacement You can remove and replace the SFP transceivers while the router is operating without damaging the router or the transceiver. However, doing so will interrupt transmission on the affected port until the transceiver is installed.
6 – Removal/Replacement Router Removal and Replacement S Router Removal and Replacement Before you can remove and replace the router, you must turn off the power to the router and disconnect its power cable. The router will lose all the Fibre Channel and iSCSI connections. Removal To remove and replace a router, perform the following steps, as applicable: 1. Make sure all traffic (I/O operations to the router) subsides at the iSCSI initiator systems. 2.
7 SANsurfer iSCSI/FC Router Manager Introduction The SANbox 6142 management application is a graphical user interface consisting of menus, buttons, and windows that you can use to manage SANbox 6142s from a workstation on Linux® and Windows® platforms. You can view and change network, port, security, and mapping configuration for one or more SANbox 6142s. The application displays the most current system information.
S 7 – SANsurfer iSCSI/FC Router Manager Introduction Figure 7-1 SANsurfer Router Manager Main Window Table 7-1. SANsurfer Router Manager Main Window Sections Item 7-2 Description Menu Bar The menu bar provides access to system functions and Wizards. Tool Bar The tool bar buttons provide quick access to the common application functions: Connect, View Logs, and Refresh.
A 7 – SANsurfer iSCSI/FC Router Manager Menu Bar Table 7-1. SANsurfer Router Manager Main Window Sections Item Description System Tree Located on the on the left side of the display, the system tree shows the connected systems and their components. An entry handle located to the left of an entry in the tree shows that you can expand that entry. Click an entry handle or double-click the entry to expand or collapse a system tree entry. Click and drag the window border to re-size the window.
S 7 – SANsurfer iSCSI/FC Router Manager Menu Bar File Menu Figure 7-3 shows the File menu. The following paragraphs describe it. Figure 7-3 File Menu Save FRU – Saves the router’s configuration and persistent data to a file. Restore FRU – Restores the router’s configuration and persistent data from a file. Exit – Exits the SANsurfer iSCSI/FC Router Manager. View Menu Figure 7-4 shows the View menu. The following paragraph describes it.
A 7 – SANsurfer iSCSI/FC Router Manager Menu Bar Figure 7-6 Broadcast Settings Menu Enable Broadcast – Enables broadcast messages sent to locate routers in the IP subnet. Enable Auto Connect – Enables the SANsurfer Router Manager to automatically connect with routers discovered by the broadcast. Broadcast Interval – Lets you enter the time interval at which the SANsurfer Router Manager sends broadcast messages to locate routers within the same IP subnet as the workstation.
7 – SANsurfer iSCSI/FC Router Manager Menu Bar 7-6 S Map Local Initiator/Target Wizard – Launches the Map Local wizard, which allows you to map a local initiator to a local target (see page 7-55). Unmap Local Initiator/Target Wizard – Launches the Unmap Local wizard, which allows you to delete a local initiator from a local target mapping (see page 7-63).
A 7 – SANsurfer iSCSI/FC Router Manager Tool Bar Help Menu Figure 7-8 shows the Help menu. The following paragraphs describe it. Figure 7-8 Help Menu Set Browser Location – Allows you to specify the browser that launches when you view the online help for the SANsurfer iSCSI/FC Router Manager. Browse Contents – Launches the online help for the SANsurfer iSCSI/FC Router Manager. About – Displays the application version information. Tool Bar Figure 7-9 shows the tool bar.
S 7 – SANsurfer iSCSI/FC Router Manager Tool Bar Action Menu The action menu provides short cuts to actions and wizards available elsewhere in the SANsurfer iSCSI/FC Router Manager. To open this menu, right-click anywhere within the router’s node in the system tree window. Figure 7-10 illustrates the action menu and the following paragraphs describe each available option. Figure 7-10 Action Menu 7-8 Connect – Adds a SANbox 6142 router to the system tree view.
A 7 – SANsurfer iSCSI/FC Router Manager Tool Bar Add Remote Router Wizard – Launches the Add Remote Router Wizard, which allows you to assign local router to a remote router as peers (see page 7-68). Remove Remote Router Wizard – Launches the Remove Remote Router Wizard, which allows you to remove a local-to-remote router peer assignment (see page 7-72).
7 – SANsurfer iSCSI/FC Router Manager System Tree Window S System Tree Window Figure 7-11 shows the system tree window. The following sections described it. Figure 7-11 System Tree Window The left most window pane shows the system tree.
A 7 – SANsurfer iSCSI/FC Router Manager System Tree Window Figure 7-12 Component Information Component information displayed for a selected router includes router information, configuration details, router status, and lists of connected or discovered devices.
7 – SANsurfer iSCSI/FC Router Manager System Tree Window S SANbox 6142 Router The top of the router tree displays the router system configuration and status.
A 7 – SANsurfer iSCSI/FC Router Manager System Tree Window Hardware Version – Identifies the router hardware version number. Software Version – Identifies the version of firmware loaded on the router. iSCSI Port Count – Identifies the number of iSCSI ports (2). Fibre Channel Port Count – Identifies the number of Fibre Channel ports (2).
7 – SANsurfer iSCSI/FC Router Manager System Tree Window IPv4 Management Info – Select this check box to use IPv4 (Internet Protocol version 4, 32-bit addressing), then use the radio buttons to identify whether to use either a dynamic or static IP address. 7-14 S IP Address – Displays the management port’s subnet mask. If you selected the Obtain an IP address automatically (DHCP) radio button, the system obtains the IP address automatically through DHCP.
A 7 – SANsurfer iSCSI/FC Router Manager System Tree Window IPv6 Default Router – Use this address to set the default router for the IPv6. The system can also set the IPv6 default router dynamically depending on your network configuration. IPv6 Local Link – This field contains the IPv6 link local address of the port. It is not editable. NOTE: IPv6 support is available only with hardware version 6 and software version 2.4.0.0 and greater.
7 – SANsurfer iSCSI/FC Router Manager System Tree Window S NTP Server 2 – Displays the IP address of the second NTP server to be queried by the router when setting its time and date. This server is used only if the first NTP server did not respond. NTP Server 3 – Displays the IP address of the third NTP server to be queried by the router when setting its time and date. This server is used only if the first and second NTP servers did not respond.
A 7 – SANsurfer iSCSI/FC Router Manager System Tree Window SNMP Management Tab The SNMP Management tabbed page consists of two sections: SNMP Configuration and SNMP Trap Receivers. The Save button saves any SNMP management changes. For more information, see Appendix D. Figure 7-17 shows the SNMP Management tabbed page. The following paragraphs describe it.
S 7 – SANsurfer iSCSI/FC Router Manager System Tree Window Read Community – Enter a password that authorizes an SNMP management server to read information from the router. This is a write-only field. The value on the router and the SNMP management server must be the same. The read community password can be up to 32 characters excluding #, semicolon (;), and comma (,). The default is public. Trap Community – Enter a password that authorizes an SNMP management server to receive traps.
A 7 – SANsurfer iSCSI/FC Router Manager System Tree Window Features Tab Figure 7-18 shows the Features tabbed page that displays the routers licensed features and lets you apply additional license features. The following paragraphs described the page. Figure 7-18 Features Tabbed Page License Information – Displays a list of the routers licensed features. Add – Initiates the Add Feature wizard.
7 – SANsurfer iSCSI/FC Router Manager System Tree Window S Topology Tab Figure 7-19 shows the Topology tabbed page that displays the routers, as shown in the following example. Figure 7-19 Topology Tabbed Page FC Ports When you select an FC port in the system tree, the system displays the FC Port Information tabbed page (see Figure 7-20).
A 7 – SANsurfer iSCSI/FC Router Manager System Tree Window FC Port Information Tab The FC Port Information tab provides the following parameters: Node Name – Displays the world-wide node name (WWNN) assigned to the FC port. Port Name – Displays the world-wide port name (WWPN) assigned to the FC port. Port Status – Lets you change the port status: Enabled (online) or Disabled (offline). After changing the status, click Save.
7 – SANsurfer iSCSI/FC Router Manager System Tree Window S Frame Size – Displays a drop-down list that lets you set the frame size: 2048, 1024, or 512 bytes. The default is 2048. If you change this setting, you must click Save (at the bottom of the page) for the change to take effect. Execution Throttle – Displays a drop-down list that lets you set the execution throttle: 16, 32, 64, 128, or 256. The default is 64.
A 7 – SANsurfer iSCSI/FC Router Manager System Tree Window Target Write – Shows the target’s write performance through the selected FC port. iSCSI Ports When you select an iSCSI port in the system tree, the window displays the Information, Advanced Configuration, and Statistics tabbed pages to the right of the tree (see Figure 7-23). These following sections describe these pages.
S 7 – SANsurfer iSCSI/FC Router Manager System Tree Window Information Tab The Information tabbed page consists of three areas: Port Information, iSCSI Port Network Settings, and iSNS. The following paragraphs describe the information displayed in these sections. iSCSI Port Information The iSCSI Port Information area provides the following parameters: Base Name – Displays the full name assigned to the selected iSCSI port. Link Status – Identifies the port connection status: Link Up or Link Down.
A 7 – SANsurfer iSCSI/FC Router Manager System Tree Window iSCSI Port Network Settings Port Status – When the port link is up, you can enable or disable the port using this drop-down list. IPv4 Address – When using an IPv4 address scheme, define the following fields: FI0054601-00 C IP Address – The IP address to which the port responds. An un-initialized port has an IP address of all zeros.
7 – SANsurfer iSCSI/FC Router Manager System Tree Window S VLAN ID IPv6 – When VLAN IPv6 is enabled the VLAN ID IPv6 contains an identification value in the range 0 to 4094. You can configure VLAN from this window. Priority IPv6 – When VLAN IPv6 is enabled, this field defines the priority assigned to this VLAN IPv6. To set the priority, open the drop-down menu and select the desired value (between 0 to 7).
A 7 – SANsurfer iSCSI/FC Router Manager System Tree Window Advanced Configuration Tab The Advanced Configuration tabbed page allows you to configure the router’s port parameters, security settings, and CHAP settings. The information displayed in these sections is illustrated in Figure 7-24 and described in the following paragraphs.
7 – SANsurfer iSCSI/FC Router Manager System Tree Window 7-28 S Target TCP Port Number – Identifies the TCP port number the router uses to receive iSCSI target commands. The iSCSI community uses TCP port number 3260 by default any change to this TCP port number requires a corresponding change in all iSCSI initiators connecting to this iSCSI target port. When you change the target TCP port number, you must click Save (at the bottom of the page) for the change to take effect.
