FCD-IPM Installation and Operation Manual Chapter 5 Setup Menu
WAN Economy Menu 5-85
To configure the operation:
1. From the Filters menu, choose Block and Forwarding.
2. Toggle between Block and Forward.
To configure the broadcast control:
The broadcast control filter manages special frames, normally not propagated
throughout the network. The frames managed are:
• IP - Local broadcast propagation
• IPX - Zero destination propagation, IPX Type 20 frames propagation
• NETBIOS over IP - IP frames with TCP/UDP ports 137, 138, 139 propagation.
From the Filters menu, press 2 to toggle between Full Propagation and Block
Propagation.
Factory default: Block Propagation.
Quick Filters are defined per protocol. Configure each protocol that you want to
block or forward.
To configure the Quick Filter parameters:
1. From the Filters menu, choose Quick Filters.
The Quick Filters menu appears (refer to Figure 5-89).
2. To toggle between Forward/Block, press the number of the protocol that you
want to filter.
QUICK FILTERS (Device name - FCD-IPM)
Choose the protocols you want to block or forward!!:
(The Blocking or forwarding is to interface LAN 1 only)
1. IP NO FILTERS
2. IPX NO FILTERS
3. SNA NO FILTERS
4. NetBIOS NO FILTERS
5. AppleTalk NO FILTERS
6. DECnet NO FILTERS
7. Others NO FILTERS
ESC - Return to previous menu
Choose one of the above:
Figure 5-89. Quick Filters Menu
