User Manual RKP215 / 217 / 219-S801 / 1601 2U 15” / 17” / 19” Rackmount LCD Keyboard Drawer with USB KVM Switch
RKP215 / RKP217 / RKP219 User Manual 1. Table Of Content 1. Table of Content 2. Read Before Installation 3. Introduction 4. Features 5. Package Contents 6. Optional Accessories 7. Peripheral Products 8. Important Safeguards 9. Structure Diagram 10. Dimension Diagram P.1 P.2 P.3 P.3 P.4 P.5 P.5 P.6 P.7 P.8 P.9 P.10 RKP215-S8/1601 RKP217-S8/1601 RKP219-S8/1601 11. LCD Session LCD Membrane Diagram LCD OSD Control P.12 P.12 P.13-14 Main Menu Sub Menu Resolution Settings P.15 For Windows 12.
RKP215 / RKP217 / RKP219 User Manual 2. Read Before Installation Technical Notes For Windows 98/98 SE systems ● HID (Human Interface Device) driver must be installed prior to using the USB KVM switch. To install the HID driver, first connect a USB keyboard and mice directly to computer (before installing KVM switch) then follow the Windows installation instructions, this will install the HID device driver and allow the use of the KVM switch.
RKP215 / RKP217 / RKP219 User Manual 3. Introduction RKP Series is a combination of keyboard, mouse and monitor into a drawer, with features such as flip-up design, adjustable brackets, built in LCD OSD to provide effective assistant for an administrator to control PC system. RKP Series provides cost effective for your limited IT budget over using CRT and rack mounting. Also, it will be space saving for your compact environment rack and effective assistant for an administrator to control PC system. 4.
RKP215 / RKP217 / RKP219 User Manual 5. Package Contents LCD Monitor Drawer with USB KVM Switch 1 Piece User Manual 1 Piece DC Power Adapter 1 Piece Power Cord 1 Piece Mounting Bracket 1 Pair Fasteners 4 Pieces CB-6 2-in-1 KVM cable 8 Pieces Before Unpacking It is very important to locate the LCD Keyboard Drawer in a suitable environment. ● The surface for placing and fixing the LCD Keyboard Drawer should be stable and level or mounted into a suitable cabinet.
RKP215 / RKP217 / RKP219 User Manual 6. Optional Accessories KVM Cable CB-6 / 10 / 15 6ft / 10ft / 15ft USB 2-in-1 cable Cascade Cable ???? 6ft USB Cascade cable Others 15" - 19" Touchscreen Video Input 24V / 48V DC Power Supply 7. Peripheral Products Rev. : 1.0 Model Description CV-S801 8-Port USB KVM switch CV-S1601 16-Port USB KVM switch CV-S101 CAT.5 USB KVM extender P.
RKP215 / RKP217 / RKP219 User Manual 8. Important Safeguards Please read all of these instructions carefully before you use the device. Save this manual for future reference. ● Unplug the LCD Keyboard Drawer from the power outlet before cleaning. ● Do not spray liquid cleaners or aerosol directly on the device. Wet a cloth with a neutral detergent (e.g. clean water) and squeeze it tight, then clean the screen slightly with it.
RKP215 / RKP217 / RKP219 User Manual 9. Structure Diagram 1. Keyboard 2. Aluminium front panel 3. Class A active matrix TFT LCD panel 4. Analog to digital signal converter board 5. Rear metal case 6. LCD inverter 7. LCD membrane 8. Ball bearing telescopic slides with stopper 9. Adjustable mounting bracket 10. KVM membrane & KVM board • ‚ ƒ „… † Š ‡ Rev. : 1.0 P.
RKP215 / RKP217 / RKP219 User Manual 10. Dimension Diagram RKP215-S8/1601 2U 15” LCD Keyboard Drawer with USB KVM 15” LCD Rev. : 1.0 P.
RKP215 / RKP217 / RKP219 User Manual 10. Dimension Diagram RKP217-S8/1601 2U 17” LCD Keyboard Drawer with USB KVM 17” LCD Rev. : 1.0 P.
RKP215 / RKP217 / RKP219 User Manual 10. Dimension Diagram RKP219-S8/1601 2U 19” LCD Keyboard Drawer with USB KVM 19” LCD Rev. : 1.0 P.
RKP215 / RKP217 / RKP219 User Manual LCD Session Rev. : 1.0 P.
RKP215 / RKP217 / RKP219 User Manual 11.
RKP215 / RKP217 / RKP219 User Manual 11. LCD Session Bright / Contrast 1. Brightness ● To perform brightness adjustment of the input RGB signal ● Use the Left & Right button to adjust and button to “Brightness” 2. Contrast ● To adjust the contrast level of the input signal ● Use the Left & Right button to adjust and button to “Contrast” Phase / Clock 1. Phase ● To adjust input video sampling clock’s phase ● Use the Left & Right button to adjust and button to “Phase” 2.