A 7 – SANsurfer iSCSI/FC Router Manager System Tree Window FI0054601-00 C CHAP Settings Enable CHAP – Enables or disables CHAP (Challenge Handshake Authentication Protocol) support. Select the check box to enable this option; clear the check box to disable it. When you change this setting, you must click Save (at the bottom of the page) for the change to take effect. CHAP Secret – Lets you define the CHAP secret used for authenticating an iSCSI client.
7 – SANsurfer iSCSI/FC Router Manager System Tree Window S Statistics Tab The Statistics tabbed page consists of a scrollable table of parameters and values. The table is divided into two sections: the first section contains statistics that are port specific, and the second section contains shared statistics (common to both iSCSI ports). You can refresh the statistics are by clicking Refresh at the top of the scrollable window. You can clear the statistics (set all values to zero) by clicking Clear.
A 7 – SANsurfer iSCSI/FC Router Manager System Tree Window Discovered iSCSI Initiators Selecting the Discovered iSCSI Initiators branch on the system tree does not provide any information in the right window. Select a discovered iSCSI initiator in the system tree to display the Information and LUN List tabbed pages to the right of the system tree, which are shown in Figure 7-26 and described in the following sections.
7 – SANsurfer iSCSI/FC Router Manager System Tree Window S The CHAP Settings section provides the following parameters: Enable CHAP – Enables or disables CHAP (Challenge Handshake Authentication Protocol) support. Select the check box to enable this option; clear the check box to disable it. CHAP Secret – Lets you define the CHAP secret used for authenticating an iSCSI client. The field is available only when the CHAP check box is checked.
A 7 – SANsurfer iSCSI/FC Router Manager System Tree Window Port – Displays information provided by the target LUN as a result of issuing a SCSI Inquiry command. Protocol – Identifies the target name. For FC targets, the name is the WWPN. WWPN/IQN – Specifies the world wide unique LUN name (WWULN), also provided on page 83 of a SCSI Inquiry command. WWNN – Shows the logical unit number.
7 – SANsurfer iSCSI/FC Router Manager System Tree Window S Status – Displays information provided by the target LUN in response to the router issuing a SCSI Inquiry command. WWPN – Displays information provided by the target LUN in response to the router issuing a SCSI Inquiry command. Remote IQN – Displays information provided by the target LUN in response to the router issuing a SCSI Inquiry command.
A 7 – SANsurfer iSCSI/FC Router Manager System Tree Window Information Tab The Information tabbed page provides the following information about the selected FC target: Product Vendor – Displays the product vendor as reported by the SCSI Inquiry command. Product ID – Displays the product ID as reported by the SCSI Inquiry command. Product Revision – Displays the product revision as reported by the SCSI Inquiry command. Node Name – Displays the world-wide node name of the target device.
S 7 – SANsurfer iSCSI/FC Router Manager System Tree Window Port Name – Displays the world-wide port name of the target device. Port ID – Displays the target device’s port ID. Target Type – Displays the FC port where the target device was discovered. Target Path – Displays the logical unit number. Target Mode – Displays the vendor name of the LUN as reported by the SCSI Inquiry command. Presented On – Displays the product ID of the LUN as reported by the SCSI Inquiry command.
A 7 – SANsurfer iSCSI/FC Router Manager System Tree Window Figure 7-31 iSCSI Presented Target List Tabbed Page Device Product Vendor – Displays the vendor name of the target device as reported by the SCSI Inquiry command. Device Product ID – Displays the product ID name of the target device as reported by the SCSI Inquiry command. Device Product Rev – Displays the product revision of the target device as reported by the SCSI Inquiry command.
S 7 – SANsurfer iSCSI/FC Router Manager System Tree Window iSCSI Discovered Targets The iSCSI Discovered Targets branch on the system tree does not provide any information in the right window. Select a discovered target to display the Information tabbed page to the right of the system tree (see Figure 7-32).
A 7 – SANsurfer iSCSI/FC Router Manager System Tree Window Target Path – Displays the router’s iSCSI port where the target was discovered. CHAP Settings – Provides an option you can use to set the challenge handshake authentication protocol (CHAP) option as follows: Enable CHAP – Select this check box to enable CHAP when connecting to this target. CHAP Secret – When the Enable CHAP option is enabled, you can enter the string used for the CHAP secret when connecting to this target.
7 – SANsurfer iSCSI/FC Router Manager System Tree Window S FCIP Route Information Tabbed Page The FCIP Route Information tabbed page contains the information that defines the selected FCIP route, as described in the following paragraphs. 7-40 FCIP Interface Status – Provides a drop-down box you can use to enable or disable the FCIP route. Disabling the route places the FC and GE ports in a down state, but still retains all route configuration parameters.
A 7 – SANsurfer iSCSI/FC Router Manager System Tree Window GigE Port Flow Control – When the GigE Link Rate is set to something other than auto, use this drop-down box to enable or disable GigE port flow control. The default is enabled. VLAN Enabled – Provides a drop-down box you can use to enable or disable VLAN support. The default is disabled. VLAN ID – When VLAN is enabled, use this field to define the VLAN ID.
7 – SANsurfer iSCSI/FC Router Manager System Tree Window S FCIP Route Statistics Tabbed Page The Statistics tabbed page consists of a scrollable table of parameters and values. Figure 7-34 FCIP Route Statistics Page You can refresh the statistics are by clicking Refresh at the top of the scrollable window. You can clear the statistics (set all values to zero) by clicking Clear.
A 7 – SANsurfer iSCSI/FC Router Manager Wizards Wizards The SANsurfer iSCSI/FC Router Manager provides easy-to-use wizards that walk you through various router configuration procedures. You can launch an available wizard using any of the following methods: Select an option from the Wizards menu, located on the Router Manager’s menu bar (see page 7-5.) Right-click anywhere within the router’s node in tree window and select one of the wizards available from the action menu (see page 7-8.
7 – SANsurfer iSCSI/FC Router Manager Wizards S Configuration Wizard The Configuration Wizard provides a set of dialog boxes that walk you through the steps required for configuring the iSCSI ports. This wizard starts automatically when your system connects to a system with any un-configured iSCSI ports. You can also start this wizard at any time by selecting Configuration Wizard from the Wizards menu or from the Action Menu.
A 7 – SANsurfer iSCSI/FC Router Manager Wizards Figure 7-36 iSCSI Port Connection Settings Panel Dialog Box 2. To configure the iSCSI Port IPV4 settings: a. b. 3. FI0054601-00 C Type the information in the following fields. IP Address Subnet Mask Gateway If desired, configure the IP address of the iSNS server with which the router registers the selected iSCSI port: Select the Enable iSNS check box to make the Server IP address field editable.
S 7 – SANsurfer iSCSI/FC Router Manager Wizards Figure 7-37 iSCSI Port IPv6 Settings Panel 4. To configure the iSCSI port IPv6 connection using this dialog box, follow these steps: a. Select Enable IPv6 Address to make the fields editable. b. Specify the iSCSI port IPv6 network settings: c. 5. 7-46 Enter the IPv6 Address 0. Enter the IPv6 Address 1. Enter the IPv6 Default Router. Enter the IPv6 Link Local.
A 7 – SANsurfer iSCSI/FC Router Manager Wizards Figure 7-38 Confirm Changes Dialog Box 6. FI0054601-00 C Review the configuration changes displayed on the screen, then click Next to confirm your changes.
S 7 – SANsurfer iSCSI/FC Router Manager Wizards The system displays the iSCSI Port Configuration Status dialog box, as shown in Figure 7-39. Figure 7-39 iSCSI Port Configuration Status 7. Read the information about the status changes, then click Next. The system displays the Refresh dialog box. 8. Read the information. If you would like to see the new configuration, click Yes; otherwise, click No. The system displays the Finish dialog box, as shown in Figure 7-40.
A 7 – SANsurfer iSCSI/FC Router Manager Wizards Figure 7-40 Configuration Wizard Finish Dialog Box 9. Read the information, then click Finish. Add Initiator Wizard The Add Initiator Wizard provides a dialog box used to enter an iSCSI initiator into the system database. iSCSI initiators are normally discovered (their name and address are captured) the first time they log in to the SANbox 6142 router.
7 – SANsurfer iSCSI/FC Router Manager Wizards S Figure 7-41 Create an Initiator Dialog Box To create an initiator: 1. Type a name in the Initiator name box. 2. Type an alias in the Initiator alias (iSCSI) box. 3. If you want to enable CHAP for this initiator, select the CHAP Enabled check box. If you want a CHAP secret, type the name in the Initiator’s CHAP Secret box. 4. Click Finish. The Security Check dialog box displays, as shown in Figure 7-42. Figure 7-42 Security Check Dialog Box 5.
A 7 – SANsurfer iSCSI/FC Router Manager Wizards The new iSCSI initiator is displayed in the discovered iSCSI initiator’s section of the system tree, as shown in Figure 7-43. Figure 7-43 System Tree with New iSCSI Initiator FW Update Wizard The FW Update Wizard provides a set of dialog boxes that walk you through the steps required for updating the SANbox 6142 firmware. This wizard helps you update the firmware on selected router.
7 – SANsurfer iSCSI/FC Router Manager Wizards S To update the firmware, follow these steps: 1. Select the check box next to the routers whose firmware you want to update, then click Next. The Open dialog box displays. Figure 7-45 Firmware File Selection Dialog Box 7-52 2. Enter in the path to the firmware file, or click Browse to locate the firmware file. 3. When the firmware file is displayed in the Firmware Image File field, click Next.
A 7 – SANsurfer iSCSI/FC Router Manager Wizards The Confirm Changes dialog box displays, as shown in Figure 7-46. Figure 7-46 Confirm Changes Dialog Box 4. Read the information, then do the following: a. If you want to save a copy of this firmware configuration, click Save Configuration to File. Browse to the desired directory, type a file name, then click Save. b. Click Next. The Security Check dialog box requests the Admin password, as shown in Figure 7-47. Figure 7-47 Security Check Dialog Box c.
S 7 – SANsurfer iSCSI/FC Router Manager Wizards Figure 7-48 Firmware Update Status Dialog Box—Progress When the firmware has loaded successfully, the system displays the Finish dialog box, along with the Update success dialog box, as shown in Figure 7-49.
