Installation Sheet

1of2
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
Assembly Instruction Sheet #IS-REG1716VG
For Style REG1716VG
Pleasegoto forproductcleaningtips.Gotothe selection.
(4)B10CandelabraBaseBulbs60WMaximum
30-45minutes
Identifyandinspectallpartsbeforebeginninginstallation.Checkpackagecontentlistanddiagramsbelowtobesureallpartsare
present.Ifanypartsaremissingordamaged,donotattempttoassemble,install,oroperatethefixture.Contactcustomerserviceforreplacement
parts.
www.quoizel.com Care+Maintenance
LightSource:
EstimatedAssemblyTime:
Preparation:
ToolsRequired: Flathead screwdriver,Phillipsscrewdriver,pliers,wirecutters,wirestrippers,electricaltape,safetyglasses.
Warnings and Cautions
Turn off electricity at circuit breaker or main fuse box before installation. Consult a licensed electrician if in doubt.
These instructions are provided for your safety. It is very important you read them completely before installing the fixture. We strongly
recommend that a licensed, professional electrician perform the installation.
Disconnect fixture from power source before replacing bulbs. Make sure bulbs are given sufficient time to cool before removal.
Package Contents
A
Crossbar Assembly
x1
Thank you forpurchasing a Quoizelproduct.
Need assistance withparts or assembly?Call Quoizel customerservice at 1-800-645-3184
or visit us on-line at www.quoizel.com
Fixture
Body
x1
2017 QuoizelInc.
ReleasedDate:2017-08-14
B
C
Bead String
x4
D
Crystal
Drop A
x8
E
Crystal
Drop B
x1
STEP 1 - Installing the Crossbar Assembly
A. Pass the supply wires from outlet box through the Crossbar
Assembly (A). Attach the Crossbar Assembly (A) to the Outlet Box
with the head of the Green Ground Screw facing you. Secure the
Crossbar Assembly (A) with Outlet Box Screws (not included).
Tighten until snug.
Supply Wires with
Ground Wire
Outlet Box Screws
(not included)
Outlet Box
A
Figure 1
STEP 3 Test Fitting Ceiling
Canopy to Crossbar Assembly
-
A.
eiling canopy
to the
ceiling
Remove mounting balls from
the Crossbar Assembly (A).
Fit the c and
Fixture Body (B)
Crossbar Assembly (A) and
secure with mounting balls.
Note: The
should be snug against the
and the mounting
balls. If
ceiling canopy
not, adjust the length
Mounting
Screw
Hex Nut and
Lock Washer
Mounting
Ball
A
B
Ceiling
Canopy
Figure 2
(Step 2 Continued)
of the nipple on the Crossbar Assembly (A) by unscrewing the
preassembled hex nut and lock washer and then screwing the
mounting screws in or out of the crossbar until the correct length is
achieved. Once the ceiling canopy and Fixture Body (B) is secure,
remove the mounting ball and ceiling canopy and Fixture Body (B)
and proceed to Step 3.
STEP 3 - Wire Connections
A. Use standard wire connectors (not included) to make all wire
connections. Twist connectors until wires are tightly joined together.
Wrap each connection with approved electrical tape and carefully
stuff all the connected wires into the Outlet Box.
Figure 3
White wire
from outlet box
White wire
from fixture
Black wire from
outlet box (or Red)
Black wire
from fixture
Bare, or Green
Ground wire
from outlet box
Ground wire
from fixture
Bare, or Green
Ground wire
from outlet box
OR
Ground wire
from fixture
Green Ground Screw
on the Crossbar
STEP 4 Install the Fixture-
A. Carefully tuck all wires into the outlet box and position the ceiling
canopy and Fixture Body (B) over the outlet box. Align the holes in
the ceiling canopy with the mounting screws, then attach the ceiling
canopy and Fixture Body (B) using the previously removed
mounting balls. Hand tighten until snug.
Mounting Screw
Mounting Ball
A
B
Ceiling Canopy
Figure 4
