SERIES II I&M MANUAL/EN/

18/20

This document and the information contained herein, is the exclusive property of R&M Materials Handling, Inc., and represents a non-public, confidential and proprietary trade secret

that may not be reproduced, disclosed to third parties, altered or otherwise employed in any manner whatsoever without the express written consent of R&M Materials Handling, Inc.

Table 5. Spare Parts List

Item Description Capacity Part Number Quantity

1 Hand chain wheel cover ¼ ton [250 kg] 52308656 1

1 Hand chain wheel cover ½ ton [500 kg] 52308657 1

1 Hand chain wheel cover 1 ton [1000 kg] 52308658 1

1 Hand chain wheel cover 1-½ ton [1500 kg] 52308659 1

1 Hand chain wheel cover 2 ton [2000 kg] 52308718 1

1 Hand chain wheel cover 3 ton [3000 kg] 52308719 1

1 Hand chain wheel cover 5 ton [5000 kg] 52308660 1

1 Hand chain wheel cover 7-½ ton [7500 kg] 52308660 1

1 Hand chain wheel cover 10 ton [10000 kg] 52308660 1

2A Hand chain wheel without overload device ¼ ton [250 kg] 1

2B Hand chain wheel with overload device > ¼ ton [250 kg] 1

3 Brake cover 1

4 Friction disc ¼ ton [250 kg] 52308624 2

4 Friction disc ½ ton [500 kg] 52308625 2

4 Friction disc 1 ton [1000 kg] 52308626 2

4 Friction disc 1-½ ton [1500 kg] 52308627 2

4 Friction disc 2 ton [2000 kg] 52308712 2

4 Friction disc 3 ton [3000 kg] 52308713 2

4 Friction disc 5 ton [5000 kg] 52308629 2

5 Ratchet gear ¼ ton [250 kg] 52308630 1

5 Ratchet gear ½ ton [500 kg] 52308632 1

5 Ratchet gear 1 ton [1000 kg] 52308633 1

5 Ratchet gear 1-½ ton [1500 kg] 52308634 1

5 Ratchet gear 2 ton [2000 kg] 52308716 1

5 Ratchet gear 3 ton [3000 kg] 52308717 1

5 Ratchet gear 5 ton [5000 kg] 52308635 1

5 Ratchet gear 7 ½ ton [7500kg] 52308635 1

5 Ratchet gear 10 ton [10000kg] 52308635 1

6 Brake plate ¼ ton [250 kg] 52308666 1

6 Brake plate ½ ton [500 kg] 52308667 1

6 Brake plate 1 ton [1000 kg] 52308668 1

6 Brake plate 1-½ ton [1500 kg] 52308669 1

6 Brake plate 2 ton [2000 kg] 52308714 1

6 Brake plate 3 ton [3000 kg] 52308715 1

6 Brake plate 5 ton [5000 kg] 52308670 1

6 Brake plate 7 ½ ton [7500 kg] 52308670 1

6 Brake plate 10 ton [10000 kg] 52308670 1

7 Position plate 1

8 Shaft 1

9 Side plate A assembly 1

10 Load chain wheel 1

11 Side plate B assembly 1

12 Gear with center spline 1

13 Drive shaft assembly 1

14 Shaft 1

15 Gear cover ¼ ton [250 kg] 52308661 1

15 Gear cover ½ ton [500 kg] 52308662 1

15 Gear cover 1 ton [1000 kg] 52308663 1

15 Gear cover 1-½ ton [1500 kg] 52308664 1