A 7 – SANsurfer iSCSI/FC Router Manager Wizards NOTE: The new firmware will not take effect until the system is rebooted. 6. Complete the wizard: a. If you want to reboot the system now, click Yes. Otherwise, click No. b. Click Finish. Map Local Initiator/Target Wizard The Map Local Initiator/Target Wizard provides a set of dialog boxes that walk you through the steps required for mapping a local initiator to a local target.
S 7 – SANsurfer iSCSI/FC Router Manager Wizards The Select a Target dialog box opens, as shown in Figure 7-51. Figure 7-51 Select a Target Dialog Box 2. 7-56 Select a target you want mapped to the previously selected initiator, then click Next.
A 7 – SANsurfer iSCSI/FC Router Manager Wizards The wizard screen prompts you to select a port on which the initiator will be presented, as shown in Figure 7-52. Figure 7-52 Select Initiator Port Dialog Box 3. FI0054601-00 C Select the port (FC Port 1 or FC Port 2), then click Next.
7 – SANsurfer iSCSI/FC Router Manager Wizards S The wizard screen prompts you to select a port on which the target will be presents (iSCSI Port 1 and iSCSI Port 2), as shown in Figure 7-53.
A 7 – SANsurfer iSCSI/FC Router Manager Wizards The Confirm Changes dialog box displays the local mapping done in the previous steps, as shown in Figure 7-54. Figure 7-54 Confirm Changes Dialog Box 4. FI0054601-00 C Review the information, then click Next.
7 – SANsurfer iSCSI/FC Router Manager Wizards S The Security Check dialog box requests the Admin password, as shown in Figure 7-55. Figure 7-55 Security Check Dialog Box 5. 7-60 Type the appropriate password, then click OK to confirm the local mapping.
A 7 – SANsurfer iSCSI/FC Router Manager Wizards The Initiator/Target Mapping Configuration Status dialog box displays local mapping completion status, as shown in Figure 7-56. Figure 7-56 Initiator/Target Mapping Configuration Status Dialog Box 6. FI0054601-00 C After reviewing the initiator to target mapping configuration status, click Next.
7 – SANsurfer iSCSI/FC Router Manager Wizards S After completing the Map Local Initiator/Target wizard, you can see the mapping by selecting the mapped Initiator in the system tree under Discovered iSCSI Initiators. Click the Local Presented Devices tab, as shown in Figure 7-57. In this example an iSCSI initiator is mapped to an FC target, other mappings are supported such as FC to FC, FC to iSCSI and iSCSI to iSCSI.
A 7 – SANsurfer iSCSI/FC Router Manager Wizards Unmap Local Initiator/Target Wizard The Unmap Local Initiator/Target Wizard provides a set of dialog boxes that walk you through the steps required for removing a local initiator from a local target mapping. You can start this wizard at any time by selecting Unmap Local Initiator/Target Wizard from the Wizards Menu or from the Action Menu.
7 – SANsurfer iSCSI/FC Router Manager Wizards S The Presented Target Selection dialog box displays a list of targets mapped to the initiator selected in the previous step, as shown in Figure 7-59. Figure 7-59 Presented Target Selection Dialog Box 2. 7-64 Select the check box next to the target to unmap, then click Next.
A 7 – SANsurfer iSCSI/FC Router Manager Wizards The Security Check dialog box requests the Admin password, as shown in Figure 7-60. Figure 7-60 Security Check Dialog Box 3. FI0054601-00 C Type the appropriate password, then click OK to confirm the target is unmapped.
S 7 – SANsurfer iSCSI/FC Router Manager Wizards The Unpresent Initiator/Target Status dialog box displays the results of the unmap operation, as shown in Figure 7-61. Figure 7-61 Unpresent Initiator/Target Status Dialog Box 4. 7-66 Review the status, then click Next.
A 7 – SANsurfer iSCSI/FC Router Manager Wizards After completing the UnMap Local Initiator/Target wizard you can verify the unmapping by selecting the Initiator in the system tree under Discovered iSCSI Initiators. Then select Local Presented Devices. For the example shown in Figure 7-62, an iSCSI initiator was unmapped from an FC target.
7 – SANsurfer iSCSI/FC Router Manager Wizards S Add Remote Router Wizard The Add Remote Router Wizard provides a set of dialog boxes that walk you through the steps required for assigning a remote router to your local router as a peer. You can start this wizard at any time by selecting Add Remote Router Wizard from the Wizards Menu or from the Action Menu. When the Add Remote Router wizard launches, the Remote Router’s IP Address dialog box requests the remote router’s IP address, as shown in Figure 7-63.
A 7 – SANsurfer iSCSI/FC Router Manager Wizards The Status dialog box displays the remote router information along with the Local Router Admin Password dialog box, as shown in Figure 7-64. Figure 7-64 Local Router Admin Password Dialog Box 2. Type the local router admin password (default=config), then click OK. The Status dialog box displays the remote router information, as shown in Figure 7-65.
7 – SANsurfer iSCSI/FC Router Manager Wizards S 3. Review the status, then click Finish. 4. Click the Refresh icon to refresh the display. 5. Select the router node, then select the Assigned Remote Router:1 tab to display the remote router’s information, as shown in Figure 7-66.
A 7 – SANsurfer iSCSI/FC Router Manager Wizards 6. Click the Topology tab to display the local and remote router topology including devices attached to both routers, as shown in Figure 7-67.
7 – SANsurfer iSCSI/FC Router Manager Wizards S Remove Remote Router Wizard The Remove Remote Router Wizard provides a set of dialog boxes that walk you through the steps required for removing a remote router from the local router. You can start this wizard at any time by selecting Remove Remote Router Wizard from the Wizards Menu or from the Action Menu.
A 7 – SANsurfer iSCSI/FC Router Manager Wizards The Local Router Admin Password dialog box requests the local router’s admin password to complete the unmap, as shown in Figure 7-69. Figure 7-69 Local Router Admin Password Dialog Box 2. Type the local router’s admin password (default=config), then click OK. The system prompts you to refresh the display, as shown in Figure 7-70. Figure 7-70 Refresh Screen 3. FI0054601-00 C Click Yes to refresh the display.
S 7 – SANsurfer iSCSI/FC Router Manager Wizards The Remove Remote Router Completion dialog box displays the completion status, as shown in Figure 7-71. Figure 7-71 Remove Remote Router Completion Dialog Box 4. 7-74 Click OK to close the message box.
A 7 – SANsurfer iSCSI/FC Router Manager Wizards Map Remote Initiator/Target Wizard The Map Remote Initiator/Target Wizard provides a set of dialog boxes that walk you through the steps required for mapping an initiator to a target one of which is remote and the other local. You can start this wizard at any time by selecting Map Remote Initiator/Target Wizard from the Wizards Menu or from the Action Menu.
7 – SANsurfer iSCSI/FC Router Manager Wizards S The Device Selection dialog box displays list of devices, as shown in Figure 7-73. Figure 7-73 Device Selection Dialog Box 3. 7-76 If necessary, expand the router tree to see the attached devices. Select the device to be mapped. The device may be a target or an initiator and may be on either the remote router or on the local router. Click Next.
A 7 – SANsurfer iSCSI/FC Router Manager Wizards The port selection dialog box prompts you to select a port the system will use to connect to the device, as shown in Figure 7-74. Figure 7-74 Port Selection Dialog Box 4. FI0054601-00 C Select the port the system will use to connect to the device, then click Next.
7 – SANsurfer iSCSI/FC Router Manager Wizards S The Device Mapping Option dialog box displays SmartWrite mapping options, as shown in Figure 7-75. Figure 7-75 Device Mapping Option Dialog Box 7-78 5. If your router includes the SmartWrite feature, Enable or Disable the options as you want. 6. Click Next.
A 7 – SANsurfer iSCSI/FC Router Manager Wizards The Confirm Mapping dialog box displays the mapping and option selections, as shown in Figure 7-76. Figure 7-76 Confirm Mapping Dialog Box 7. Review the information and, if correct, click Next. The Local Router Admin Password dialog box displays, as shown in Figure 7-77. Figure 7-77 Local Password Dialog Box 8. FI0054601-00 C Type the local router admin password (default=config), then click OK.
7 – SANsurfer iSCSI/FC Router Manager Wizards S The Remote Mapping Status screen displays a list of newly mapped devices, as shown in Figure 7-78. Figure 7-78 Local Router Admin Password Dialog Box 9. Review the status information, then click Finish. The system prompts you to refresh the display, as shown in Figure 7-79. Figure 7-79 Refresh Screen 10. 7-80 Click Yes to refresh the display.
A 7 – SANsurfer iSCSI/FC Router Manager Wizards 11. View the mapped devices in the router’s tree window. Figure 7-80 shows the mapping created in the sample procedures. Figure 7-80 Remote Mapped Device Unmap Remote Initiator/Target Wizard The Unmap Remote Initiator/Target Wizard provides a set of dialog boxes that walk you through the steps required for removing an initiator-to-target mapping.
7 – SANsurfer iSCSI/FC Router Manager Wizards S Figure 7-81 Device Selection Dialog Box To unmap an initiator and target: 1. 7-82 Select the device to be unmapped, then click Next.
A 7 – SANsurfer iSCSI/FC Router Manager Wizards The Local Router’s Admin Password dialog box requests the local router’s admin password to continue with the unmap, as shown in Figure 7-82. Figure 7-82 Local Router Admin Password Dialog Box 2. Type the local router’s admin password (default=config), then click OK. The Remote Unmap Initiator-Target Status dialog box displays the status of the unmap operation, as shown in Figure 7-83. Figure 7-83 Remote Unmap Initiator-Target Status Dialog Box 3.
7 – SANsurfer iSCSI/FC Router Manager Wizards S Discover iSCSI Target Wizard The Discover iSCSI Target Wizard provides a set of dialog boxes that walk you through the steps required for discovering an iSCSI target. You can start this wizard at any time by selecting Discover iSCSI Target from the Wizards Menu or from the Action Menu.
A 7 – SANsurfer iSCSI/FC Router Manager Wizards 4. Type the appropriate password, then click OK to confirm the discovery of the iSCSI target. If the wizard detected iSCSI targets, the Refresh dialog box signifies the discovery of the iSCSI target, as shown in Figure 7-86. This dialog box may take a few seconds before appearing. Figure 7-86 Discover iSCSI Target Wizard—Refresh Dialog Box 5. Click Yes to refresh system tree with the discovered iSCSI target, or click No to skip the refresh.
