Publication No. 980935 Rev. M 3152B User Manual
Astronics Test Systems Programming Reference 5-21
Table 5-2, 3152B SCPI Command Summary (continued)
Keyword Parameter Form Default 3152A HS
Synchronization Commands (continued)
[:SOURce]
:PHASe2 (=PLL)
:LOCK
[:STATe] OFF | ON | 0 | 1 0
0920A
:SOURce EXTernal | ECLTrg 0| TTLTrg<n> EXT
0930A
:ADJust -180 to 180 0
0900A
:FINe -36 to 36 0
0910A
LXI Configuration Commands
:SYSTem
:IP
[:ADDRess] <IP_address> 0167A
:MASK <mask> 0171A
:GATeway <gate_way> 0169A
:BOOTp OFF | ON | 0 | 1 0 0168A
HOSTname: <host_name> 0170A
:KEEPalive
:STATe OFF | ON | 0 | 1 1 0173A
:TIMEout 2 to 300 45 0174A
:PROBes 2 to 10 2 0172A
USB Mass Memory Commands
: :MMEMory
:CATalog?
:CDIRectory <directory_name>
:DELete? <file_name>
:LOAD
:TRACe? <label>,<file_name>
System Commands
:RESet
14200
:SYSTem
:ERRor?
1430@
:VERSion?
1440@
:INFOrmation
:CALibration? 0175A
:MODel? 0176@
:SERial? 0177A
:SMEMory
:MODe READ | WRITe READ
1200A
[:STATe] OFF | ON | 0 | 1 0
1210A
:TEST
[:ALL]?
1400@?