RKP215 / RKP217 / RKP219 User Manual 11. LCD Session MISC 1. Information ● ● ● The first header row shows the current resolution setup The second header row shows the horizontal frequency of the current input signal The third header row shows the vertical frequency of the current input signal 2. OSD Timer ● To modify the duration of the OSD time-out 3.
RKP215 / RKP217 / RKP219 User Manual 11. LCD Session Resolution Settings For Microsoft Windows Step 1 – Press right click on the desktop Step 2 – Choose “Properties” Step 3 – Change the “Screen Resolution” Step 4 – Change the “Screen refresh rate” Rev. : 1.0 P.
RKP215 / RKP217 / RKP219 User Manual KVM Session Rev. : 1.0 P.
RKP215 / RKP217 / RKP219 User Manual 12. KVM Session Front View Bank No. Selected Channel Online Channel Bank Button Channel Select Button Shift Button LED Indication Selected Channel - Displayed channel on monitor & red in LED. Channel select button - Press to select channel from 1 – 8. Rev. : 1.0 Shift button - Press & Hold follow with a channel button to select channel from 9 – 16. Online Channel - Green LED state the PC has connected and power on. Bank no. - Display the Bank no.
RKP215 / RKP217 / RKP219 User Manual 12. KVM Session Rear View DC Cascade Power Port Channel Port RKP2XX-S801 RKP2XX-S1601 Rev. : 1.0 DC Power -connect to external 12V DC power adapter. Cascade Port -connect to expansion. Console Port - connect to monitor, PS/2 keyboard & mouse. Channel Port - connect to PC computer with CB-6 2-in-1 KVM cable. P.
RKP215 / RKP217 / RKP219 User Manual 12. KVM Session Installation Steps Before installation, please make sure all computers are turned on and its operating system are running properly with keyboard and mouse. 1. Connect the 2-in-1KVM cable to the one of your server. ● USB Type A Male connector to the USB Port ● HDDB 15-pin Male connector to the VGA Port PC I/O windows diagram To VGA port 2. Plug the power adapter included to the switch. DC Power Rev. : 1.0 3.
RKP215 / RKP217 / RKP219 User Manual 12. KVM Session Cascading Using a USB KVM cable to connect from Bank 1’s “Cascade port” to Bank 2’s “Console port”. After connected please press “Bank” & “Channel” button on the front of the USB KVM switch to reset the USB KVM switch. Bank 1 Bank 2 Bank 8 (Max.) USB Cascade cable USB Cascade cable Cascade level Max. : 8 level Rev. : 1.0 ● Max. PC connection is 128 or with additional 122 PCs. ● All USB KVM switch is compatible & can cascade with each other.
RKP215 / RKP217 / RKP219 User Manual 13. Start Up 1. The channels that have PC connected and it is switch on will have a green LED on that channel. 2. The red LED will indicate the selected channel. 3. 7 segments LED will display the bank number. 4. Press channel button to select the channel. 5. Enter the password, default is “00000000” eight zeros. 6. Otherwise the keyboard & mouse will be locked. 7. If you forget your password, send back to Manufacturer. HotKey Command Rev. : 1.
RKP215 / RKP217 / RKP219 User Manual 13. Start Up Hot-key Command Operation 1. Calling OSD Menu Scroll 2. £ + Scroll + ¤ + Switch to Previous Bank Scroll 5. Scroll + Switch to Next Power On Port (powered on PC only) Scroll 4. Space Bar + Switch to Previous Port (powered on PC only) Scroll 3. Scroll + Scroll + First digit of Port Number: 0 for Port 0-9 1 for Port 10-16 Pg Up + Second digit of port Num- Switch to Specific Port Scroll Scroll + Bank 1~8 + No. 0 or 1 + No.
RKP215 / RKP217 / RKP219 User Manual 13. Start Up HotKey Command Operation 6. Switch to Next Bank Scroll 7. + + Note: PgDn Scroll B + The default Beeper function is ON and beeper control is only for available for Scan Mode. Auto Scan for Powered on PC Scroll 9. + Enable / Disable beeper sound Scroll 8. Scroll + Scroll S + Reset to factory Default Setting Scroll + Note: Scroll R + ROM REFLASH Not available for password reset. 10. Find Port by name Scroll Note: Rev. : 1.