S 7 – SANsurfer iSCSI/FC Router Manager Wizards FCIP Route Add Wizard The FCIP Route Add Wizard provides a set of dialog boxes that walk you through the steps required for adding an FCIP route. You can start this wizard at any time by selecting FCIP Route Add from the Wizards Menu or from the Action Menu. When the FCIP Route Add Wizard launches, it displays a warning message, letting you know the operation may drop the connection to the selected GE and FC ports.
A 7 – SANsurfer iSCSI/FC Router Manager Wizards The FC and GigE Port Selection dialog box prompts you to select an FC-GigE port pair, as shown in Figure 7-89. Figure 7-89 FCIP Route Add Wizard—Port Selection Dialog Box 2. Select the FC-GigE Port pair. The corresponding parameter options become available. 3. If desired, configure the following port route/parameters: 4. FI0054601-00 C FCIP Interfaces FC & GE – Provides a drop-down box you can use to enable or disable the FCIP route.
7 – SANsurfer iSCSI/FC Router Manager Wizards S The Local and Remote IP Address dialog box requests entry of IP addresses (see Figure 7-90). Figure 7-90 FCIP Route Add Wizard—Local and Remote IP Address Dialog Box 5. 6. 7-88 Configure any of the following parameters: Local IP Address – Enter the IP address the GigE port will use. An uninitialized port has an IP address of all zeros. Subnet Mask – Enter the subnet mask the GigE port will use.
A 7 – SANsurfer iSCSI/FC Router Manager Wizards The TCP/IP Options dialog box requests entry of TCP/IP parameters, as shown in Figure 7-91. Figure 7-91 FCIP Route Add Wizard—TCP/IP Options Dialog Box 7. FI0054601-00 C Configure any of the following parameters: Jumbo Frames – Provides a drop-down box you can use to enable or disable Jumbo IP frames. When disabled the MTU is 1500 bytes. When enabled the MTU is 9000 bytes.
S 7 – SANsurfer iSCSI/FC Router Manager Wizards 8. VLAN Priority – Provides a drop-down box that contains eight options for the VLAN priority: any number between 0–7. This dialog box is available only when VLAN is enabled. After setting the TCP/IP parameters, click Next to continue or click Cancel to quit the wizard. The FCIP Options dialog box requests entry of FCIP parameters, as shown in Figure 7-92. Figure 7-92 FCIP Route Add Wizard—FCIP Options Dialog Box 9.
A 7 – SANsurfer iSCSI/FC Router Manager Wizards used by the FCIP route so as to not consume all the available link bandwidth. For example, if the slowest link in the WAN being used is a DS-3 link, the maximum available bandwidth is 45 megabits per second. To limit the FCIP route to 33% of the overall link bandwidth set the bandwidth to 15 megabits per second. 10. After setting the FCIP parameters, click Next to continue or click Cancel to quit the wizard.
S 7 – SANsurfer iSCSI/FC Router Manager Wizards FCIP Route Remove Wizard The FCIP Route Remove Wizard provides a set of dialog boxes that walk you through the steps required for removing an FCIP route. You can start this wizard at any time by selecting FCIP Route Remove from the Wizards Menu or from the Action Menu. When the FCIP Route Remove wizard launches, it displays a warning message, letting you know the operation may drop the connection to the selected GE and FC ports.
A 7 – SANsurfer iSCSI/FC Router Manager Wizards The FCIP Remove dialog box displays a list of existing FCIP routes, as shown in Figure 7-96. Figure 7-96 FCIP Route Remove Wizard—Route Selection Dialog Box 2. Select the FCIP route you want to remove, then click Finish. The Security Check dialog box requests the administrator password, as shown in Figure 7-97. Figure 7-97 FCIP Route Remove Wizard—Security Check Dialog Box 3.
S 7 – SANsurfer iSCSI/FC Router Manager Wizards The Add FCIP Route Complete dialog box lets you know when the configuration is complete, as shown in Figure 7-98. Figure 7-98 FCIP Route Remove Wizard—Completed Dialog Box NOTE: This dialog box may take a few seconds before appearing. 4. 7-94 Click OK to exit the dialog box.
A Command Reference The command line interface (CLI) enables you to perform a variety of router management tasks through an Ethernet or serial port connection.
S A – Command Reference Guest Account Guest Account Routers come from the factory with the following account already defined: Account name: guest Password: password This guest account provides access to the router and its configuration. After planning your router management needs, consider changing the password for this account. The guest account is automatically closed after 15 minutes of inactivity. See the Password Command for information about changing passwords.
A A – Command Reference Working with SAN Router Configurations Save Router Configuration and Persistence Perform the following steps to save the router’s configuration and persistent data. Persistent data consists of LUN mappings, discovered FC targets, and discovered iSCSI initiators. 1. Execute the Fru save CLI command (see FRU Command) to generate a file (iSR-6142_FRU.bin) containing the saved data. This file is stored locally on the router in an FTP directory. 2.
A – Command Reference Working with SAN Router Configurations S Restore Router Configuration and Persistence Perform the following steps to restore the router’s configuration and persistent data: 1. Transfer the saved data from a workstation to the router by executing an FTP utility on the workstation. The following text is an example of an FTP transfer to put previously saved router configuration data on the router: c:\>ftp 172.17.137.102 Connected to 172.17.137.102.
A A – Command Reference Commands Commands The CLI command syntax is as follows: command keyword keyword [value] keyword [value1] [value2] The command is followed by one or more keywords. Consider the following rules and conventions: Commands and keywords are case insensitive. Required keyword values appear in standard font: [value]. Optional values are shown in italics: [value]. Underlined portions of the keyword in the command format indicate the abbreviated form that can be used.
A – Command Reference Commands S Admin Command Opens and closes an administrator session. You can run any command that changes the router configuration within an Admin session. Only one Admin session can be open on the router at any time. An inactive Admin session will time out after 15 minutes. Authority None Syntax admin start (or begin) end (or stop) cancel Keywords start (or begin) Opens the Admin session. end (or stop) Closes the Admin session.
A A – Command Reference Commands Beacon Command Enables or disables the Heartbeat and System Fault LEDs flashing. The heartbeat and system fault LEDs flash synchronously (on and off, together). No other LEDs are affected. Authority Admin session Syntax beacon on off Keywords on Turns on the router beacon. off Turns off the router beacon.
A – Command Reference Commands S Clear Command The clear command provides two operations: it removes all entries from the router’s log file, or it resets the Fibre Channel and iSCSI statistic counters. Authority Admin session Syntax clear [logs or stats] Keywords logs Clears all entries from router’s log file. stats Resets the statistic counters.
A A – Command Reference Commands Date Command This command displays or sets the date and time. To set the date and time, the information string must be provided in this format: MMDDhhmmCCYY. The new date and time takes effect immediately. Authority Admin session to set the date and time. No authority required to display the current date and time. Syntax date [MMDDhhmmCCYY] Keywords [MMDDhhmmCCYY] Specifies the date—this requires an Admin session.
S A – Command Reference Commands FcipRoute Command The FCIP route command provides for configuring a new FCIP route and modifying or deleting an existing FCIP route. Each FCIP route requires a dedicated FC and Gigabit Ethernet port. Configuring an FCIP route, specifying an FC and GE port pair, take precedence over any previous configuration for the port pair (FC/GE). This removes the previous configuration of the port pair. Authority Admin session.
A A – Command Reference Commands Remote IPv6 Address fe80::21b:21ff:fe06:d517 [:: ] MTU Size (0=Normal, 1=Jumbo, 2=Other) [Normal ] TCP Window Size (0=8KB, 1=16KB, 2=32KB) [32768 ] Window Scaling (0=Enable, 1=Disable) [Disabled ] TCP Port No.
S A – Command Reference Commands TCP Window Size (0=8KB, 1=16KB, 2=32KB) [32768 ] Window Scaling (0=Enable, 1=Disable) [Disabled ] TCP Port No.
A A – Command Reference Commands FRU Command The FRU command saves and restores the router’s configuration. Authority Admin session to restore. Syntax fru restore save Keywords restore The FRU restore command requires that you first ftp the tar file containing the desired configuration to the router. After issuing this command, you are prompted for the restore level. You can fully restore the router’s configuration (all configuration parameters and LUN mappings) or restore only the LUN mappings.
S A – Command Reference Commands Help Command The help command displays a list of the commands and their syntax.
A A – Command Reference Commands memory | mgmt | ntp perf | presented_initiators | presented_targets properties | remotemaps | remotepeers snmp | stats | system targets ] show chap show fc [ ] show fciproutes [ ] show features show initiators [ fc | iscsi ] show iscsi [ ] show isns [ ] show localmaps show logs show memory show mgmt show ntp show perf [ byte | init_rbyte | init_wbyte | tgt_rbyte | tgt_wbyte ] show presented_initiators [ fc | iscsi ] show presented
A – Command Reference Commands S History Displays a numbered list of the previously entered commands.
A A – Command Reference Commands Image Command Updates the router’s firmware image and cleans up (removes) the image files in the router’s /var/ftp directory. NOTE: Use FTP to transfer an image file to the router’s /var/ftp directory. Authority Admin session Syntax image cleanup list unpack [file] Keywords cleanup Removes all firmware image files in the router’s /var/ftp directory. You can transfer these are files when updating the router’s firmware image.
A – Command Reference Commands S Initiator Command Adds, modifies, and removes an initiator in the router’s database. Authority Admin session Syntax initiator add mod remove Keywords add Adds an initiator the router’s database. mod Modifies the settings of an initiator. remove Removes an initiator. Examples Initiator add command example: QRouter (admin) #> initiator add A list of attributes with formatting and current values will follow.
A A – Command Reference Commands Initiator remove command example: QRouter (admin) #> initiator rm Index (WWNN/iSCSI Name) ----- ----------------0 iqn.1991-05.com.microsoft:qlogic-09sd5i4l Please select an Initiator from the list above ('q' to quit): 0 All attribute values for that have been changed will now be saved.
A – Command Reference Commands S Localmap Command The localmap command maps a locally-connected initiator device to a locally-connected target device. The initiator and target are not on the same FC port. Authority Admin session Syntax localmap add rm Keywords add Add local initiator to target mapping. rm Remove local initiator to target mapping.
A A – Command Reference Commands initiator is assigned below. To accept the default assigned name simply press the ENTER key or enter a new name. FC presented initiator WWPN [21:01:00:c0:dd:0c:8b:e2 ] : The selected target has not been presented on the port that was selected to be accessed the initiator. The following steps in the wizard will now setup the target so that it is presented on the port that will be used by the initiator. A default name for the presented target is assigned below.
