User Manual DVI-D KVM Switch 1U KVM Switch with DVI-D Connections Features: »» 12 Port »» Single User
Contents Safety Notice iii 1 Product Overview 1 1-1 Package Content (Standalone KVM) 1-2 Package Content (Integrated KVM) 1-3 DVI-D KVM Table 2 Installation 2-1 2-2 2-3 2-4 Before Installation Unpacking the Unit Installation Instructions (Standalone KVM) KVM Port & CATx Dongle Connection 3 Operation 1 1 2 3 3 3 3 4 5 3-1 KVM Button 3-5 Hotkeys for KVM 5 6 4 Product Specifications 7 4-1 Specifications Table 5 Important Information Warranty Information What the Warranty Does N
Safety Notice Please read the following before using your Raloy unit: ■■ Unplug equipment before cleaning. Don’t use liquid or spray detergent; use a moist cloth. ■■ Keep equipment away from excessive humidity and heat. Preferably, keep it in an air-conditioned environment with temperatures not exceeding 40º Celsius (104º Fahrenheit). ■■ When installing, place the equipment on a sturdy, level surface to prevent it from accidentally falling and causing damage to other equipment or injury to persons nearby.
1 Product Overview 1-1 Package Content (Standalone KVM) ■■ 1 x KVM Unit KVM unit ■■ 1 x Mounting set w/ bracket & screws ■■ 1 x Power cord (for KVM) 1-2 Package Content (Integrated KVM) ■■ 1 x KVM Unit KVM unit 1
1-3 DVI-D KVM Table www.Raloy.com/support/downloads.
2 Installation 2-1 Before Installation ■■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. 2-2 Unpacking the Unit The equipment comes with the standard parts shown in package content. Check and make sure they are included and in good condition. If anything is missing, or damaged, contact Raloy immediately.
2-4 KVM Port & CATx Dongle Connection USB Servers DVI-D KVM port Power Audio 12 11 10 9 8 7 6 5 4 3 2 1 USB Servers RCI-6 / RCI-10 / RCI-15 Combo KVM Cable ■■ 6 / 10 / 15 ft. DVI KVM cable ■■ Server end: DVI-D, USB, & Audio ■■ KVM port: DVI-D & USB3.0 IP console, remote console, daisy-chain and OSD menu are NOT available for this model.
3 Operation 3-1 KVM Button Power ON ■■ Turn off all servers and KVM switches ■■ Make sure all cables / connectors are properly connected ■■ Power ON sequence 1. Turn on Rack Monitor (if applicable) 2. Turn on KVM switch 3.
3-5 Hotkeys for KVM Hotkey Function Scroll Lock + Scroll Lock + Switch to previous port Scroll Lock + Scroll Lock + Switch to next port Scroll Lock + Scroll Lock + Port no. Switch to specific port Scroll Lock + Scroll Lock + S Auto scan for powered on PC Scroll Lock + Scroll Lock + B Enable / Disable beeper sound Remarks: ■ Example of “Scroll Lock + Scroll Lock + Port no.” - Port No. : 01 to 12 - e.g. Port 4 : Scroll Lock + Scroll Lock + 0 + 4 - e.g.
4 Product Specifications 4-1 Specifications Table Product Information Dimensions (W x D x H) Gross Weight Packaging Information Dimensions (W x D x H) Gross Weight Environmental -5 to 60 °C (23 to 140 °F) Number of Ports Connector Connectivity Graphic Connector Resolution Input Device Audio Out Multi-Platform Support Power Input Consumption Regulatory Safety Environment 7 11.9 lbs / 5.4 kg Storage Temperature Vibration Compatibility 500 x 400 x 90 mm (19.7 x 15.7 x 3.5 in.
5 Important Information Warranty Information I. Raloy Limited Warranty Raloy Customer Support warrants to the original retail purchaser that this product is and will be free from defects in materials and workmanship for a period of twenty-four (24) months from date of purchase. During the warranty period, the purchaser must promptly contact Raloy Tech Support for assistance to report a unit failure. II. Warranty Period 1.
What the Warranty Does Not Cover ■■ Any product, on which the serial number has been defaced, modified or removed. ■■ Damage, deterioration or malfunction resulting from: ■■ Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product modification, or failure to follow instructions supplied with the product. ■■ Repair or attempted repair by anyone not authorized by us. ■■ Any damage of the product due to shipment. ■■ Removal or installation of the product.
