Specification

For more information, visit our website at:
QUIETCOOLSYSTEMS.COM
QC ES-3100
QuietCool Energy Saver Line
QC ES-3100 Specications
Hi: 3,081 CFM / Low: 2,020 CFM
Hi: 2,400 CFM / Low: 1,500 CFM
Covers 1,027 SQFT to 1,541 SQFT
Hi: 285 Watts / Low: 80.8 Watts
Hi: 3.68 / Low: 1.14
120 VAC, 60 Hz
2
Hi: 47.4 / Low: 33.0
34”
16”
6 feet
16 1/2”
13 1/2”
Barometric Pressurized R5 Dampers
Recommended: IT-36002 QuietCool RF Wireless
Control Kit
10 Years
None Required
None Required; ts 16” or 24” on center
4.11 SQ FT net free area
14 1/4” x 22 1/4”
16” x 24”
56 lbs.
27” x 20” x 38”
Air Flow
HVI-916 Airow (for CA Title 24 New Construction)
Recommended SQFT Coverage @ 2-3 CFM per SQFT
Energy Use
Amps
Motor Voltage
# of Speeds
dBA
Minimum Attic Clearance
Duct Diameter
Duct Length
Motor Head Diameter
Motor Head Length
Dampers
Controls (Sold Separately)
Warranty
Framing
Joist Cutting
Minimum Suggested Attic Venting
Ceiling Rough Opening
Removable Grille Outside Dimension
Shipping Weight
Box Dimensions
In The Box
-QC ES-3100 Motorhead
-Ceiling Grille
-Cut-out Template
-Window Locks
-Damper Box
-6 Foot Duct
-Accessory Bag