A – Command Reference Commands S FC presented initiator WWPN [21:01:00:c0:dd:0c:8b:e2 ] : The selected target has not been presented on the port that was selected to be accessed the initiator. The following steps in the wizard will now setup the target so that it is presented on the port that will be used by the initiator. A default name for the presented target is assigned below. To accept the default assigned name simply press the ENTER key or enter a new name. iSCSI presented target name [iqn.2004-08.
A A – Command Reference Commands Logout Command Exits the command line interface and returns you to the login prompt.
A – Command Reference Commands S Password Command Changes the guest and administrator passwords. Authority Admin session Syntax password Examples Password command example: QRouter (admin) #> passwd Press 'q' and the ENTER key to abort this command. Select password to change (0=guest, 1=admin) : 1 account OLD password : ****** account NEW password (6-128 chars) : ****** please confirm account NEW password : ****** Password has been changed.
A A – Command Reference Commands Ping Command The ping command verifies the connectivity of each Ethernet port, management, GE1 (iSCSI 1), and GE2 (iSCSI 2). Authority Admin session Syntax ping Examples Ping command example: QRouter (admin) #> ping A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value.
S A – Command Reference Commands Quit Command Exits the command line interface and returns you to the login prompt.
A A – Command Reference Commands Reboot Command Restarts the router firmware. Authority Admin session Syntax reboot Examples Reboot command example: QRouter (admin) #> reboot Are you sure you want to reboot the System (y/n): y System will now be rebooted...
S A – Command Reference Commands Remote Map Command The remotemap command provides for the mapping of an initiator and target, one of which is located on a remote system (router). It prompts you to enter the remote system (router), then lists the devices (initiators and targets) located on the remote system. You can select a device from the remote system and then the local system.
A A – Command Reference Commands Index (WWNN,WWPN/iSCSI Name) ----- ---------------------0 20:00:00:e0:8b:08:5f:3d,21:00:00:e0:8b:08:5f:3d (Initiator) 1 20:00:00:d0:b2:00:19:f0,21:00:00:d0:b2:00:19:f0 (Init/Tgt) Please select a REMOTE device from the list above ('q' to quit) : 0 NOTE: Both the LOCAL and REMOTE systems do not have the SMART-WRITE feature, therefore the querying of the SMART-WRITE settings are not applicable and will be skipped for this mapping.
S A – Command Reference Commands Smart-Write (0=Enable, 1=Disable) [Enabled ] Smart-Write Compression (0=Enable, 1=Disable) [Disabled ] Smart-Write Load Balance (0=Enable, 1=Disable) [Disabled ] All attribute values for that have been changed will now be saved. Remotemap add command example wihout SMART-WRITE licenses: QRouter (admin) #> remotemap add The following wizard will create a mapping a device connected to the local system and a device connected to the selected remote peer system.
A A – Command Reference Commands Please select a remote mapping from the list above ('q' to quit): 0 Smart-Write Compression (0=Enable, 1=Disable) [Disabled ] 1 Smart-Write Load Balance (0=Enable, 1=Disable) [Enabled ] 1 All attribute values for that have been changed will now be saved. Remotemap modify command example without SMART-WRITE licenses: QRouter (admin) #> remotemap mod The following wizard will be used to modify various settings of a remote mapping.
A – Command Reference Commands S Remote Peer Command The remotepeer command lets you assign a router peer to a local router, which can have up to four peers. Authority Admin session Syntax remotepeer add rm Keywords add Add a peer router. rm Remove a peer router. Examples Remotepeer add command example: QRouter (admin) #> remotepeer add A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value.
A A – Command Reference Commands Remotepeer remove command example: QRouter (admin) #> remotepeer rm Index (System Info, Mgmt IP Address) ----- -----------------------------0 iSR-6142.0608A00487(172.17.137.215) Please select a remote system from the list above ('q' to quit): 0 WARNING: Remote mappings exist between the LOCAL system and the selected REMOTE system. Removing this REMOTE system will also remove these mappings.
A – Command Reference Commands S Reset Factory Command Restores the router configuration parameters to the factory default values. It deletes all LUN mappings, as well as all persistent data regarding targets, LUNs, and initiators. It also restores the factory default IP addresses. Authority Admin session Syntax reset factory Keywords factory Restores the router to factory default configuration.
A A – Command Reference Commands Save Command Saves logs and traces. Authority Admin session Syntax save capture logs traces Keywords capture The save capture command creates a debug file that captures all debug dump data. After the command completes, you must ftp the debug capture file from the router. logs The save logs command creates a tar file containing the router’s log data, storing the file in the router’s /var/ftp directory.
A – Command Reference Commands S Two Save traces command examples: QRouter (admin) #> save traces Save ASIC Traces completed. Package is Router_Asic_Trace.tar.gz Please use FTP to extract the file out from the System. QRouter (admin) #> save traces No ASIC trace files exist to save. Command aborted.
A A – Command Reference Commands Set Command Configures general router parameters as well as parameters that are specific to the Fibre Channel, iSCSI, and management ports. Authority Admin session Syntax set chap fc [port_num] features Iscsi [port_num] Isns [port_num] mgmt ntp properties snmp system Keywords chap Sets the CHAP secrets. fc [port_num] Sets the Fibre Channel port parameters. features Sets licensed router features such as SmartWrite or additional host ports.
A – Command Reference Commands S system Sets system parameters such as symbolic name and log level.
A A – Command Reference Commands Set CHAP Command Configures general router parameters. Authority Admin session Syntax set chap Examples Set CHAP command example: QRouter (admin) #> set chap Index (WWNN,WWPN/iSCSI Name) ----- ---------------------0 iqn.2004-08.com.qlogic.isr-6142.0539A01064.0.2000002037fd8bab.2200002 037fd8bab 1 iqn.2004-08.com.qlogic.isr-6142.0539A01064.1.2000002037fd8bab.
A – Command Reference Commands S Set FC Command Configures a Fibre Channel port. Authority Admin session Syntax set fc [port_num] Keywords [port_num] The number of the FC port to be configured. Examples Set FC command example: QRouter (admin) #> set fc 1 A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value.
A A – Command Reference Commands Set Features Command The set features command lets you enter licensed router features such as SmartWrite or additional host ports. NOTE: The date and time must be set prior to entering feature license keys. Authority Admin session Syntax set features Examples Set Features command example: QRouter (admin) #> set features A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value.
S A – Command Reference Commands Set iSCSI Command Configures an iSCSI port. Authority Admin session Syntax set iscsi [port_num] Keywords [port_num] The number of the iSCSI port to be configured. Examples Set iSCSI command example: QRouter (admin) #> set iscsi 1 A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value.
A A – Command Reference Commands IPv6 Tgt TCP Port No. (Min=1024, Max=65535) [3260 ] IPv6 Window Scaling (0=Enable, 1=Disable) [Enabled ] IPv6 Window Scaling Factor (Min=0, Max=5) [1 ] IPv6 VLAN (0=Enable, 1=Disable) [Disabled ] All attribute values for Port 1 that have been changed will now be saved.
S A – Command Reference Commands Set iSNS Command Configures iSNS parameters for an iSCSI port. Authority Admin session Syntax set isns [port_num] Keywords [port_num] The number of the iSCSI port to be configured for iSNS. Examples Set iSNS command example: QRouter (admin) #> set isns 1 A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value.
A A – Command Reference Commands Set Mgmt Command Configures the router’s management port (10/100). Authority Admin session Syntax set mgmt Examples Set Mgmt command example: QRouter (admin) #> set mgmt A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value. If you wish to terminate this process before reaching the end of the list press 'q' or 'Q' and the ENTER key to do so.
A – Command Reference Commands S Set NTP Command Use the set NTP command to configure the network time protocol parameters. NTP sets the date and time on the router from a network time server. Authority Admin session Syntax set ntp Examples Set NTP command example: QRouter (admin) #> set ntp A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value.
A A – Command Reference Commands Set Properties Command Configures the CLI (command line interface) properties. Authority Admin session Syntax set properties Examples Set Properties command example: QRouter (admin) #> set properties A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value. If you wish to terminate this process before reaching the end of the list press 'q' or 'Q' and the ENTER key to do so.
S A – Command Reference Commands Set SNMP Command Configures the general simple network management protocol (SNMP) properties, as well as configuring eight trap destinations. Authority Admin session Syntax set snmp trap_destinations Keywords trap_destinations Specifies the setting of the trap destinations. Examples Set SNMP command example for setting the general properties: QRouter (admin) #> set snmp A list of attributes with formatting and current values will follow.
A A – Command Reference Commands ------------------------------------Destination enabled (0=Enable, 1=Disable) [Disabled ] Configuring SNMP Trap Destination 3 : ------------------------------------Destination enabled (0=Enable, 1=Disable) [Disabled ] Configuring SNMP Trap Destination 4 : ------------------------------------Destination enabled (0=Enable, 1=Disable) [Disabled ] Configuring SNMP Trap Destination 5 : ------------------------------------Destination enabled (0=Enable, 1=Disable) [Disabled ] Con
A – Command Reference Commands S Set System Command Configures the general router parameters. Authority Admin session Syntax set system Examples Set System command example: QRouter (admin) #> show system A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value. If you wish to terminate this process before reaching the end of the list press 'q' or 'Q' and the ENTER key to do so.
A A – Command Reference Commands Show Command Displays router operational information. Authority None Syntax show chap fc [port_num] fciproutes [link_id] features initiators [fc or iscsi] iscsi [port_num] isns [port_num] localmaps logs memory mgmt ntp perf [ byte | init_rbyte | init_wbyte | tgt_rbyte | tgt_wbyte ] presented_initiators [ fc | iscsi ] presented_targets [fc or iscsi] properties remotemaps remotepeers snmp stats system targets [fc or iscsi] Keywords chap Displays Chap information.
S A – Command Reference Commands iscsi [port_num] Displays iSCSI port information and configuration. isns [port_num] Displays the router’s iSCSI name server (iSNS) configuration. localmaps Displays local mappings, FC to FC, iSCSI to FC, and FC to iSCSI. logs Displays contents of the router logs. memory Displays memory managed by router. Includes total and available. mgmt Displays the router’s management port (10/100) configuration. ntp Displays the router’s network time protocol (NTP) configuration.
A A – Command Reference Commands system Displays router product information including serial number, software version, hardware version, configuration, and temperature. targets [fc or iscsi] Displays targets discovered by the router: FC, iSCSI, or both.
