Publication No. 980935 Rev. M 3152B User Manual
Astronics Test Systems Programming Reference 5-47
PULSe:DELay <delay>(?)
HS Syntax: 0730A<float>(
?)
Description
Programs delay of the standard pulse waveform.
Parameters
Name
Range
Type
Default
Description
<delay>
0 to
99.999
Numeric
10
Programs the pulse delay parameter in units of percent
.
Response
The 3152B returns the current pulse delay value.
PULSe:WIDTh <pulse_width>(?)
HS Syntax: 0731A<float>(?)
Description
Programs pulse high portion of the standard pulse waveform.
Parameters
Name
Range
Type
Default
Description
<pulse_width>
0 to
99.999
Numeric
10
Programs the pulse width p
arameter in units of percent.
Response
The 3152B returns the current width value.
PULSe:TRANsition <rise>(?)
HS Syntax: 0732A<float>(?)
Description
Programs pulse transition from low to high of the standard pulse waveform.
Parameters
Name
Range
Type
Default
Description
<rise>
0 to
99.999
Numeric
10
Programs the pulse rise time parameter in units of
percent
.
Response
The 3152B returns the current rise time value.
PULSe:TRANsition:TRAiling <fall>(?)
HS Syntax: 0733A<float>(?)
Description
Programs the pulse transition time from high to low for the standard pulse waveform.
