Chapter 4 Configuration FCD-IPM Installation and Operation Manual
4-2 Quick Setup Menu
• Exit – Select this option to return to the Operational Status Messages screen. In
this mode you can view real-time information about the unit’s activities.
4.2 Main Menu
Figure 4-1 shows the Main Menu options.
The name of the device connected to the terminal (FCD-IPM) is listed at the top of
the screen.
To choose an option from the Main Menu:
Type the number preceding the option.
MAIN MENU (Device name - FCD-IPM)
----------
1. Quick setup
2. Security setup
3. Advanced setup
4. View
5. Diagnostic tools
0. Exit
Press number to select or ESC to return to the previous menu
Figure 4-1. FCD-IPM Main Menu
4.3 Quick Setup Menu
The parameters listed on the Quick Setup Menu include most of FCD-IPM's
internetworking features:
• WAN Interface
• IP Parameters
• Physical connections
• Protocol
• Routing type.
The Quick Setup screen presents messages that prompt you to accept or modify
the current parameters. The parameter options are enclosed in brackets [ ].
To access the Quick Setup Menu:
1. In the Main menu, press 1.
The Quick Setup menu appears, showing the first parameter, Link Status.
To accept the current parameter:
• Press <Enter>.