A – Command Reference Commands S Show CHAP Command Displays CHAP configuration. Authority None Syntax show chap Examples Show CHAP command example: QRouter #> show chap The following is a list of iSCSI nodes that have been configured with CHAP 'ENABLED': Type iSCSI Node -------- -----------No entires found.
A A – Command Reference Commands Show FC Command Displays Fibre Channel port information for the specified port. If you do not specify the port, it displays both ports. Authority None Syntax show fc [port_num] Keywords [port_num] The number of the FC port to display.
S A – Command Reference Commands Show FcipRoutes Command Displays FCIP route(s) configuration parameters. Authority None Syntax show fciproutes [link_id] Keywords [link_id] The number of the FCIP route to be displayed (1 or 2).
A A – Command Reference Commands Show Features Command The show features command displays the licensed features that have been enabled on the router.
A – Command Reference Commands S Show Initiators Command Displays SCSI initiator information for iSCSI, FC, or both. Authority None Syntax show initiators fc iscsi Keywords fc Specifies the display of Fibre Channel initiators. iscsi Specifies the display of iSCSI initiators. Examples Show Initiators command example: QRouter #> show initiators Initiator Information ----------------------Initiator Name iqn.1991-05.com.microsoft:qlogic-8qdaqlxt Alias IP Address 10.3.5.130 Portal No.
A A – Command Reference Commands Show iSCSI Command Displays iSCSI information for the specified port. If you do not specify the port, this command displays both ports. Authority None Syntax show iscsi [port_num] Keywords [port_num] The number of the iSCSI port to display. Examples Show iSCSI port command example: QRouter (admin) #> show iscsi iSCSI Port Information -----------------------iSCSI Port 1 Port Status Enabled Link Status Up iSCSI Base Name iqn.2004-08.com.qlogic:isr-6142.
S A – Command Reference Commands IPv6 Link Local fe80::2c0:ddff:fe0c:8be2 IPv6 Default Router :: IPv6 Target TCP Port No. 3260 IPv6 Window Scaling Enabled IPv6 Window Scaling Factor 1 IPv6 VLAN Disabled iSCSI Port 2 Port Status Enabled Link Status Up iSCSI Base Name iqn.2004-08.com.qlogic:isr-6142.0608a00471.1 MAC Address 00-c0-dd-0c-8b-e3 IP Address 0.0.0.0 Subnet Mask 0.0.0.0 Gateway IP Address 0.0.0.0 Firmware Revision No. 3.00.02.44 No.
A A – Command Reference Commands Show iSNS Command Displays iSNS configuration information for the specified iSCSI port. If you do not specify the port, this command displays the iSNS configuration information for both iSCSI ports. Authority None Syntax show isns [port_num] Keywords [port_num] The iSCSI port number whose iSNS configuration you want to display.
S A – Command Reference Commands Show Localmaps Command The show localmaps command displays all local mappings on the router. Local mappings are mappings between initiator and target devices. Authority None Syntax show localmaps Examples Show Localmaps command example: QRouter (admin) #> show localmaps Local Mappings ---------------Initiator iqn.1991-05.com.
A A – Command Reference Commands Show Logs Command Displays the router event log.
A – Command Reference Commands S Show Memory Command Displays the router’s memory usage. If there are no configured FCIP routes, it shows the FCIP memory usage of zero.
A A – Command Reference Commands Show Mgmt Command Displays the router’s management port (10/100) configuration. Authority None Syntax show mgmt Examples Show Mgmt command example: QRouter (admin) #> show mgmt Management Port Information ----------------------------- FI0054601-00 C IPv4 Interface Enabled IPv4 Mode Dhcp IPv4 IP Address 172.17.137.129 IPv4 Subnet Mask 255.255.254.0 IPv4 Gateway 172.17.136.
A – Command Reference Commands S Show NTP Command Displays the router’s network time protocol (NTP) configuration.
A A – Command Reference Commands Show Performance Command Displays router performance data. Authority None Syntax show perf byte init_rbyte init_wbyte tgt_rbyte tgt_wbyte Keywords byte Displays data transfer rate of each port (FC and GE). init_rbyte Displays initiator read transfer rate per port. init_wbyte Displays initiator write transfer rate per port. tgt_rbyte Displays target read transfer rate per port. tgt_wbyte Displays target write transfer rate per port.
A – Command Reference Commands S Show Performance byte command example: QRouter #> show perf byte Displaying bytes/sec (total)...
A A – Command Reference Commands Show Presented Initiators Command Displays initiators presented by the router: FC.
A – Command Reference Commands S Show Presented Targets Command Displays targets presented by the router: FC, iSCSI, or both. Authority None Syntax show presented_targets fc iscsi Keywords fc Specifies the display of FC presented targets. iscsi Specifies the display of iSCSI presented targets.
A A – Command Reference Commands Show Presented iSCSI Targets command example: QRouter #> show presented_targets iscsi Presented Target Information -----------------------------iSCSI Presented Targets ------------------------Name iqn.2000-04.com.qlogic:isr6142:0.50001fe150069d20.50001fe150069d2c IP 10.3.5.66 WWNN 50:00:1f:e1:50:06:9d:20 WWPN 50:00:1f:e1:50:06:9d:2c Name iqn.2000-04.com.qlogic:isr6142:1.50001fe150069d20.50001fe150069d2c IP 10.3.5.
A – Command Reference Commands S Show Properties Command Displays the router’s CLI (command line interface) properties.
A A – Command Reference Commands Show Remotemaps Command Displays all remote maps that have been configured. Authority None Syntax show remotemaps Examples Show Remotemaps command example: QRouter #> show remotemaps Remote Mappings ----------------Local Device 20:01:00:e0:8b:28:5f:3d,21:01:00:e0:8b:28:5f:3d (Initiator) Remote Device 20:00:00:14:c3:3d:d2:bf,22:00:00:14:c3:3d:d2:bf (Target) Local Port FC2 FC1 Remote System iSR-6142.0608A00471(172.17.137.
S A – Command Reference Commands Show Remotepeers Command The show remotepeers commands displays all remote peers. Authority None Syntax show remotepeers Examples Show Remotepeers command example: QRouter #> #> show remotepeers Remote System Information ------------------------Product Name iSR-6142 Symbolic Name Serial Number 0608A00487 HW Version 3 SW Version 2.2.0.4 No. of iSCSI Ports 2 iSCSI Base Name iqn.2004-08.com.qlogic:isr-6142.0608a00487 Mgmt IP Address 172.17.137.
A A – Command Reference Commands Show SNMP Command Displays the router’s simple network management protocol (SNMP) and any configured traps. Authority None Syntax show snmp Examples Show SNMP command example: QRouter #> show snmp SNMP Configuration -----------------Read Community Public Trap Community Private System Location System Contact Authentication traps Disabled System OID 1.3.6.1.4.1.3873.1.5 System Description iSR-6142 Trap Destination 1 -----------------IP Address 10.0.0.
A – Command Reference Commands S Show Stats Command Displays the router statistics: FC and iSCSI.
A A – Command Reference Commands MAC Rcvd Carrier Sense Errors 0 MAC Rcvd Dropped Frames 0 MAC Rcvd CRC Errors 0 MAC Rcvd Encoding Errors 0 MAC Rcvd Length Errors Large 1 MAC Rcvd Small Errors Small 0 MAC Rcvd Multicast Frames 34394 MAC Rcvd Broadcast Frames 33144 iSCSI Port 2 Interrupt Count 51604 Target Command Count 0 Initiator Command Count 0 MAC Xmit Frames 0 MAC Xmit Byte Count 0 MAC Xmit Multicast Frames 0 MAC Xmit Broadcast Frames 0 MAC Xmit Pause Frames 0 MAC Xmit Control Frames 0 MAC Xmit Deferr
A – Command Reference Commands S Unexpected I/O Rcvd 0 iSCSI Format Errors 0 Header Digest Errors 0 Data Digest Errors 0 Sequence Errors 0 PDU Xmit Count 2729500577 PDU Xmit Count 2729500577 PDU Xmit Count 2729500577 IP Xmit Packets 54392134283 IP Xmit Byte Count 59132566295008 IP Xmit Fragments 0 IP Rcvd Packets 42061430681 IP Rcvd Byte Count 58764046068744 IP Rcvd Fragments 0 IP Datagram Reassembly Count 0 IP Error Packets 0 IP Fragment Rcvd Overlap 0 IP Fragment Rcvd Out of Order 0 IP Datagram Reassemb
A A – Command Reference Commands Show System Command Displays router product information including the serial number, software version, hardware version, configuration, and temperature. Authority None Syntax show system Examples Show System command example: QRouter #> show system System Information -------------------Product Name iSR-6142 Symbolic Name FI0054601-00 C Serial Number 0608A00471 HW Version 5 (IPv6 Supported) SW Version 2.4.2.0rc2 No. of FC Ports 2 No.
A – Command Reference Commands S Show Targets Command Displays targets the router discovered: FC, iSCSI, or both. Authority None Syntax show targets fc iscsi Keywords fc Specifies the display of FC targets. iscsi Specifies the display of iSCSI targets. Examples Show FC Targets command example: QRouter #> show targets fc Target Information -------------------WWNN 50:00:1f:e1:50:01:11:50 WWPN 50:00:1f:e1:50:01:11:58 Port ID 01-0d-00 Portal No.
A A – Command Reference Commands Show VLAN Command Displays the router’s VLAN configuration. Authority None Syntax show vlan [port_num] Keywords [port_num] The iSCSI port number whose VLAN configuration you want to display.
A – Command Reference Commands S Shutdown Command The shutdown command provides for an orderly shutdown of the routers firmware. It does not power down the router.
A A – Command Reference Commands Target Command Removes targets from the router’s database. Typically, you can use this command to remove targets from the database that are no longer connected to the router. The target add command is not currently supported. Authority Admin session Syntax target add rm Keywords add Not supported rm Remove a target from the router’s target database. Examples Target add command example: QRouter (admin) #> target add Command 'target add' is currently not supported.
S A – Command Reference Commands Traceroute Command Prints the route a network packet takes to the reach the destination specified by the user. Authority Admin session Syntax traceroute Examples Traceroute command example: A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value. If you wish to terminate this process before reaching the end of the list press 'q' or 'Q' and the ENTER key to do so.
B Log Messages Log Data The router maintains a message log you can retrieve and review using either the command line interface or the SANsurfer Router Manager. The message log is persistent, maintained across router power cycles and reboots. The three log message categories are: Informational Error Fatal The following sections describe the log message categories. Informational Log Messages The following sections list and describe the informational log messages by reporting module.
