LED / Status Recommended Corrective Action
- POWER
- TSTAT/CIRC
- LIMIT
- DAMPER
Retry / Recycle
Delay
1. No Spark
a. Can you hear sparking?
- If there is no spark noise replace the control.
b. If you can hear spark noise check the following:
- Loose connection in ignition cable or ground wire
- Continuity of ignition cable
- Break in ignition cable insulation
- Loose ground connection
- Break in pilot ceramic insulator
- Incorrect pilot spark gap
2. No Pilot Flame
a. If pilot does not light check the following:
- All manual gas valves are open
- Supply tubing is not plugged, kinked or leaking
- Gas line pressures are good
- Gas line is purged of air
- Pilot orice is not plugged (pilot gas is owing)
- Condensate quenching pilot
Note: It may be necessary to recycle the “call for heat” more than once to clear the pilot supply tubes
of air.
b. If no gas ow check the following:
- 24 volts across PV and MV/PV at gas valve, if voltage ok replace defective gas valve
- Check for break in wiring harness to gas valve
- 24 volts across control connector P4-6 and P4-7, if no voltage at control replace defective control
3. Spark does Not Stop When Pilot Lights
If the spark does not stop when the pilot lights check the following:
- Loose connection in ignition cable or ground wire
- Continuity of ignition cable
- Clean ame rod
- Pilot electrode porcelain cracked
- Pilot ame covers ame rod and is steady and blue, if not adjust pilot ame
- Low gas pressure at gas valve inlet
- Defective control
4. Main Flame Does Not Light
If the main burners do not light check the following:
- Check orice size and/or blockage
- 24 volts across control terminals P4-5 and P4-7? If no voltage while in defective control.
- 24 volts across MV and MV/PV at gas valve? Check for break in wiring harness to gas valve
- Defective gas valve
5. Circulator is On, Damper is Open But Boiler Fails to Start (continued)
