21222324252627282930
30
Key
No.
Description Part Number
Boiler Model
RRG062 RRG096 RRG130 RRG164
Section Assembly and Canopy Assembly
1 Cast Iron Section Assembly (Complete)
6171703 1 --- --- ---
6171704 --- 1 --- ---
6171705 --- --- 1 ---
6171706 --- --- --- 1
2 Flue Bafe 71106001 2 3 4 5
3 Canopy Assembly
611170302 1 --- --- ---
611170402 --- 1 --- ---
611170502 --- --- 1 ---
6111706010 --- --- --- 1
4
Cerafelt Sealing Strip ½" x 1" x 10'
(Canopy for Section Assembly)
6206001 1 1 1 1
5
Carriage Bolt ¼" - 20 x 1" 80860115
2 2 2 2Flat Washer, ¼" 80860603
Nut, Hex ¼" - 20 80860407
