72
T48C862-R8
4590B–4BMCU–02/03
Figure 68. Example of MCL Receive Dialog
8-bit Pseudo MCL Mode In this mode, the SSI exhibits all the typical MCL operational features except for the
acknowledge-bit which is never expected or transmitted.
7654321 76543210
A
msb
lsb
tx data 1 rx data 2
msb lsb
Write STB
(tx data 1)
SC
SD
SRDY
ACT
Interrupt
(IFN = 0)
Interrupt
(IFN = 1)
0A
Read SRB
(rx data 2)
SIR
SDD
Start
Stop
