3152B User Manual Publication No. 980935 Rev. M
5-56 Programming Reference Astronics Test Systems
<segment
>
number>
1 to 10k
Numeric
(integer only)
1
Selects the segment number of which will be deleted
.
TRACe:DELete:ALL
HS Syntax:
10210
Description
This command
deletes all waveform memory segments and clears
the entire waveform memory. This
command is
useful for the memory management of arbitrary waveforms.
TIP
The TRAC:DEL:ALL command does not re-write the memory so, whatever
waveforms were downloaded to the memory are still there for recovery. The
TRAC:DEL:ALL command removes all stop bits and clears the segment table. You
can recover memory segments using the TRAC:DEF command. You can also use
this technique to re-size or to combine waveform segments.
TRACe:SELect <segment_number>
HS Syntax:
1030A<integer>
Description
This command
selects the active waveform segment to be
output. By selecting the active segment you are
performing two function:
1. The TRACe:DEF command applies to the selected segment
2. The SYNC output is assigned to the selected segment. This is critical when using sequenced mode,
where multiple segments form a large sequence. TRACE:SEL allows you to
synchronize external
devices to the segment of interest.
Parameters
Name
Range
Type
Default
Description
<segment_
number>
1 to 1
6k
Numeric
(integer only)
1
Selects the active segmen
t number.
Response
The
3152B returns the active segment number.
SEGment# <header><binary_block>
HS Syntax:
10501#<string>
Description
This command
partitions the waveform memory into smaller segments.
The principle is the same as when
using the TRACE:DEF command, but this is a more efficient implementation for when a large number of
segments need to be defined. The idea is that waveform segments can be built as one long waveform and
then
split into the required number of segments by using this command to
download a binary table of segment
sizes. \When using this method there is no need to define and download waveforms to individual segments.
