FCD-IPM Installation and Operation Manual Chapter 5 Setup Menu
Interface Parameters Menu 5-49
Busy Idle T1 signal is held at active for 2.5 seconds, and then toggled to inactive
until the Out of Service condition end.
Time Slots for Voice Ports
Refer to Timeslots Mapping in Table 5-17.
A typical screen is shown in Figure 5-54.
T1 TIME SLOTS MAPPING: LINK 1 ( Device name - FCD-IPM )
-----------------------------
TS1 [DATA LINK1 ] TS13 [NC ]
TS2 [DATA LINK1 ] TS14 [I/O1 VOICE 1 ]
TS3 [NC ] TS15 [I/O1 VOICE 2 ]
TS4 [NC ] TS16 [NC ]
TS5 [FIX SUB-VOICE ] TS17 [NC ]
TS6 [FIX SUB-VOICE ] TS18 [NC ]
TS7 [FIX SUB-DATA ] TS19 [I/O2 VOICE 1 ]
TS8 [NC ] TS20 [I/O2 VOICE 4 ]
TS9 [NC ] TS21 [NC ]
TS10 [NC ] TS22 [NC ]
TS11 [NC ] TS23 [NC ]
TS12 [NC ] TS24 [NC ]
Enter time slot number (0 refers to all the time slots)
Press 'ENTER' - to toggle the time slot type
Press 'ESC' - to Return to previous menu
Time slot number :
Figure 5-54. T1 Time Slots Mapping Link1 Screen
Alarm Filter
The Alarm Log File can show all events and alarm statuses that have occurred in
the E1/T1 interface. You can use the Alarm Filter to mask or unmask events from
the Alarm Log File.