RKP215 / RKP217 / RKP219 User Manual 13. Start Up KVM OSD Operation Note: When using the keyboard arrow key to move the cursor, the keypad arrow key (Up, Down, Right, Left) is unable to work at this menu. 1. “MAIN CONTROLS” - OSD Menu of USB KVM switch ● To pop up MAIN CONTROLS—OSD menu of USB KVM switch, please use hot keys command . ● To operate MAIN CONTROLS, please use keyboard and mouse. ● ● ◇ Mouse Operating: You may also simply use mouse, twice clicking left button, to choose a category.
RKP215 / RKP217 / RKP219 User Manual 13. Start Up LANGUAGE Menu LANGUAGE ?X CHOOSE A LANGUAGE : 01 ENGLISH Mouse Operation : ● Move mouse and click the left button to choose a language, and click left key again to save. Keyboard Operation : ● Rev. : 1.0 Press é / ê to choose a language and press ENTER to save. P.
RKP215 / RKP217 / RKP219 User Manual 13. Start Up PORTNAME Menu PORTNAME Bank 1 01 SYSTEM 01 02 ☼ SYSTEM 02 03 ☼ SYSTEM 03 04 ☼ SYSTEM 04 05 ☼ SYSTEM 05 06 ☼ SYSTEM 06 07 ☼ SYSTEM 07 08 ☼ SYSTEM 08 09 SYSTEM 09 ?X Bank Session 5 PC Name Session 6 Use “Tab” key to select session like Bank, PC, OSD, SCAN, CHANGE PASSWORD, CONSOLE ON/OFF, etc… Bank Session Use Page Up & Page Down to switch previous or next bank PC Name Session 1.
RKP215 / RKP217 / RKP219 User Manual 13. Start Up TIMEVIEW Menu TIMEVIEW OSD 10 SCAN : 10 1. 2. Rev. : 1.0 ?X SEC SEC OSD TIME means the display period of OSD windows or PC system name on your monitor. You can modify it from 05 sec to 99 sec. The factory default value is 10 sec... SCAN TIME means the scan interval from one PC port to next PC port. The default SCAN time is 10 sec and the maximum scan time is 99 sec.
RKP215 / RKP217 / RKP219 User Manual 13. Start Up SECURITY Menu SECURITY ?X ENTER PASSWORD ________ ENTER NEW PASSWORD ________ RETYPE NEW PASSWORD ________ ● To CHANGE PASSWORD for avoiding all PC systems to be intruded by the others. The default password is 8 digits “ 00000000 “. ● Please follow the steps below to cahnge the password. 1. Enter the factory default password “00000000” in the first row “ENTER PASSORD” and press the “Enter”. ENTER PASSWORD •••••••• 2.
RKP215 / RKP217 / RKP219 User Manual 13. Start Up FINDPORT Menu FINDPORT ?X ENTER NAME : _ _ _ _ _ _ _ _ _ _ “FINDPORT“ option helps you to find the PC system by its name. ● Enter PC system name and press ENTER, it will search the matching PC system and given the message for searching result. Note: PC system name is defined in PORTNAME function. Example ： a) If you enter a PC name which can be found on the system, the window will show the PC system name you searched and which BANK it belongs to.
RKP215 / RKP217 / RKP219 User Manual 13. Start Up CONSOLE Menu CONSOLE ?X ENABLE DISABLE ● ● ● ENABLE – any user can use the console DISABLE – user is not allowed to use the console port, unless password is entered.When password is entered already and pass the KVM switch authentication, the CONSOLE will be set to ENABLE. Default – ENABLE no password is required Note: After finish the usage of KVM switch, please don’t forget to set up CONSOLE ENABLE state to DISABLE state.
RKP215 / RKP217 / RKP219 User Manual 14. FAQ Rev. : 1.0 1. Keyboard or mouse dose not work or not be compatible with the PC. Please make sure the keyboard or mouse works when directly plug into the computer. If the problem persists, please try another keyboard or mouse. 2. Mouse doesn’t work in Auto Scan mode You can press any key on the keyboard or the front button on the face plate for returning standard mode and then use the Keyboard or Mouse again. P.
RKP215 / RKP217 / RKP219 User Manual 15.
RKP215 / RKP217 / RKP219 User Manual 15. Technical Specifications LCD Item Description LCD Screen Manufacturer South Korea LCD Origin Panel 15” TFT 17” TFT 19” TFT Resolution 1,024 x 768 1,280 x 1,024 1,280 x 1,024 Brightness 300 cd/m2 350 cd/m2 500 cd/m2 Color 16.2 Million 16.2 Million 16.7 Million Contrast Ratio 450:1 350:1 500:1 Viewing Angle 140° x 125° 140° x 120° 170° x 170° 304 x 228 mm 337 x 270 mm 376 x 301 mm 0.297 mm 0.264 mm 0.
