49-2511.fm Page 1 Friday, November 17, 2000 4:45 PM Please read before using this equipment.
49-2511.fm Page 2 Friday, November 17, 2000 4:45 PM ˆ Introduction Your RadioShack B/W 9-Inch 4-Channel Security Monitor is an important addition to your existing security system. It features flexible operation with many security-oriented benefits. Your monitor includes these features. 9-Inch (measured diagonally) Monitor — provides a clear view for security detail. Warning: This system is not waterproof. To reduce the risk of electrical shock or damage, do not expose this system to rain or moisture.
49-2511.fm Page 3 Friday, November 17, 2000 4:45 PM • This system is designed for indoor use only. AUDIO (IN), a yellow VIDEO (IN), a black AUDIO (OUT) and a DC 12V (OUT) barrel plug. Connect the yellow jack, the white jack, and the barrel plug to the long cable that comes with your camera as follows: • Do not install any camera or monitor where it will be exposed to high humidity or rain. • Select a location for the monitor that will not be blocked by objects or traffic.
9-2511.fm Page 4 Friday, November 17, 2000 4:45 PM ˆ Operation Press POWER on the monitor. The AUTO indicator lights and the monitor automatically scans the input to all of its jacks in sequence. If you did not connect a camera to one or more of the jacks, the monitor displays a blank screen when it scans those jacks. To have the monitor skip a blank screen, see “Programming a Viewing Sequence.” To manually select a single camera’s view, press AUTO. The AUTO indicator turns off.
49-2511.fm Page 5 Friday, November 17, 2000 4:45 PM CONT (Contrast) — Adjusts the contrast between the dark and light parts of the picture. jacks of your VCR using video-quality shielded cables (not supplied). Monitor BRT (Brightness) — Adjusts the overall brightness of the screen. V-HOLD (Vertical Hold) — Stops the picture from rolling. VCR H-HOLD (Horizontal Hold) — Stops horizontal tearing. AUDIO (Volume) — Adjusts the sound volume picked up by all camera microphones.
49-2511.fm Page 6 Friday, November 17, 2000 4:45 PM VCR Playback to the Monitor 3. Begin playback on the VCR. 4. When you finish playing the recorded tape and have turned off the VCR, press AUTO to return to sequential camera scanning To view a recorded tape through the monitor, follow these steps. 1. Turn on the monitor and the VCR. 2. Press VCR on the monitor's front panel. The VCR indicator lights. ˆ Care Image is not clear. Keep the monitor dry; if it gets wet, wipe it dry immediately.
49-2511.fm Page 7 Friday, November 17, 2000 4:45 PM ˆ Specifications Picture Tube ............................................................................ B/W 10" tube with 90° deflection Power Source ................................................................................................... AC 120V, 60 Hz Power Consumption ................................................................................................. Max. 40 W Resolution ......................................................
49-2511.fm Page 8 Friday, November 17, 2000 4:45 PM Limited Ninety-Day Warranty This product is warranted by RadioShack against manufacturing defects in material and workmanship under normal use for ninety (90) days from the date of purchase from RadioShack companyowned stores and authorized RadioShack franchisees and dealers.