S B – Log Messages Informational Log Messages Table B-1. Application Modules—Informational Log Messages (Continued) ID B-2 Log Message No. 54306 QLFC_Logout: Origin 0x%x, VP Index 0x%x, Id 0x%x 1058 54307 QLFC_Logout: Port ID %.2x%.2x%.2x 1059 54308 QLFC_Logout: Node Name %.2x%.2x%.2x%.2x%.2x%.2x%.2x%.2x 1060 54309 QLFC_Logout: Port Name %.2x%.2x%.2x%.2x%.2x%.2x%.2x%.2x 1061 54359 QLFC_HandleTeb: FC Login.
A FI0054601-00 C B – Log Messages Informational Log Messages 1028 FC login occurred with WWNN xx.xx.xx.xx.xx.xx.xx.xx. 1029 FC login occurred with WWPN xx.xx.xx.xx.xx.xx.xx.xx. 1058 FC logout occurred, origin xx (1 = HBA, 2 = target, 3 = initiator), VP (virtual port) xx, ID (loop ID) x. 1059 FC logout occurred with port ID xx.xx.xx. 1060 FC logout occurred with WWNN xx.xx.xx.xx.xx.xx.xx.xx. 1061 FC logout occurred with WWPN xx.xx.xx.xx.xx.xx.xx.xx.
S B – Log Messages Informational Log Messages iSCSI Driver The following informational log messages are common to both iSCSI ports: 1 (GE1) and 2 (GE2). The messages are listed in Table B-2 and described following the table. Log messages beginning with #0 denote iSCSI port 1 (GE1) and log messages beginning with #1 denote iSCSI port 2 (GE2). Table B-2. iSCSI Driver—Informational Log Messages ID B-4 Log Message No.
A B – Log Messages Informational Log Messages Fibre Channel Driver The following informational log messages are common to both Fibre Channel ports: 1 (FC1) and 2 (FC2). The messages are listed in Table B-3 and described following the table. Log messages beginning with #0 denote fibre channel port 1 (FC1). Log messages beginning with #1 denote fibre channel port 2 (FC2). Table B-3. Fibre Channel Driver—Informational Log Messages ID FI0054601-00 C Log Message No.
S B – Log Messages Informational Log Messages 768 FCIP - Fibre Channel link up occurred. Event status is reported, as is the contents of the FC processor’s mailbox 1 register. 769 FCIP - Fibre Channel link down occurred. 770 FCIP - Fibre Channel link up occurred. Event status is reported, as is the RunTimeMode (0 = loop, 1 = point-to-point). User Modules The user modules generate the log messages listed in Table B-4 and described in the following table. Table B-4.
A B – Log Messages Informational Log Messages Table B-4. User Modules—Informational Log Messages (Continued) FI0054601-00 C ID Log Message No. 151903 qapimaptargettoinitiator_1_svc: Localmap added to target device %.2x:%.2x:%.2x:%.2x:%.2x:%.2x:%.2x:%.2x 351 151904 qapiunmaptargettoinitiator_1_svc: Localmap removed for initiator device %.2x:%.2x:%.2x:%.2x:%.2x:%.2x:%.2x:%.2x 352 151905 qapiunmaptargettoinitiator_1_svc: Localmap removed to target device %.2x:%.2x:%.2x:%.2x:%.2x:%.2x:%.2x:%.
S B – Log Messages Informational Log Messages 348 Remotemap removed for local FC device WWPN xx.xx.xx.xx.xx.xx.xx.xx. 349 Remotemap removed for remote FC device WWPN xx.xx.xx.xx.xx.xx.xx.xx. 350 Localmap added for FC initiator WWPN xx.xx.xx.xx.xx.xx.xx.xx. 351 Localmap added to FC target device WWPN xx.xx.xx.xx.xx.xx.xx.xx. 352 Localmap removed for FC initiator. 353 Localmap removed to FC target device. 354 Localmap added for iSCSI initiator "iqn.dddd-dd.ttt.ttt.ttt.......".
A B – Log Messages Informational Log Messages TOE Driver The TOE driver generates the informational log messages listed in Table B-6 and described following the table. Table B-6. TOE—Informational Log Messages ID 217350 262 Log Message QL3022:eth%x: Interface is down No. 262 The GigE interface d (0 or 1) used for an FCIP route is down. System The system modules generate the informational log messages listed in Table B-7 and described following the table. Table B-7.
S B – Log Messages Error Log Messages Error Log Messages The following sections list and describe the error log messages by reporting module. Application Modules The application modules generate the error log messages listed in Table B-8 and described following the table. Table B-8. Application Module—Error Log Messages ID B-10 Log Message No.
A B – Log Messages Error Log Messages Table B-8. Application Module—Error Log Messages (Continued) FI0054601-00 C ID Log Message No.
S B – Log Messages Error Log Messages Table B-8. Application Module—Error Log Messages (Continued) ID B-12 Log Message No. 42024 QLFC_Logout: No active path to device. WWPN: %.2X%.2X%.2X%.2X%.2X%.2X%.2X%.
A B – Log Messages Error Log Messages Table B-8. Application Module—Error Log Messages (Continued) ID FI0054601-00 C Log Message No.
S B – Log Messages Error Log Messages B-14 98 Unable to create an object for the target device: exceeded the maximum number of target devices. 100 Unable to create an object for the target node: exceeded the maximum number of target devices. 107 Memory unavailable for LUN object. 117 Unable to create an object for initiator object: exceeded the maximum number of initiators. 136 Process control block status indicates that a PCI error occurred during a target operation.
A FI0054601-00 C B – Log Messages Error Log Messages 324 iSCSI Login PDU was received with an invalid TSIH value. The TSIH is invalid because there is no session with that TSIH value. This would occur if the iSCSI initiator attempting the login failed to used the TSIH value provided in the target login response PDU (router is target) in subsequent login PDUs. 393 CHAP validation failed during login. 394 Unexpected CHAP key.
S B – Log Messages Error Log Messages B-16 1042 Attempting login but Fibre Channel connection cannot be opened. 1064 Attempting logout of device for which there is no active path (WWPN not found). 1067 Logout attempted using Fibre Channel VP index that has not been configured. Operation attempted on an unconfigured VP. 1108 Event notification: Fibre Channel processor encountered a system error (unrecoverable firmware error).
A FI0054601-00 C B – Log Messages Error Log Messages 2320 FCIP handle Teb: Driver Fatal error. 2321 FCIP configure portal: Find portal object failed for QLUT_TYPE_FC, PortId (%d). 2322 FCIP configure portal: QLFCIP_ConfigPortal: Invalid PortId for FCIP link PortID(%d). 2323 FCIP allocate TRB pool: Allocation failed (size 0x%x). 2324 FCIP Trb: Null portal object in map table. 2325 FCIP eet TRB: Null portal object in map table. 2326 FCIP get TRB: Duplicate allocation of FcipTrb (0x%p).
S B – Log Messages Error Log Messages iSCSI Driver The following error log messages are common to both iSCSI ports, 1 (GE1) and 2 (GE2). They are listed in Table B-9 and described following the table. Log messages beginning with #0 denote iSCSI port 1 (GE1). Log messages beginning with #1 denote iSCSI port 2 (GE2). Table B-9. iSCSI Driver—Error Log Messages ID B-18 Log Message No.
A FI0054601-00 C B – Log Messages Error Log Messages 329 The iSCSI processor failed the external loopback test. 337 The iSCSI processor command to disable a GE port failed. 513 The iSCSI processor could not connect with the iSCSI name server (iSNS). 849 The iSCSI processor reported that the iSCSI port NVRAM contains invalid data (checksum error). 859 The iSCSI processor reported a link down condition.
S B – Log Messages Error Log Messages Fibre Channel Driver The following error log messages are common to both Fibre Channel ports, 1 (FC1) and 2 (FC2). They are listed in Table B-10 and described in this section. Log messages beginning with #0 denote fibre channel port 1 (FC1) and log messages beginning with #1 denote fibre channel port 2 (FC2). Table B-10. Fibre Channel Driver—Error Log Messages B-20 ID Log Messages No.
A B – Log Messages Error Log Messages Table B-10. Fibre Channel Driver—Error Log Messages (Continued) ID FI0054601-00 C Log Messages No. 107254 #%d: QLUpdateSinglePortCont 0x%x: out of slots in host database 758 107267 #%d: QLFcipIsrEventHandler: System error event (%x), MB1=%x, MB2=%x, MB3=%x, MB4=%x, MB5=%x, MB6=%x, MB7=%x 771 87 The FC processor received a SCSI command for an unknown target path or has run out of resources to execute additional commands.
S B – Log Messages Error Log Messages 582 The drivers host (initiator) database is full. 758 No slots available in host database. 771 FCIP system error event. User Modules The user modules generate the error log messages listed in Table B-11 and described following the table. Table B-11. User Modules—Error Log Messages ID B-22 Log Message No.
A B – Log Messages Error Log Messages Table B-11. User Modules—Error Log Messages (Continued) ID FI0054601-00 C Log Message No.
S B – Log Messages Error Log Messages B-24 21 Failed memory allocation for Get LUN List API. 22 Failed memory allocation for Get Presented Targets List API. 23 Failed memory allocation for Get LUN Mask API. 24 Failed memory allocation for Initiator API. 25 Failed memory allocation for Target Device API. 32 Failed memory allocation for FC Target API. 33 Failed memory allocation for System Status API. 34 Failed memory allocation for Diagnostic API.
A B – Log Messages Fatal Log Messages System The system modules generate the error log messages listed in Table B-12 and described following the table. Table B-12. System—Error Log Messages ID Log Message No. 237572 "Failed to kill sys killer %d\n" 4 237573 "Temperature over high threshold %d\n" 5 4 Failed to kill system task. 5 Reporting router exceeds maximum operating temperature. Fatal Log Messages The following sections list and describe the fatal log messages by reporting module.
S B – Log Messages Fatal Log Messages Table B-13. iSCSI Driver—Fatal Log Messages (Continued) B-26 ID Log Message No. 69964 #%d: QLDisable: QLRebootTimer failed AF %x RS %x Time %d 332 69966 #%d: QLEnable: QLRebootTimer failed AF %x RS %x Time %d 334 70224 #%d: QLProcSrblessiSNSResponse: Invalid handle %x 592 70400 #%d: QLInitializeDevice: QLStartAdapter failed 768 70417 #%d: QLInitializeAdapter: QLInitializeFW failed 785 70432 #%d: QLDoInterruptServiceRoutine: PortFatal interrupt.
