PPHP1594 PPHP1595 OWNER'S MANUAL www pyleaudio com
Contents Safety Instructions 1 About the PPHP1594 PPHP1595 2 Applications Features Loudspeaker Placement and Mounting Troubleshooting Specifications Frequency Response 2 2 2 3 4 4 Safety Instructions WARNING: Do not expose this unit to rain or moisture. Do not remove cover or back. No user serviceable parts inside. Please refer all servicing to qualified personnel. Important Safety Instructions 1. 2. 3. 4. 5. 6. 7. 8. Please read all instructions before operating the unit.
ABOUT THE PPHP1594 PPHP1595 PPHP1594 PPHP1595 ABOUT THE PPHP1594 PPHP1595 Applications Live sound reinforcement, speech and vocals, music playback in entertainment, A/V, and institutional venues especially when ease of use and portability are important factors. Features 15" low-frequency driver with dual neodymium magnet for low-distortion and light weight. Parallel Speakon connections allow daisychaining of a second speaker. Integral 35mm pole mount receptacle with securing thumb screw.
TROUBLESHOOTING PPHP1594 PPHP1595 TROUBLESHOOTING Symptom No sound Likely Cause Speaker not connected to amplifier Speaker cable is faulty or improperly connected. Signal source(mixer, instrument, etc.) Is not sending a signal. NO sound. Speaker comes on. Faulty cables and connections Signal sounds distorted and very loud. Excessive input signal, trying to exceed the capabilities of the speakers Signal sounds distorted even at Mixer or other source is moderate volumes.
SPECIFICATIONS PPHP1594 PPHP1595 Specifications • • • • • • • • • • • • • • Rugged, Light-Weight Co-Polymer Enclosure Multi-angle enclosure for Front of House or Stage MonitorApplication Power Rating: 375W RMS 900W Peak Integral Frame 15'' Woofer w/Dual Neodymium Magnets 2'' Kapton VC 1'' Titanium Compression Driver, Ferro-Fluid Cooled Frequency Response (±3dB): 35Hz-20kHz 1W@1M SPL: 108dB Impedance: 8 Ohms Crossover Frequency: 2.
Place Stamp Here PYLE PRO Audio, Inc.
Thank you for purchasing this PYLE product. To activate your warranty, please mail this card within 10 days. Limited Warranty Our obligation under this warranty is limited to the repair or replacement of the defective unit when it is returned to us prepaid. This warranty will be considered void if the unit was tampered with, improperly s e rv ic e d o r s u b je c t to m is u s e , n e g le c t o r a c c id e n ta l d a m a g e .
