Chapter 4 Configuration FCD-IPM Installation and Operation Manual
4-36 View Menu
Table 4-8. SHDSL Status Screen Parameters
Parameters Possible Values Description
Op. State
Idle
Handshake, Training,
Framer Sync
Data
Operational status of the SHDSL link
Link is down
FCD-IPM is establishing communication link with remote
device
Data is being transferred over the SHDSL link
Bitrate
Actual line rate after the handshake process is completed
Loop Attenuation
Difference (in dB) between the power transmitted from FCD-
IPM and the power received by the unit operating at the other
side of the application
Transmit Power
Level of power (in dB) which is transmitted on the SHDSL line
SNR
Signal-to-noise ratio, difference (in dB) between signal and
background noise
SHDSL DSP Version,
SHDSL Driver
Version
SHDSL DSP and driver revisions
Loop Attenuation, Transmit Power and SNR are displayed only when OP. State is in
Data mode.
SHDSL STATUS ( Device name - FCD-IPM )
Op. State : Data
Framer Status : Sync
Bitrate : 1032
Loop Attenuation : 5
Transmit Power : 7.5
SNR : 14
SHDSL DSP Version : 1
SHDSL Driver Version: R1.7.1
CRC ES SES LOSW LOSWS UAS
-------- ---- ---- ---- ---- ----- ----
15 Min : 3 1 0 0 0 0
24 hours : 0 0 0 0 0 0
ESC - previous menu | M - More | R - Refresh | C - Clear statistics
Figure 4-40. SHDSL Status
Note
