For more information, visit our website at:
QUIETCOOLSYSTEMS.COM
QC CL-4700
QuietCool Original Classic Line
QC CL-4700 Specifications
120 VAC, 60 Hz
Hi: 551 Watts / Low: 415 Watts
Hi: 4415 CFM / Low: 3402 CFM
Covers up to 2210 SQ FT
2
18”
9 feet
18 1/2”
13 1/2”
Barometric Pressurized R5 Dampers
Recommended 8 Hour Electronic Timer (IT-30070) and
HI-LOW-OFF Switch (IT-35000)
10 Years
None Required
None Required; fits 16” or 24” on center
5.89 SQ FT net free area
14 1/4” x 30 1/4”
16” x 32”
75 lbs.
36” x 22” x 40”
-QC CL-4700 Motorhead -Damper Box
-Ceiling Grille -9 Foot Duct
-Cut-out Template -Accessory Bag
-Window Locks
Motor Voltage
Energy Use
Air Flow
Recommended SQFT Coverage @ 2 CFM per SQ FT
# of Speeds
Duct Diameter
Duct Length
Motor Head Diameter
Motor Head Length
Dampers
Controls (Not Included)
Warranty
Framing
Joist Cutting
Minimum Suggested Attic Venting
Ceiling Rough Opening
Removable Grille Outside Dimension
Shipping Weight
Box Dimensions
In The Box