A FI0054601-00 C B – Log Messages Fatal Log Messages 20 iSCSI processor SRAM test failed. 21 iSCSI processor failed diagnostic reboot. 22 iSCSI processor failed NVRAM diagnostic. 23 iSCSI processor failed DRAM diagnostic. 24 iSCSI processor failed to return diagnostic results. 309 Response queue entry contains an invalid handle. 319 Set NVRAM reboot timer failed. 332 Port disable reboot timer failed. 334 Port enable reboot timer failed. 592 iSNS response contains an invalid handle.
S B – Log Messages Fatal Log Messages FC Driver The following fatal log messages are common to both Fibre Channel ports, 1 (FC1) and 2 (FC2). They are listed in Table B-14 and described following the table. Log messages beginning with #0 denote fibre channel port 1 (FC1). Log messages beginning with #1 denote fibre channel port 2 (FC2). Table B-14. Fibre Channel Driver—Fatal Log Messages ID B-28 Log Message No.
A B – Log Messages Fatal Log Messages Table B-14. Fibre Channel Driver—Fatal Log Messages (Continued) FI0054601-00 C ID Log Message No. 102749 #%d: QLProcessResponseQueueFS: Invalid handle 0x%x, type 0x%x 349 102752 #%d: QLTimer: Ext Ram parity error exceed limit cnt 0x%x, limit 0x%x, Disabled adapter 352 102755 #%d: QLTimer: Heartbeat failed 355 102800 #%d: QLRestartRisc: restart RISC 400 19 FC1 processor SRAM test failed. 20 FC1 processor power-on self-test (POST) failed.
S B – Log Messages Fatal Log Messages 352 FC processor external SRAM parity error count exceeded limit: FC port disabled. 355 FC processor heartbeat failed. 400 FC processor being restarted. TOE Driver The TOE driver generates the fatal log messages listed in Table B-15 and described following the table. Table B-15. TOE—Fatal Log Messages ID B-30 Log Message No. 200721 QL3022:ql3xxx_probe: Adapter eth#%d, Invalid NVRAM parameters 17 200725 QL3022:eth%x: Resetting chip.
A B – Log Messages Fatal Log Messages System The system modules generate the fatal log messages listed in Table B-16 and described following the table. Table B-16. System—Fatal Log Messages FI0054601-00 C ID Log Message No. 233473 "memory monitor: Detected Uncorrectable Ecc %08lx system is rebooting in 5 secs\n" 1 233474 "Failed to register interrupt handler!\n" 2 233475 "%s class_simple_create failed\n" 3 1 Uncorrectable memory error detected at address provided in log message.
B – Log Messages Fatal Log Messages S Notes B-32 FI0054601-00 C
C Configuring CHAP CHAP Definition In challenge handshake authentication protocol (CHAP), the authentication agent sends the client program a random value that is used only once and an ID value. Both the sender and peer share a predefined secret. The peer concatenates the random value, the ID, and the secret, and calculates a one-way hash using MD5 (Message-Digest algorithm 5).
S C – Configuring CHAP Configuring CHAP Using CLI a. Click General. b. Click Secret (in the middle of the screen). If this is the first time you are setting secrets, reset all secrets. c. Type the secret (secret_port) that you created in Step 1. 4. Click Discovery. 5. Click Add. 6. Type the address of the iSCSI port of the router. 7. Click Advanced. 8. Select Chap Login Information. 9. Type the secret (secret_initiator) you created in Step 2 into Target Secret. 10.
A C – Configuring CHAP Configuring CHAP Using CLI CLI—Normal Session—Bi-directional CHAP To configure a bi-directional CHAP used during a normal session: 1. 2. 3. On the router a. Enable CHAP on the presented target to which the initiator will login. b. Create a secret (for example, secret_target). c. Use Set CHAP. Use Initiator add to add the initiator that is about to do a normal login: a. Enable the CHAP for this initiator. b. Create a secret (for example, secret_initiator). c.
S C – Configuring CHAP Configuring CHAP Using the GUI CLI—Normal Session—Uni-directional CHAP To configure single-direction CHAP to be used during a normal session: 1. Do not enable CHAP on the presented target. 2. Use Initiator add: a. Add the initiator that is about to do a normal login. b. Enable the CHAP for this initiator. c. Create a secret (for example, secret_initiator). d. Use Set Chap to update the CHAP settings of the initiator. 3. Go to the MS Initiator. 4. Click Targets. 5.
A C – Configuring CHAP Configuring CHAP Using the GUI 8. Select Enable CHAP. 9. Create a CHAP secret (for example, secret_initiator). 10. Go to the MS Initiator and perform the following steps: a. Click General. b. Click Secret (in the middle of the screen). c. If this is the first time you are setting secrets, reset all secrets. d. Type the CHAP secret (secret_port) that you created in Step 5. 11. Click Discovery. 12. Click Add. 13. Enter the address of the iSCSI port of the bridge.
S C – Configuring CHAP Configuring CHAP Using the GUI d. Click Advanced. e. Click Chap Login Information. f. Type the secret (secret_initiator) you created in Step 5 into Target Secret. 7. Click OK. 8. Click OK. The initiator completes discovery. GUI—Normal Session—Bi-directional CHAP To program bi-directional CHAP during a normal session: C-6 1. On the bridge, enable CHAP for the iSCSI presented target. 2. Select the presented target on the left column of the SANsurfer Router Manager. 3.
A C – Configuring CHAP Configuring CHAP Using the GUI 16. Type the secret (secret_initiator) that you created in Step 9 into Target Secret. 17. Select Mutual Authentication. 18. Click OK. 19. Click OK. The initiator completes normal login. GUI—Normal Session—Uni-directional CHAP To program single-direction CHAP during a normal session: 1. Do not enable CHAP on the iSCSI presented target. 2.
C – Configuring CHAP Configuring CHAP Using the GUI S Notes C-8 FI0054601-00 C
D Simple Network Management Protocol (SNMP) Introduction Simple network management protocol (SNMP) provides monitoring and trap functions for managing the router through third-party applications that support SNMP. The router firmware supports SNMP versions 1 and 2 and a QLogic Management Information Base (MIB). You may format the traps using SNMP version 1 or 2 (See Notifications).
S D – Simple Network Management Protocol (SNMP) Introduction Table D-1. SNMP Properties (Continued) Parameter Description System contact Specifies the name of the person to be contacted to respond to trap events. The name can be up to 64 characters excluding the number sign (#), semicolon (;), and comma (,). The default is undefined. Authentication traps Enables or disables authentication trap generation in response to authentication failures. The default is disabled.
A D – Simple Network Management Protocol (SNMP) Management Information Base (MIB) Management Information Base (MIB) The following sections describe the QLogic management information base (MIB). The MIB consists of four object groups: System Information Network Port Table Fibre Channel Port Table Fibre Channel Port Table System Information The system information objects provide the system serial number, version numbers (hardware/software/agent), and number of ports (FC/GE).
S D – Simple Network Management Protocol (SNMP) Management Information Base (MIB) qsrNoOfGbEPorts Syntax Unsigned32 Access Read-only Description The number of gigabit Ethernet ports on the system. qsrAgentVersion Syntax SnmpAdminString Access Read only Description The version number of the agent software on the system. Network Port Table The network port table contains a list of network ports that are operational on the router.
A D – Simple Network Management Protocol (SNMP) Management Information Base (MIB) qsrNetMask InetAddress qsrGateway InetAddress qsrMacAddress MacAddress qsrNwLinkStatus QsrLinkStatus qsrNwLinkRate QsrLinkRate qsrNwPortRole Syntax QsrPortRole Access Not accessible Description The operational role of this port: management port, iSCSI port, a TOE. qsrNwPortIndex Syntax Unsigned32 Access Not accessible Description A positive integer indexing each network port in a given role.
D – Simple Network Management Protocol (SNMP) Management Information Base (MIB) S qsrNetMask Syntax InetAddress Access Read only Description The subnet mask for this port. qsrGateway Syntax InetAddress Access Read only Description The gateway for this port. qsrMacAddress Syntax IMacAddress Access Read only Description The MAC address for this port. qstNwLinkStatus Syntax QsrLinkStatus Access Read only Description The operational link status for this port.
A D – Simple Network Management Protocol (SNMP) Management Information Base (MIB) qsrFcPortEntry Syntax QsrFcPortEntry Access Not accessible Description Each entry (row) contains information about a specific FC port.
D – Simple Network Management Protocol (SNMP) Management Information Base (MIB) S qsrFcPortWwn Syntax PhysAddress Access Read only Description The world wide name for this port. qsrFcPortId Syntax PhysAddress Access Read only Description The interface's 24-bit FC address identifier. qsrFcPortType Syntax Unsigned32 Access Read only Description The type of FC port, as indicated by the use of the appropriate value assigned by IANA. The IANA-maintained registry for FC port types can be found at: www.iana.
A D – Simple Network Management Protocol (SNMP) Management Information Base (MIB) qsrSensorEntry Syntax QsrSensorEntry Access Not accessible Description Each entry (row) corresponds to a single sensor.
D – Simple Network Management Protocol (SNMP) Management Information Base (MIB) S qsrSensorValue Syntax Integer32 Access Read only Description The current value of the sensor. qsrUpperThreshold Syntax Integer32 Access Read only Description The upper-level threshold for this sensor. qsrLowerThreshold Syntax Integer32 Access Read only Description The lower-level threshold for this sensor.
A D – Simple Network Management Protocol (SNMP) Notifications Notifications The router provides the following notification types: Notification Objects Agent Start Up Notification Agent Shut Down Notification Network Port Down Notification Fibre Channel Port Down Notification Sensor Notification Generic Notification The following sections describe these notifications and objects they use. Notification Objects This section defines the objects used in notifications.
D – Simple Network Management Protocol (SNMP) Notifications S qsrAgentStartup uses the following object: qsrEventTimeStamp Agent Shut Down Notification The agent shut down notification indicates that the agent on the router is shutting down. qsrAgentShutdown uses the following object: qsrEventTimeStamp Network Port Down Notification The network port down notification indicates that the specified network port is down.
A D – Simple Network Management Protocol (SNMP) Notifications Generic Notification The generic notification reports events other than the defined event types. It provides a description object that identifies the event in clear text.
D – Simple Network Management Protocol (SNMP) Notifications S Notes D-14 FI0054601-00 C
