User guide

IMPORTANT! Confirm that the tip is locked firmly in place before proceeding.
Keep out
of sunlight
321
4
1
Plunger
2
UV-Activated Chip Sealant Syringe
3
Chip Sealant Tip (twist to attach)
4
Brown plastic bag (do not discard)
3.
Prepare a syringe containing
Immersion Fluid:
a.
Remove the syringe, plunger, and tip from the packaging.
b.
Before uncapping the syringe, gently pull back the plunger 1-2 mm and
release it to break any resistance that may have formed during storage.
c.
Unscrew the cap from the syringe, then attach the Immersion Fluid Tip by
pushing it into place.
IMPORTANT! The application of the
Immersion Fluid Tip requires force.
No twisting or screwing is required to attach it.
d.
Carefully depress the plunger until
Immersion Fluid flows from the tip of
the assembled syringe, then place it on a clean surface until ready for use.
IMPORTANT! Confirm that the tip is locked firmly in place before proceeding.
IMPORTANT! Open only one syringe at a time. Use all of the Immersion Fluid
within 60 minutes of uncapping the syringe. Once a syringe is opened, you
cannot reattach the cap for later use.
21 3 4
<1 hour
1
Immersion Fluid Syringe
2
Cap (remove)
3
Immersion Fluid Tip (push to attach)
4
Low-lint wipe
Chapter 2 Prepare Samples and Load Reactions
Load the chips using the Chip Loader
2
